Carrier WeatherMaker 50A020 Installation Instructions Manual

Single package electric cooling rooftop units with electric heat option, comfortlink controls and puron refrigerant (r-410a)
Hide thumbs Also See for WeatherMaker 50A020:
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . 1
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Acoustic Insulation . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 1 - Provide Unit Support . . . . . . . . . . . . . . . . . 3
Step 2 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . 3
Step 3 - Field Fabricate Ductwork . . . . . . . . . . . . . . 3
Step 4 - Make Unit Duct Connections . . . . . . . . . . . 3
Step 5 - Trap Condensate Drain . . . . . . . . . . . . . . 22
Damper Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components. Only
trained and qualified service personnel should install, repair, or
service air-conditioning equipment.
Untrained personnel can perform basic maintenance functions of
cleaning coils and filters and replacing filters. All other operations
should be performed by trained service personnel. When working
on air-conditioning equipment, observe precautions in the
literature, tags and labels attached to the unit, and other safety
precautions that may apply.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53500271-01
Single Package Electric Cooling Rooftop Units
with Electric Heat Option, ComfortLink Controls
Installation Instructions
Page
Printed in U.S.A.
Form 50A-18SI
and Puron
®
Refrigerant (R-410A)
Follow all safety codes. Wear safety glasses and work gloves. Use
quenching cloth for unbrazing operations. Have fire extinguisher
available for all brazing operations.
It is important to recognize safety information. This is the safety-
alert symbol
. When you see this symbol on the unit and in
instructions or manuals, be alert to the potential for personal
injury.
Understand the signal words DANGER, WARNING, CAUTION,
and NOTE. These words are used with the safety-alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices, which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability,
or operation.
WARNING
Before performing service or maintenance operations on unit,
turn off main power switch to unit. Electrical shock could
cause personal injury.
WARNING
1.
Improper installation, adjustment, alteration, service, or
maintenance can cause property damage, personal injury,
or loss of life. Refer to the User's Information Manual
provided with this unit for more details.
2.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING
DO NOT USE TORCH to remove any component. System
contains oil and refrigerant under pressure.
To remove a component, wear protective gloves and goggles
and proceed as follows:
a. Shut off electrical power to unit.
b. Recover refrigerant to relieve all pressure from system
using both high-pressure and low pressure ports.
c. Traces of vapor should be displaced with nitrogen and
the work area should be well ventilated. Refrigerant in
contact with an open flame produces toxic gases.
d. Cut component connection tubing with tubing cutter and
remove component from unit. Use a pan to catch any oil
that may come out of the lines and as a gage for how
much oil to add to the system.
e. Carefully un-sweat remaining tubing stubs when neces-
sary. Oil can ignite when exposed to torch flame.
Failure to follow these procedures may result in personal inju-
ry or death.
Pg 1
WeatherMaker
50A020-060
11-21
Replaces: 50A-17SI
®
