INSTRUCTION MANUAL
high-frequency level sensor
RFLS–28
Read the instructions published in this manual carefully before using the level meter for the first time.
Keep the manual in a safe place. The manufacturer reserves the right to implement changes without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFLS-28 1B Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dinel RFLS-28 1B Series

Summary of Contents for Dinel RFLS-28 1B Series

  • Page 1 INSTRUCTION MANUAL high-frequency level sensor RFLS–28 Read the instructions published in this manual carefully before using the level meter for the first time. Keep the manual in a safe place. The manufacturer reserves the right to implement changes without prior notice.

  • Page 3: Table Of Contents

    Contents Basic description ........................5 Sensor variants..........................5 Dimensional drawing .......................6 Installation and putting into operation ..................7 Electrical connection .........................8 5.1. Type RFLS-28N-_-_-P-_ electrical connection .............8 5.2. Type RFLS-28N-_-_-PD-_ electrical connection ............9 Settings elements ........................11 Status indication ........................12 Settings ............................ 13 8.1.
  • Page 4 The manufacturer is not responsible for improper use, loss of work caused by either direct or indirect damage, or for expenses incurred at the time of installation or during the period of use of the level sensors. RFLS–28 © Dinel, s.r.o.

  • Page 5: Basic Description

    FPM (Viton) O-ring, for sensing various from -20°C liquids, mashed and paste materials, also appropriate for oil, RFLS–28_–10V acids, bases, or asphalt and tar © Dinel, s.r.o. RFLS–28...

  • Page 6: Dimensional Drawing

    ** Typical switching point position for oil. see the accessories data sheet for the TN-28 extension tube RFLS-28_-1_-FG–_–_ clear cap of LED indication OK 24 O-ring 24x2 (B, E or V) Ø 14,6 Ø G ¾" Ø RFLS–28 © Dinel, s.r.o.

  • Page 7: Installation And Putting Into Operation

    LED indication 4 . Installation and putting into operation Please follow the next 3 steps: electrical connection • For , see chapter settings • For , see chapter Mechanical assembly • For , see chapter © Dinel, s.r.o. RFLS–28...

  • Page 8: Electrical Connection

    The power supply must be designed as a stabilised source of low safe voltage with galvanic isolation. If a switched power supply is used, its design must effectively suppress common mode interference. If the switched power supply is equipped with a PE protective terminal, it must be strictly earthed! RFLS–28 © Dinel, s.r.o.

  • Page 9: Type Rfls-28N-_-_-Pd-_ Electrical Connection

    No. 5 or 6 terminal No. 3 Q output of the sensor 0 V of the sensor terminal No. 1 or 2 Dinel programming wire P not connected BLK OFF Legend POWER ALARM SSU-1212-D black white blue brown © Dinel, s.r.o. RFLS–28...
  • Page 10 No. 5 or 6 terminal No. 3 Q output of the sensor 0 V of the sensor terminal No. 1 or 2 programming wire P terminal No. 7 SET CH SETTING Legend POWER ALARM black SSU-1212-AD white blue brown RFLS–28 © Dinel, s.r.o.

  • Page 11: Settings Elements

    Medium window settings – the user has the medium available and can perform flooding and • drainage on the sensor. Green LED Orange LED Sensitive spot for the magnetic Fig. 4: Positions of the settings and indication elements on the sensor © Dinel, s.r.o. RFLS–28...

  • Page 12: Status Indication

    RFLS–28 © Dinel, s.r.o.

  • Page 13: Settings

    For safety reasons, for scanning min. level, we recommend setting “O-mode” (sensor closes when submerged). A faulty sensor or wiring will take effect here in the same way as level emergency conditions by opening the sensor. Analogously, for the max. level, we recommend setting “C-mode” (sensor opens when submerged). © Dinel, s.r.o. RFLS–28...
  • Page 14 For safety reasons, for scanning min. level, we recommend setting “O-mode” (sensor closes when submerged). A faulty sensor or wiring will take effect here in the same way as level emergency conditions by opening the sensor. Analogously, for the max. level, we recommend setting “C-mode” (sensor opens when submerged). RFLS–28 © Dinel, s.r.o.

  • Page 15: Settings Using The Magnetic Pen - Rfls-28_-_-_-P/Pd

    Unless otherwise agreed, “O-mode” is set on all sensors straight from the factory. When using the “quick settings” function, the sensor does not eliminate the presence of deposits and foam on the electrode. The manufacturer recommends performing the basic settings as soon as possible. © Dinel, s.r.o. RFLS–28...
  • Page 16 A faulty sensor or wiring will take effect here in the same way as level emergency conditions by opening the sensor. Analogously, for the maximum level, it is recommended to set “C-mode” (the sensor opens when submerged). RFLS–28 © Dinel, s.r.o.
  • Page 17 The sensor is now set to O-mode (closes when submerged in the required medium). 3. Check the status of the indicators: • If the orange LED is illuminated and the green LED is flashing, the sensor is correctly set. © Dinel, s.r.o. RFLS–28...

  • Page 18: Settings Rfls-28_-_-_-Pd-_ Using The Ssu-1212-Ad Unit

    4. Check the status of the ALARM indicator. If the red LED is not flashing, the sensor is set cor- rectly. If it is flashing, the sensor is set incorrectly. Repeat the setting. 5. Switch the SET CH switch to the OFF position. RFLS–28 © Dinel, s.r.o.
  • Page 19 7. Check the status of the ALARM indicator. If the red LED is not flashing, the sensor is set cor- rectly. If it is flashing, the sensor is set incorrectly. Repeat the setting. 8. Switch the SET CH switch to the OFF position. © Dinel, s.r.o. RFLS–28...

  • Page 20: Settings "Medium Window" Mode - Media Resolution Function

    Orange LED not illuminated not illuminated Orange LED Orange LED Orange LED not illuminated not illuminated Fig. 6: “Medium window” mode – only detection of the required medium: (e.g.: only beer foam, beer and air are ignored) RFLS–28 © Dinel, s.r.o.
  • Page 21 4. Check the status of the ALARM indicator. If the red LED is not flashing, the sensor is set cor- rectly. If it is flashing, the sensor is set incorrectly. Repeat the setting. 5. Switch the SET CH switch to the OFF position. © Dinel, s.r.o. RFLS–28...

  • Page 22: Mechanical Mounting

    (see tab. materials used on p. 18). Chemical damage is not covered by the warranty. In the case of placement in the tank at the medium inlet point, installation out of reach of the filling flow is required RFLS–28 © Dinel, s.r.o.
  • Page 23 After setting the sensitivity to the given medium, the sensor reliably reacts to the presence or ab- sence of the medium level. Conversely, the sensor does not react to residues and deposits of viscous media on the measuring electrode. Fig. 8: Side installation of sensors in a tank filled with viscous medium © Dinel, s.r.o. RFLS–28...
  • Page 24 If the level drops, the sensor does not react to foam deposits on the electrode. Orange LED not illuminated Orange LED Fig. 11: Monitoring the level of a foamy medium RFLS–28 © Dinel, s.r.o.
  • Page 25 TN-28 extension tube (performance P, Z, CL) RFLS-28 back installation (performance RG, RN) RFLS-28 front installation (performance FG, FN) Fig. 12: Examples of the installation of the sensors in a tank © Dinel, s.r.o. RFLS–28...

  • Page 26: Sensor Variant With The "Pd" Output With Diagnostics

    LED starts flashing (in the case of incorrect setting) or illuminates (in the case of a failure). The emergency relay opens (terminal Nos. 11 and 12). When the setting is corrected or the failure is removed, the alarm is deactivated and the unit proceeds to standard operation. RFLS–28 © Dinel, s.r.o.

  • Page 27: Order Code

    TN-28 plastic cable gland for protective hose, cannot be used for TN-28 CABLE cable length in m AVAILABLE VARIANT RFLS-28 OF THE PRODUCT CODE The SSU-1212-D, SSU-1212-AD evaluation units are used to evaluate the diagnostic signal. © Dinel, s.r.o. RFLS–28...

  • Page 28: Accessories

    (NBR, EPDM, FPM/ in the Viton), (1 unit) price TN-28-P (flange) TN-28-Z (G1" at extra thread) extension tube cost TN-28-Cl (Tri- Clamp) at extra cable over 2 m cost protective hose (for at extra cable gland H) cost RFLS–28 © Dinel, s.r.o.

  • Page 29: Resilience Of O-Rings

    – Alkalis in general* ● ●● ● Ozone ●● ●● – * The type of O-ring for a specific type of medium must be discussed with the manufacturer. Legend: ●● suitable ● conditionally suitable – unsuitable © Dinel, s.r.o. RFLS–28...

  • Page 30: Safety, Protection, And Compatibility

    If a change of the sensor settings is necessary, the whole system must be temporarily switched • off and the process held in a safe condition using other means and measures. Fault indication is described in the following chapters Status indication or Status indication of • the sensor with diagnostic RFLS–28 © Dinel, s.r.o.

  • Page 31: Putting Out Of Operation Or Disposal

    Write as detailed a description of the fault as possible. Attach a detailed description of the ap- • plication and of the installation location and send everything together with the sensor to the Dinel s.r.o. company address. We would like to ask for your utmost cooperation in finding the root cause of the fault. Your •...

  • Page 32: Product Marking

    = 300 mA omax RFLS-28N-1E-FN-P-B t = -40 ... +80 °C Cable: 2m Ser. No.:______ Description: Symbol of the manufacturer: Dinel logo ® Internet address: www.dinel.cz Country of origin: Made in Czech Republic Level meter type: RFLS–28N–_–_–P-_ Dinel Cable length: Cable: _ _ m Serial number of the product: No.: _ _ _ _ _ - (from the left: production year, serial production number)

  • Page 33: Technical Parameters

    NPT 3/4 FN, RN Mechanical performance and area classification Sensor Device classification electrode type performance RFLS–28N All types Basic performance for use in non-explosive environments. Factory default switching mode O (closes when submerged) for sensing water sensitivity © Dinel, s.r.o. RFLS–28...
  • Page 34 -20 °C ... +105 °C -20 °C ... +80 °C 10 MPa temperature in – process connection place extension tube (see accessories datasheet) ta – ambient temperature (housing with electronics) ambient temperature – (housing with electronics) RFLS–28 © Dinel, s.r.o.

  • Page 35: Packing, Shipping, And Storage

    Store the device in its original packaging in dry areas protected from weather conditions, with humidity of up to 85 % without any effects of chemically active substances. The storage temperature range is -10 °C to +50 °C. © Dinel, s.r.o. RFLS–28...
  • Page 36 U Tescomy 249 760 01 Zlín Czech Republic Phone: +420 577 002 002 E-mail: sale@dinel.cz www.dinel.cz The manufacturer reserves the right to change the specifications and appearance of the product without prior notice Find the updated version at www.dinel.cz version: 08/2017 10/2022...
