INSTRUCTION MANUAL
EP
1/10 SCALE ONROAD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Natrix 750-E and is the answer not in the manual?

Questions and answers

Related Manuals for Serpent Natrix 750-E

Summary of Contents for Serpent Natrix 750-E

  • Page 1 INSTRUCTION MANUAL 1/10 SCALE ONROAD...

  • Page 2: Table Of Contents

    READ THIS FIRST! The Serpent Natrix 750-E is a state of the art electricpowerd 1/10 scale onroad racing car. The assembly manual - This is a highly technical hobby product, intended to be used in a safe racing environment. This car will guide youthrough all the steps to complete the car, so you can hit the track with a good base-set-up is capable of speeds in excess of 80 km/h or 50mph.
  • Page 3 HOW TO USE THE MANUAL LINES DESCRIPTION ICONS DESCRIPTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in Each step contains a variety of symbols described below. which the parts should be assembled. The lines are described below. Step number;...

  • Page 4: Front Diff Assembly

    FRONT DIFF ASSEMBLY STEP 1 STEP 2 FRONT DIFF BAG Note the correct pin location. Add just enough oil to cover the large gear before assembling the small satellite gears and cross pins. For the correct cst value please check the default setupsheet.
  • Page 5 STEP 3 STEP 4 STEP 5 1- Allow the excess of oil to escape Mount the diff top-case on the lower case, make sure to follow below Detail View, and through the escape hole. tighten the screws. Fill the differential with 2- Close the hole with the 3x3 i l i s setscrew.

  • Page 6: Rear Assembly 1

    REAR ASSEMBLY 1 STEP 6 STEP 7 BAG 1 M2.5x4 M3x6 REAR ROLL CENTER INSERTS CHART M3x6 M3x6 REAR REAR REAR FRONT M3x6 M2.5x4 M3x6 M3x6...
  • Page 7 STEP 8 REAR DEFAULT WHEELBASE SHIMS M3x8 M4x4 REAR ANTIROLL BAR ROD LENGTH M4x4 36 mm M3x8 M4x4...
  • Page 8 STEP STEP 10 BAG 2 2x12 2x12 M3x6 2x12 M3x6...
  • Page 9 P 11 STEP 12 M3x6 REAR BELT TENSION Use the central slot as M3x8 starting position. 12x18x4 12x18x4 M3x6 M3x6 M3x8 M3x6 M3x6 12x18x4...
  • Page 10 STEP 13 BAG 3 M5X4 2.5x12 6x12x4 6x12x4 2.5x12 M5x4 6x12x4...
  • Page 11 STEP STEP 15.1 5X8X2.5 15.2 M3x6 M3x3 M3x3 M3x3 M3x6 M3x3 M3x6 5x8x2.5...

  • Page 12: Motor Mount Assembly

    MOTOR MOUNT ASSEMBLY STEP BAG 4 OPT 804505 MOTOR PLATE 1/8 S750E M3x8 M3x16 M3x8 M3x16 M3x6 M3x6 M3x6 M3x8 M3x8 M3x6 M3x8 M3x6 M3x8 M3x16...
  • Page 13 STEP 17 OPT 804512 SPUR GEAR 36T STEEL M1 804513 SPUR GEAR 38T STEEL M1 804515 SPUR GEAR 42T STEEL M1 804516 SPUR GEAR 44T STEEL M1 2.5x10 904178 SPUR GEAR 56T 988E 904179 SPUR GEAR 57T 988E 904180 SPUR GEAR 58T 988E M4x4 M3x5 M3x5...

  • Page 14: Rear Assembly 2

    REAR ASSEMBLY 2 STEP 18 BAG 5 18.1 18.3 REAR TRACK WIDTH 2.3 mm 18.2 1.3 mm 2x10 10x15x4 10x15x4 M3x3 2x10 2x10 M3x3 10x15x4...
  • Page 15 STEP 19 STEP 20 21.1 REAR CAMBERLINK LENGTH 6.8 mm M3x8 REAR CAMBERLINK M3x6 DEFAULT POSITION M3x6 21.2 M3x16 M3x8 M3x6 M3x16...

  • Page 16: Front Assembly

    FRONT ASSEMBLY STEP STEP 22 BAG 6 Note that the front suspension brackets are not symetric. Check Note that the front bearing blocks are not symetric below the correct orientation RIGHT LEFT M3x6 M3x12 M3x6 M3x6 M3x12 M3x6...
  • Page 17 P 23 STEP 24 FRONT DEFAULT WHEELBASE SHIMS M2.5x4 M3x4 M3x12 M3x4 M3x12 M3x4 M2.5x4 M3x12...
  • Page 18 STEP 25 STEP 26 BAG 7 26.1 2.5x12 6x10x3 12x18x4 Flanged 6x10x3 12x18x4 M4x6 Flanged 2.5x12 FRONT BELT TENSION M3x8 Use the central slot as 26.2 starting position. M3x10 M3x6 2.5x12 M4x6 M3x6 M3x10 M3x8 6X10X3 Flanged 12x18x4...
  • Page 19 STEP 27 STEP 28 5x8x2.5 Flanged 28.1 FRONT ANTIROLL BAR ROD LENGTH 27.5 mm M4x10 28.2 M3x3 M3x3 M3x3 M3x3 M4x10 5X8X2.5 Flanged...
  • Page 20 STEP 29 STEP 30 BAG 8 M3x4 M3x8 3x6x0.5 3x6x0.5 3x6x1 3x6x1 FRONT CASTER DEFAULT SPACERS FRONT SUSPENSION INSERTS CHART 4mm 2mm OUTSIDE INSIDE RIGHT LEFT RIGHT LEFT RIGHT LEFT M3x4 M3x8 3x6x0.5 3x6x1...
  • Page 21 STEP 31 Nylock nut M3 31.1 31.2 3.2x7x0.5 10x15x4 2x10 M3x3 M3x10 10x15x4 2x10 STEERING BLOCK INSERTS CHART LEADING NEUTRAL TRAILING 46.3 ACKERMANN POSITION RIGHT LEFT M3x6 M3x5 2x10 M3x3 M3x10 Nylock Nut M3 M3x5 M3x6 3.2x7x0.5 10x15x4...
  • Page 22 STEP 32 FRONT CAMBER AND TRACK WIDTH 2.6 mm 3.4 mm...

  • Page 23: Steering Assembly

    STEERING ASSEMBLY STEP 33 BAG 9 33.1 33.2 M3x6 Preload the servo-saver- spring 1mm. 4x7x2.5 3x6x0.5 1 mm M3x6 SERVOSAVER ACKERMANN INSERTS 4x7x2.5 FORWARD NARROW REARWARD NARROW FORWARD WIDE REARWARD WIDE M3x6 3x5x1 M3x6 M3x6 3x6x0.5 4X7X2.5...
  • Page 24 STEP 34 34.2 34.1 STEERING TRACKROD LENGTH 27.2 mm...

  • Page 25: Center Assembly

    CENTER ASSEMBLY STEP 35 35.1 35.2 3x6x6 M3x10 M3x6 M3x6 M3x8 M3x6 M3x6 M3x6 M3x8 M3x6 M3x6 M3x8 M3x10 3x6x6 M3x6 M3x6...
  • Page 26 STEP 36 BAG 10 36.1 36.2 The amount of servo spacers depants on the brand and type of the servo. STEERING TRACKROD LENGTH M3x5 M3x8 M3x6 M3x8 M3x5 M3x6 M3x8...
  • Page 27 STEP 37 STEP 38 M3x6 M3x6 M3x8 M3x6 M3x6 M3x10 5x8x2.5 Flanged 5x8x2.5 M3x14 M3x6 M3x14 M3x6 M3x8 M3x10...

  • Page 28: Bumper/Shocktower Assembly

    BUMPER/SHOCKTOWER ASSEMBLY STEP 39 STEP 40 BAG 11 M3x6 M3x6 Nylock nut M3 M3x6 M3x8 M3x10 M3x8 M3x10 M3x8 M3x8 M3x6 Nylock Nut M3 M3x6 M3x8 M3x10...
  • Page 29 STEP 41 STEP 42 M2x10 M2x10 M3x10 M3x8 M2x10 2x10 2x10 M3x8 M3x10 Body clip mid...

  • Page 30: Shock Assembly

    SHOCK ASSEMBLY STEP 43 STEP 44 SHOCK BAG 43.1 44.1 R2.3 Note the correct orientation of the For the correct piston holes please Use some silicone oil shock spacers . check the default setupsheet. during the assembly. R2.3 43.2 44.2 Use some silicone oil during the assembly.
  • Page 31 STEP 45 STEP 46 45.1 45.3 SHOCKS LENGTH: Assemble the spring and spring- cup (align correctly) to complete Measure the shock Push the shoch top and 1-Bleed: push length fully extended. the shock. the membrane into the shockrod all the way shock cap.
  • Page 32 STEP 47 STEP 48 M3x6 M3x6 M3x6 M3x6...
  • Page 33 FINAL ASSEMBLY STEP 49 BAG 12 OPT 804505 MOTOR PLATE 1/8 S750E M4x4 M3x10 M3x10 M3x10 M4x4 M3x10 M4x4 M3x10...
  • Page 34 STEP 50 M3x6 M3x6 M3x6...
  • Page 35 OPT 804521 WHEELIEBAR SET S750E M3x6 M3x20 M3x8 6x8x0.3 6x10x3 Flanged 3x6x3 3x6x2 3x6x3 M3x6 6x10x3 Nylock Flanged nut M3 6x8x0.3 Nylock Nut M3 M3x6 M3x8 M3x20 3x6x2 3x6x3 6x8x0.3 6X10X3 Flanged...
  • Page 36 OPT 804521 WHEELIEBAR SET S750E M3x8 M3x5 M3x5 M3x5 M3x5 M3x8 M3x5...
  • Page 37 OPT 804353 RIM COVER FR 748 (2) 804354 RIM COVER RR 748 (2) M2.5x5 M2.5x5 M2.5x5...
  • Page 38 STEP 51 Nylock nut M4 Nylock nut M4 Nut M4 Flanged...
  • Page 39 STEP Body clip mid...

  • Page 40: Exploded Views

    EXPLODED VIEWS INDEX DEFFERENTIAL EXPLODED VIEW SHOCK EXPLODED VIEW REAR EXPLODED VIEW FRONT EXPLODED VIEW CENTER EXPLODED VIEW BUMPER SHOCKTOWER EXPLODED VIEW FINAL EXPLODED VIEW...
  • Page 41 DIFFERENTIAL EXPLODED VIEW 804390 Diff set fr 748 V2 804394 804392 110445 500290 804395 804395 804406 110222 804392 500290 110131 110116 110222 804395 804394 110445 804395 804391 Diff set rr 748 V2 804440 Diff set rr 750 arrowspace magnesium 804450 Oneway diff fr S7XX...
  • Page 42 SHOCK EXPLODED VIEW 160141 160135 Shock onroad set big bore (2) 160129 160139 160136 160146 160140 160147 opt 110300 160138 6442 909405 110300 160137 160142 opt 160144 160130 160299 opt 160129 160302 opt 160303 160142 Shock onroad big bore piston 1 hole (4) 160151 Shock onroad big bore piston 4 hole LF (2) 160302 Spring orange 160143 Shock onroad big bore piston 2 hole (4)
  • Page 43 REAR EXPLODED VIEW 110108 110124 1652 804411 804412 110124 1652 110108 804500 110215 804501 804152 110504 804500 804152 110116 110504 110132 802339 110215 804415 804410 903231 903231 1650 902138 903187 808214 804116 110108 1647 804282 110118 804425 804414 804341 opt 804146 110114 110303...
  • Page 44 FRONT EXPLODED VIEW 804396 804398 opt 110124 110303 804423 804268 1320 804121 804396 1320 110109 804398 opt 110207 110120 804423 804424 110207 804104 110303 804118 110504 804153 804390 110124 110504 804432 804153 110115 804429 804430 804320 804433 110415 808214 110115 110449 903508 808214...
  • Page 45 CENTER EXPLODED VIEW 110109 804332 110124 110108 804162 804193 opt 804509 110122 1311 110124 804431 110111 411206 401134 110129 401833 804337 1312 401653 804507 110108 902138 901255 401783 110128 804324 901255 411253 804123 110415 401782 411206 110108 411253 802260 804506 804324 804158 411253...
  • Page 46 BUMPER SHOCKTOWER EXPLODED VIEW 802211 804293 opt 110108 802361 804295 804293 opt 110208 802361 110208 802211 110104 1667 160135 804295 110208 110402 1650 1667 804413 110109 110108 804416 110109 110124 804428 110122 1650 110112 160135 110108 110104 804293 Body support washers med + high (5+5) 804417 Diffusor S750 804521 Wheeliebar set S750E...
  • Page 47 FINAL EXPLODED VIEW 905122 904136 110452 110122 110122 110118 110129 110452 804517 Pinion 22T steel M1,3 804518 Pinion 23T steel M1,3 804519 Pinion 24T steel M1,3 804520 Pinion 25T steel M1,3...

  • Page 48: Team Serpent Network

    TEAM SERPENT NETWORK SPARE PARTS www.serpent.com/804013/spares/ OPTIONALS PARTS www.serpent.com/804013/Optionals/ SERPENT TOOLS www.serpent.com/product/Tools/ SERPENT MERCHANDISING www.serpent.com/product/Merchandising/...
  • Page 49 SERPENT WEBSITE AND BLOG www.serpent.com www.teamserpent.com www.dragon-rc.com SERPENT PROMO PAGES http://promo.serpent.com SERPENT FACEBOOK GROUPS http://promo.serpent.com/indexfb.htm SERPENT ADVANCED MANUALS http://promo.serpent.com/sam/ SERPENT SOCIAL MEDIA www.facebook.com/teamserpentrc www.youtube.com/user/SerpentMRC www.twitter.com/SerpentMRC www.plus.google.com/+SerpentModelcars/posts www.weibo.com/teamserpent...
  • Page 50 INSTRUCTION MANUAL 1/10 SCALE ONROAD #62941-1 Manual S750E...
