- Page 1 KAYO MOTO KMB60 Assembly Manual WWW.KAYOMOTO.COM...
- Page 3 ① Torque wrench ② 6mm hexagon socket ③ 17mm socket ④ No. 10-12 wrench ⑤ No. 12-14 wrench ⑥ No. 5 hexagon wrench ⑦ No. 8 wrench ⑧ Phillips screwdriver ⑨ Needle nose pliers 1. The above picture shows the tools needed to unpack and install the vehicle 3.
- Page 4 Name Quantity A User’s manual B Vent valve Pipe clamp C Handlebar upper clamps Hexagon socket head screw M8*25 D Battery E Handlebar pad F Cable tie G Battery belt H Spark plug socket Setback lining 6. Use tool ①② to lock handlebar upper clamps(C), and the distance between the two ends of the mark is close, tighten evenly, first start by hand tightening all four clamp bolts...
- Page 5 9. Use tool ⑦ to remove the screws on the lower clamps, put on setback lining(I) and then tighten the screws. 11. Use tool ④⑦ to disassemble the oil pipe 12. Use tool ④ to remove the fixing screws clamp, then insert the front disc brake oil pipe, under the seat.
- Page 6 14. Use tools ①③⑤⑨ to remove the flange shaft fixed to the front shock and the iron wire fixed to the rear wheel. 15. Put the vehicle on the stand for easy 16. Use tool ①③⑤ to install the front wheel installation of other accessories.
- Page 7 19. Please read the user’s manual (A) carefully before riding to better understand the performance of the vehicle.
