  • Page 1 CS-LAN User Manual Version 1.0.1 2015/07/12 www.sysbas.com...
  • Page 2 Revision History Revision Date Document Version Pages Description July. 20. 2015 Initial release...

  • Page 3: Table Of Contents

    Contents Chapter 1 Overview  About this Manual  Reader  Documents  Technical Supports Chapter 2 Getting Started  Overview  Features  Application Chapter 3 Hardware Specifications  Hardware   Serial Port Pin Specifications Chapter 4 Connecting Network ...
  • Page 4 Chapter 7 Appendix  Trouble Shootings  Specifications...

  • Page 5: Chapter 1 Overview

    This manual was prepared for the users of CS-LAN. It is recommended to thoroughly read and understand this manual prior to using or setting the CS-LAN. This manual includes the application of hardware level and settings of software level. This manual is intended to help the users to easily control and manage the device to be connected with CS-LAN.

  • Page 6: Technical Supports

    Technical Supports SystemBase provides technical support through two methods below: 1. Send an e-mail to our technical support team at tech@sysbas.com to receive fast responses. Any questions, requests, suggestions or comments are welcomed. 2. For instant response, call us. Our technical team will always provide detailed consultation and guides through a simple phone call.

  • Page 7: Chapter 2 Getting Started

    The communication specification supports IEEE 802.3 10/100Base-TX and amounts RS232 standard DE9 connector, thereby providing the serial communication speed at the highest 921.6Kbps and Ethernet communication speed at 100Mbps. A CS-LAN is the device that connects the remote control, monitoring and various types of serial devices in the device connected via network.
  • Page 8 Contents of Package The CS-LAN package is composed as follows. Check if all components are included in the package. CS-LAN device unit 1 5V DC Adaptor Ethernet Cable CS-LAN User Manual Class A equipment Sellers or users should be aware of the fact that this device is intended for industrial use(Class A),...

  • Page 9: Application

    CS-LAN can be applied in various fields. Network Serial Communication As the most common example of application, The PC and CS-LAN are connected to a network so the serial devices connected to CS-LAN can be used in the PC. Serial Communication Tunneling A serial cable connected between the PC and serial device is extended to network so it can be used as a serial cable (without distance limits).
  • Page 10 COM Port Redirection Using a redirection to use the serial port of CS-LAN connected to network as the serial port mounted on a PC. Factory / Industrial Automation PLC, Robot, Arm, Human-Machine Interface, Logistics storage rail Medical device, tester controller...

  • Page 11: Chapter 3 Hardware Specifications

    LED: Indicate the operation of CS-LAN. The next chapter provides each LED functions from the LED states.  LAN Port: This port (8-pin RJ45) is used in connecting CS-LAN with Ethernet card, hub, router and other wire network connector. LED Name...

  • Page 12: Serial Port Pin Specifications

    Receive Data (Input) Transmit Data (Output) Data Terminal Ready (Output) Ground Data Set Ready (input) Request to Send (Output) Clear to Send (Input) * CS-LAN is a DCE (Data Communications Equipment) converter that is directly connected to DTE equipment such as PC.

  • Page 13: Chapter 4 Connecting Network

    First the users need to know the network address, IP Address where the CS-LAN is being operated. If LAN port of CS-LAN is used by IP assigned from DHCP or set on a fixed static ID address or unknown ID address, this manual provides how to access the CS-LAN as follows.

  • Page 15: Chapter 5 Setting Via Web

    This chapter is intended to provide web settings for CS-LAN. Access Open a web browser and enter an IP address of CS-LAN to bring up the authentication window at the first access. Enter “cslan” in ID and “99999999” in password to bring up a web setting page.
  • Page 16 Menu Default Description Device CS-LAN To set the name of a device Name MAC Address Distinct Address To show a MAC Address Connection Type Static To select if static IP or dynamic IP assigned from DHCP is selected To set the current ID address IP Address 192.168.0.223...

  • Page 17: Serial Setting

    Serial Setting The operation settings of serial port are set at the serial settings. After changing the settings, press a [Submit] button to save the changes, and the system should be restarted via reboot menu in order to apply the changes to the actual operation. If not saving the changes prior to exit, the changes will be lost.
  • Page 18 COM port. TCP Server CS-LAN plays a role as a socket server to standby for accessing from client on the network. The socket number is set at the [Local Port] and once the socket access is completed, the data generated between the socket and the serial port will be transferred as it is.
  • Page 19 Menu Default Description once is to be buffered and stood by at the set time prior to rereading. If there’s new data received, it will fill the buffer again but if not, all received data will be sent to a socket at once; therefore, no traffic issue is caused but is not to assure its real temporality.

  • Page 20: Change Id/Pw

    Please be aware that this setting is saved and applied at the same time without rebooting. Reboot A device is restarted. If you change the settings and save them via a submit button. The CS-LAN is restarted with the changes.

  • Page 21: Chapter 6 Utility-Based Setting

    Settings Select a list of devices for setting among the searched devices and click a configure button to bring a CS-LAN setting window as shown in the follows. Please refer to SGConfig manual for more detailed information on option and setting.
  • Page 22 Check if the computer and CS-LAN are on the same network if TCP/IP used. (Check the connection with CS- LAN via a ping command in the computer). IP address of CS-LAN is found on the logical network same as host computer.
  • Page 23 TCP, UDP, ICMP, DHCP, HTTP Software Utility Redirector, TestView, SGConfig Configuration Web, SGConfig Ordering Information CS-LAN *Reset Button Function Operation Result Warm Booting Press less than 3 seconds CS-LAN is restarted. Factory Default Press more than 3 seconds Cs-LAN settings are reset...
  • Page 24 Copyright Copyright ⓒ 2020 SystemBase CO., Ltd. All rights reserved. This manual is a document protected by Copyright law. Unauthorized copying, duplicating, publishing of some or all of contents without prior consent from SystemBase is against Copyright Law. www.sysbas.com...
  • Page 25 If you have any inconvenience while using the product, please contact us. Email: Working Hour • Purchase/Quotation: overseas@sysbas.com MON ~ FRI 9:00 ~ 18:00 • Technical Support/RMA: tech@sysbas.com www.sysbas.com Tel: +82-2-855-0501 Fax: +82-2-855-0580 Copyright ⓒ 2020 SystemBase Co., Ltd. All Right Reserved.
