- Page 1 KAYO MOTO Assembly Manual WWW.KAYOMOTO.COM...
- Page 2 ① Torque wrench ② Needle nose pliers ③ 12mm socket ④ 21mm socket ⑤ 17mm socket ⑥ No. 8-10 wrench ⑦ No. 12-14 wrench ⑧ 6mm hexagon socket ⑨ Phillips screwdriver ⑩ No. 8 T-sleeve ⑪ No. 10 T-sleeve 1. The above picture shows the tools needed to unpack and install the vehicle 2.
- Page 3 Name Quantity Name Quantity Accessory box Handlebar foam & padding cover Front fender Cable tie User’s manual Side stand Spring Spark plug sleeve Bolt Spacer Front wheel 6. Remove the wire fixing the vehicle and the 7. Use tool ① ⑧ to remove the clamps and the fixed iron frame.
- Page 4 10. Use tool ⑩ to remove the front fender fixing 11. Use tool ⑤ ⑦ ⑨ to install C (Torque requirement screws, install B and tighten the screws back. is 20-30N.m). 12. Remove the front axle screw and take away 13.
- Page 5 16. Use tool ⑪ to remove the fixing screws on 17. Adjust the fuel tank switch to the position like the left and right sides of the seat cushion and above. remove it, then use ⑨ to install the battery screws, and finally use ⑪...
