- Page 1 sWiFi/all User Manual Version 1.0 2020.04.06...
- Page 2 User Manual Revision History Revision Date Version Pages Description 04/06/2020 Copyright 2006-2016 SystemBase Co., Ltd. All rights reserved. Websites http://www.sysbas.com/ Phone +82-2-855-0501 +82-2-855-0580 16F Daerung Post Tower-1, 288, Digital-ro, Guro-gu, Seoul, Republic of Korea (Postal code 08390) For any inquiries or comments, please contact our technical support department.
-
Page 3: Table Of Contents
목차 sWiFi/all User Manual CONTENTS 1. OVERVIEW .......................... 3 1. Package ....................................3 2. Operating Environment ..............................3 3. Techinical Support ................................3 2. FEATURE ..........................4 2.1 Station Mode ..................................4 2.2 COM Redirector Mode .............. 오류! 책갈피가 정의되어 있지 않습니다. 3. - Page 4 목차 sWiFi/all User Manual 5.4 View Settings ..................................9 5.5 Setting Description ..............................11...
-
Page 5: Overview
OS: Windows XP or above 3. TECHNICAL SUPPORT SystemBase provides technical support to customer in three ways. Technical support may be obtained through technical support or FAQ at our website https://www.sysbas.com/en. For faster response, please email technical support team at tech@sysbas.com... -
Page 6: Feature
sWiFi/all User Manual 2. Specification 2. SPECIFICATION sWiFi/all is an ultra-small serial converter that provides WiFi wireless connectivity function to equipment supporting RS232, RS422, RS485. The communication specification supports 2.4GHz, 5GHz IEEE 802.11 a/b/g/n and supports standard serial communication. sWiFi/all connects various kinds of serial equipment to the network, including remote control and monitoring of devices connected through the network. -
Page 7: Com Redirector Mode
sWiFi/all User Manual 2. Specification 2.2 COM Redirector Mode The serial port of sWiFi/all connected to the network can be used as if were a serial port mounted on a... -
Page 8: Hardware
sWiFi/all User Manual 3. Hardware Configuration 3. HARDWARE CONFIGURATION 3.1 sWiFi/all Appearance sWiFi/all is a DCE(Data Communications Equipment) type converter that connects directly to DTE equipment such as PCs. Pressing the factory reset button for more than 3 seconds will reset the sWiFi/all to the default state. -
Page 9: Serial Port (De-9 Female)
sWiFi/all User Manual 3. Hardware Configuration 3.2 Serial Port (DE-9 FEMALE) Pin No. Signal Description Receive Data (Input) Transmit Data (Output) Data Terminal Ready (Output) Ground Data Set Ready (input) Request to Send (Output) Clear to Send (Input) 3.3 LED Operating Status LED Name State Operation... -
Page 10: Console Setting
sWiFi/all User Manual 5. Console Setting 4. HOW TO CONNECT This chapter provides information necessary for sWiFi/all to connect and operate with the desired serial devices, such as wireless LAN and serial connection. Procedure for connecting sWiFi/all to devices and networks is as follows. 4.1 Power Supply Check that the input voltage supplied to sWiFi/all matches the model’s specification and supply the voltage. -
Page 11: Utility Setting
sWiFi/all User Manual 5. Utility Setting 5. SETTING IN UTILITY sWiFi/all provides a setup method through sWiFiConfig.exe utility. 5.1 Mode Setting The initial sWiFi/all serial port settings are 9,600bps, 8bit, 1stop, no parity. 5.2 Setting Click the Supply Config button to change the sWiFi/all settings. The data set at this time will be stored in sWiFi/all and with the reset of sWiFi/all, it will work in the changed settings. - Page 12 sWiFi/all User Manual 5. Utility Setting 5.4 View Settings Click the ReadConfig button in the program to view the current setup status of sWiFi/all. You can view or execute console commands through the console window at the bottom of the program.
- Page 13 sWiFi/all User Manual 5. Utility Setting 5.5 Setting Description Default Description command Set the operating protocol to be used on the serial port. com_redirector Make the serial port on CS sWiFi/all available as a virtual COM port on a PC in Windows 2000/XP/2003/Vista/7/8.1 environment.
- Page 14 sWiFi/all User Manual 5. Utility Setting Default Description command the socket at once. For example, if a serial device transmits 100 bytes of text from a serial device to a socket on the server via CS sWiFi/all, if the value is 0, the data entered in bytes at a time is immediately sent to the server through the socket, ensuring real time, but causing a lot of traffic to the network.
- Page 15 sWiFi/all User Manual 5. Utility Setting FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 16 sWiFi/all User Manual 5. Utility Setting and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
