BendPak HDS-40 Service Manual

Hide thumbs Also See for HDS-40:

Installation and operation manual (64 pages)

Installation and operation manual (56 pages)

Installation and operation manual (18 pages)

page of 36

/ 36
Bookmarks

Quick Links

Download this manual

Service Manual

SERVICE PARTS & DIAGRAMS

BENDPAK

HDS-40

PRODUCT SKU

5175176

DRAWING Nº

5260607

Need help?

Do you have a question about the HDS-40 and is the answer not in the manual?

Questions and answers

Summary of Contents for BendPak HDS-40

Page 1 Bend Pak product. It provides comprehensive information on identifying serviceable parts and components and assists in troubleshooting problems and performing assembly /disassembly procedures. BendPak, Inc. Corporate Office Customer Service Desk / Warranty Parts Orders Domestic Sales & Service International Sales &...
Page 2 5260607 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY SEE COLORS & GRAPHICS FOR LABEL PLACEMENT REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:48 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 3: Front View
DRIVE THRU 4.026in 102.3mm FRONT VIEW 91.260in 8.150in 2318.0mm 69.528in 1645 LEMONWOOD DR. 207.0mm 61.378in SANTA PAULA, CA 93060 1766.0mm 1559.0mm TITLE: HDS-40 PRODUCTION 31.028in LIFT VER D (CE CERT) 788.1mm SIZE DWG. NO. 5260607 SCALE: 1:45 SHEET 2 OF 3...
Page 4 504.5mm LOWEST LOCK 9.528in 242.0mm LOWERED 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: HDS-40 PRODUCTION LIFT VER D (CE CERT) SIZE DWG. NO. 5260607 ALL DIMENSIONS SHOWN ARE WITH LOCK LADDER ADJUSTED ALL THE WAY UP SCALE: 1:40 SHEET 3 OF 3...
Page 5 5216170 HDS-40 CROSSTUBE ASSEMBLY, SMALL WINDOW 5215240 HDS-40 POWER SIDE RAMP ASSEMBLY 5601447 HDS-40 OFF SIDE RAMP WELDMENT 5215162 HDS-40 EXTENDED DRIVE UP RAMP ASSEMBLY 5601246 HDS-40 SAFETY LADDER WELDMENT 5535104 NUT M30 x 3.5 NL DETAIL A 5535212 NUT M30 x 3.5...
Page 6 5215240 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:35 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 7 10.394in 264.0mm PORTS MUST BE ON THIS SIDE 30.591in 777.0mm 265.236in 6737.0mm 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: HDS-40 POWER SIDE RAMP ASSEMBLY SIZE DWG. NO. 5215240 SCALE: 1:25 SHEET 2 OF 2...
Page 8 5216169 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245091 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 9 5216170 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245091 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 10 HDS-18E/27/40 PARTS BAG 5215096 PUSH BUTTON AIR ASSEMBLY 5620194 HDS-18E/27/40 TIRE STOP WELDMENT 5595558 HDS-40 CABLE ASSEMBLY Ø19 x 4102mm ST 5595559 HDS-40 CABLE ASSEMBLY Ø19 x 5836mm ST 5595564 HDS-40 CABLE ASSEMBLY Ø19 x 10452mm ST 5595565 HDS-40 CABLE ASSEMBLY Ø19 x 12167mm ST...
Page 11 5174600 NOTE: UNLESS OTHERWISE SPECIFIED. PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5250175 THE SOLE PROPERTY OF BENDPAK INC. ANY SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:50 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 12 5216139 PROPRIETARY AND CONFIDENTIAL SHOWN IN REPRESENTATIONAL FORM ONLY 5250168 5250195 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250169 5250278 (*)LENGTH FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 13 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS HDSO SERIES THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 14 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5215149 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 15 FOR REFERENCE ONLY DO NOT SCALE ITEM NO PART NUMBER DESCRIPTION QTY REV 5600266 HDS-40 EXTENDED DRIVE UP RAMP WELDMENT 1 5716089 HDS-40 APPROACH RAMP EDGE GUARD 5530464 BBSS M10 x 1.5 x 24mm DO NOT SCALE DRAWING NAME DATE...
Page 16 FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM UNLESS OTHERWISE SPECIFIED THE INFORMATION CONTAINED IN THIS DRAWING IS 5250079 THE SOLE PROPERTY OF BENDPAK INC. ANY (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 17 01174 4102 82.5 38.0 39.40 4020 ITEM NO PART NUMBER DESCRIPTION 5595093 CABLE, LIFTING, Ø19mm, HDS-40 SERIES 3903mm* 5746071 Ø19mm CABLE BUTTON 5746070 Ø19mm THREADED CABLE CONNECTOR 5535055 NUT M36 x 4 NL 5545032 WASHER M36 x 66 FLAT WHERE USED...
Page 18 01174 5836 82.5 38.0 39.4 5755 ITEM NO PART NUMBER DESCRIPTION 5595093 CABLE, LIFTING, Ø19mm, HDS-40 SERIES 5637mm* 5746071 Ø19mm CABLE BUTTON 5746070 Ø19mm THREADED CABLE CONNECTOR 5535055 NUT M36 x 4 NL 5545032 WASHER M36 x 66 FLAT DO NOT SCALE DRAWING...
Page 19 10452 82.5 38.0 39.4 10370 ITEM NO PART NUMBER DESCRIPTION QTY. 5595093 CABLE, LIFTING, Ø19mm, HDS-40 SERIES 10253mm* 5746071 Ø19mm CABLE BUTTON 5746070 Ø19mm THREADED CABLE CONNECTOR 5535055 NUT M36 x 4 NL 5545032 WASHER M36 x 66 FLAT DO NOT SCALE DRAWING...
Page 20 12167 38.0 82.5 39.4 12085 ITEM NO PART NUMBER DESCRIPTION QTY. 5595093 CABLE, LIFTING, Ø19mm, HDS-40 SERIES 11968mm* 5746071 Ø19mm CABLE BUTTON 5746070 Ø19mm THREADED CABLE CONNECTOR 5535055 NUT M36 x 4 NL 5545032 WASHER M36 x 66 FLAT DO NOT SCALE DRAWING...
Page 21 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT BENDPAK GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:30 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 22 5600266 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT YELLOW (RAL-1018) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 23 FOR REFERENCE ONLY DO NOT SCALE ITEM NO PART NUMBER DESCRIPTION QTY REV 5701063 HDS-40 OFF SIDE RAMP 5731019 HDS-40 OFF SIDE RAMP END PLATE 5755031 HDS-18/27/40 HINGE TUBE 5765020 HDS-18EA/27/40 ROLLING JACK TUBE WHERE USED 5735086 HDS-18E/27/40 ROLLING JACK PLATE...
Page 24 5601833 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 25 5601834 DIMENSIONS SHOWN ARE AFTER PAINTING PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 26 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS 5601833 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT REMOVE ALL WELD SPLATTER SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 27 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS 5601833 THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 28 HDS-40 SERIES CYLINDER MOUNTING BLOCK (R.H.) 5736155 HDS-40 SERIES CYLINDER MOUNTING BLOCK (L.H.) 5700012 HOSE RETAINER 5735251 HDS-40 SERIES CYLINDER STRAP 5731013 HDS-40 SERIES POWER SIDE RAMP END PLATE 5735074 HDS-18/27/40 SERIES CROSSTUBE SHAFT STOP 5755031 HDS-18/27/40 SERIES HINGE TUBE 5735349 CYLINDER ALIGNMENT KEY 5736536...
Page 29 MATERIAL: HR ASTM A36 OR Q235 GB/T 700 PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5601141 THE SOLE PROPERTY OF BENDPAK INC. ANY FLAME CUT PERMISSABLE REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 30 (216 to 279 mm), or between Color: Black and White Binding: Saddle Stitched Paper: 100 to 120 gsm (27 to 32 pound), uncoated 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 31 4 Post Lifts Product Decal Positioning DANGER VISUALLY CONFIRM THAT ALL PRIMARY SAFETY LOCKS ARE ENGAGED BEFORE ENTERING WORK AREA. Suspension components on this lift are intended to raise and lower lift; they are NOT load-holding devices. Do not go under an elevated lift until visual confirmation is made that the lift is engaged on its Safety Locks.
Page 32 Contact the participant for information pertaining to certified attachments, accessories, or configuration-modifying components. BendPak lifts are supplied with concrete fasteners meeting the criteria as prescribed by ASTM E488/ E488M-18. Lift buyers are responsible for any special regional, structural, and/or seismic anchoring requirements specified by any other agencies and/or codes such as the Uniform Building Code (UBC) and/or International Building Code (IBC).
Page 33 Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate non-glare medium matte over-lami- nate (No gloss) for abrasion, chemical and ultra violet protection. Santa Paula, CA USA Santa Paula, CA USA www.bendpak.com www.bendpak.com MODEL NUMBER MODEL NUMBER DESCRIPTION DESCRIPTION...
Page 34: Does Not Print
4 Post Lifts Product Decal Positioning GRAY DOES NOT PRINT DIE-CUT LINE PN 5906044 DOES NOT PRINT American_Owned_50_Years_Logo.pdf: Trim: 4"W x 3"H Material: 4 Mil. Permanent White Adhesive Vinyl Ink: U.V. protected CMYK 4/C Process Finish: Matte Overlaminate (No Gloss) Print Process: Offset Lithography - 200 line-screen or 300 p.p.i.
Page 35 4 Post Lifts Product Decal Positioning M, E, C SEE NEXT PAGE **FOR ALI APPROVED Back of Post FOR LABEL (Top to Bottom) LIFTS ONLY PLACEMENT HEIGHT G, D, I, J or K, F Side of Post Front of Post (Front &...
Page 36 4 Post Lifts Product Decal Positioning Views of Powerside Post BACK OF SIDE OF FRONT OF POST POST POST CALIFORNIA PROPOSITION 65 WARNING WARNING! This product can expose you to chemicals including styrene and vinyl chloride which are on the list of over 900 chemicals identiﬁed by the State of California to cause cancer, birth defects or reproductive harm.
