Summary of Contents for Dinel CLS-23
- Page 1 INSTRUCTION MANUAL průmyslová elektronika Capacitive level sensors CLS – 23 Read carefully the instructions published in this manual before the first use of the level meter. Keep the manual at a safe place. The manufacturer reserves the right to implement changes without prior notice.
-
Page 2: Table Of Contents
CONTENT 1 . Basic description ........................4 2 . Variants of sensors ........................5 3 . Dimensional drawing ........................5 4 . Installation and putting into operation ..................6 5 . Mechanical mounting .........................6 6 . Electrical connection ........................9 7 . Settings ............................11 8 . Function and status indication (only with LED state indicator variant) ........12 9 . Order code ..........................13 10 . Correct specification examples ....................13 11 ... -
Page 3: Basic Description
There are next performances available: N – Normal for non-explosive areas, E – Extended temperature range for non-explosives areas, Xi – Explosion proof (intrinsically safe for explosive areas), NT – High temperature variant for non-explosives areas and XiT – High temperature variant for explosive areas. CLS-23 capacitive level sensors meet the safety integrity level requirements according to standard EN 61508 at level SIL 1. * Variant „E“ without LED state indicator © Dinel, s.r.o. -
Page 4: Variants Of Sensors
200 mm) also from the side. Electrode length from 50 mm to 1 m. 3 . Dimensional drawing CLS – 23_ – 10 CLS – 23_– 11(12) CLS – 23_ –20 CLS – 23_ –21 LED * Thread PP (var.:11) FEP (var.:12) Types of threads: G 3/8'' M18x1,5 M20x1,5 1/2–14 NPT CLS–23 © Dinel, s.r.o. -
Page 5: Installation And Putting Into Operation
(armouring). In the case of the reading of an aggressive medium, we recommend that the producer be consulted If the sensors are fitted with protective caps at the ends of the electrodes, remove the caps before commissioning. © Dinel, s.r.o. CLS–23... - Page 6 >5 distance of the inner walls from the >5 electrode at 5 mm. In some cases (sticky liquids, low permittivity liquids) it is better to mount the sensor into a pipe bend. Be careful of possible formation Fig. 3: Mounting in the pipe of air pockets. CLS–23 © Dinel, s.r.o.
- Page 7 LONG FITTING TUBES IN SIDE FOR TYPE: All variants WALL MOUNTING max. The installation of the sensor near the inlet, in the narrow neck or using an unsuitable welding >5 flange may cause the incorrect sensor function. min. Suitable welding flanges can be found in the Dinel assortment, types ON, NN – see Accessories. WRONG CORRECT >5 WRONG CORRECT CORRECT WRONG Fig.
-
Page 8: Electrical Connection
At sensors with the length of electrodes greater than 300 mm it is necessary to use an auxiliary ≥ probe (e.g. conductive probe) when installing from above on non-conductive containers for the maximum detection reliability. The auxiliary electrode is connected electrically with the housing of ≥ the sensor. The recommended length of the auxiliary electrode and the distance from the sensors ≥ are shown in the picture. ≥ Suitable types of auxiliary electrodes are for example: Dinel CNP–18F–30 probes with an M18 ≥ thread or a PDE–18 plate electrode (see Accessories). ≥ ≥ Auxiliary electrode PDE–18 > Electrical connection to the sensor housing >... - Page 9 In the event of strong ambient electromagnetic interference, paralleling of conductors with power distribution, or for distribution to distances over 30 m, we recommend using a shielded cable and grounding the shielding on the side of the power source. © Dinel, s.r.o. CLS–23...
-
Page 10: Settings
/ closed status of the sensor. FACTORY DEFAULT SETTINGS: Sensors CLS–23_–10; –20; –30 have factory default settings for detecting mineral oils, CLS – 23_– 11; –12; –21 for detecting drinking water. Switching is set to mode "O" (the sensor will close when submerged). CLS–23 © Dinel, s.r.o. -
Page 11: Function And Status Indication (Only With Led State Indicator Variant)
This period is sufficiently short to avoid unwanted switching of relay contacts. For binary inputs, we recommend to set the filter so as not to respond to pulses shorter than 3 ms. Units Dinel NSSU, NDSU a NLCU with transistor switch („T“) detects and transmitts these pulses to the output. -
Page 12: Order Code
320 mm. CLS–23Xi–11–C–R–NPT (N) performance for non-explosive areas; (11) insulated (coated) short bar (PP) electrode 30 mm; (C) electrically connection with connector; (R) NAMUR output type; (NPT) process connection with sealing thread 1/2 – 14 NPT. CLS–23 © Dinel, s.r.o. -
Page 13: Accessories
Explosion proof CLS–23Xi and XiT is provided by conformity with standards EN 60079- 0:2013+A11:2014, EN 60079-0:2012. Explosion proof CLS–23Xi and XiT is verified FTZÚ – AO 210 Ostrava – Radvanice: FTZÚ 12 ATEX 0106X. A declaration of conformity was issued for this device in the wording of Act No. 90/2016 Coll., as amended. Supplied electrical equipment matches the requirements of valid European directives for safety and electromagnetic compatibility. Special conditions for safe use of variant CLS–23Xi (XiT) If the apparatus is used as device of Group II and with using of an approved power supply device, which output parameters comply with required input parameters, it is necessary to have an galvanic separation or in case of apparatus without galvanic separation (Zener barriers) it is necessary to provide equipotential equalizing between sensor and barrier earthing point. Design CLS–23Xi-11 (12, 20, 21) can be used in zone 0. Other design DLS–23Xi can be used in zone 0 only electrode part and head with electronics can be used only in zone 1. Ambient temperature: Tamb = - 20°C ... +75°C Temperature of measured medium according to design variant: Xi type 10, 12: (- 25°C to + 105°C) Xi type 11: (- 10°C to + 105°C) Xi type 20, 21, 30, XiT: (- 30°C to + 150°C) Maximum temperature of electrodes is equal to temperature of measured medium. © Dinel, s.r.o. CLS–23... -
Page 14: Functional Safety
13 . Functional safety The CLS-23 capacitive level sensors meet the safety integrity level requirements according to stan- dard EN 61508. The sensors are intended for level height detection applications of liquids with increased safety demands in modes: • Overfill protection • Dry run protection In both modes, the sensors meet the requirements for functional safety at level SIL 1. The sensor electronics have 1oo1 architecture (single-channel without diagnostics). It is recommended to perform a function test of the sensor's safety function 1 per year. -
Page 15: Putting Out Of Operation Or Disposal
Carefully read the product manual chapter "Installation instructions" and "Electrical connection" and perform the described steps in reverse sequence. Disposal: Capacitative limit sensors CLS-23 are made from materials that can be recycled by specialised companies. Mark the device as waste and dispose of it according to the respective government directive for handling electronic waste. Materials: see "Technical specifications". 16 . General conditions and warranty Dinel, s.r.o. guarantees for the period of three (3) years that the product has the characteristics as ... -
Page 16: Marking Of Labels
FTZÚ 12 ATEX 0106X L = 10uH t = -20 ... +75 °C Limit parameters: Ui = 12 V =, Ii = 15 mA; Pi = 45 mW; Ci = 15 nF; Li = 10 μH Ambient temperature range: ta= -20 ... +75 °C Štítek pro CLS-23XiT-11(12, 20, 21)- Number of certificate of intrinsic safety: FTZÚ 12 ATEX 0106X Compliance mark: Protection class: IP68, Electro-waste take-back system mark: Size of labels 81 x 9 mm, the size shown does not correspond to reality. CLS–23 © Dinel, s.r.o. -
Page 17: Technical Specifications
Current supply (state OFF / ON) – NAMUR ≤ 1 mA / ≥ 2,2 mA Ui = 12 V DC; Ii = 15 mA; Pi = 45 mW; Ci = 15 nF; Max. internal values Li = 10 µH Coupling capacity / Electric strength 44 nF / 250 V AC Typical C < 150 pF/m Reference value of LC parameters of used cable Typical L < 0,8 µH /m Process connection Output type Type Size Marking Output Variants Metric thread M18 x 1,5 S („S“) N, E, NT Metric thread M20 x 1,5 PNP („P“) N, E, NT Pipe thread (BSP) G 3/8'' G3/8 NAMUR („R“) Xi, XiT Pipe thread (BSP) G 1/2'' G1/2 Sealing thread 1/2–14 © Dinel, s.r.o. CLS–23... - Page 18 -20°C ... +75°C 8 MPa 6 MPa 5 MPa – – CLS–23XiT–30 -30°C ... +150°C -30°C ... +150°C -20°C ... +75°C 8 MPa 6 MPa 5 MPa 4 MPa 3 MPa * Valid for top mounting (in vertical position) CLS–23 © Dinel, s.r.o.
- Page 19 4 MPa 3 MPa * Valid for top mounting (in vertical position) ta – Ambient temperature range (on housing) tp – Temp. in process connection place tm – Medium operating temp) Variants: Variants: N; E; Xi; NT; XiT; © Dinel, s.r.o. CLS–23...
-
Page 20: Packing, Shipping And Storage
Sensor variants CLS–23_–20, 21 and 30 with the electrodes longer than 100 mm are fitted with protective caps at the ends of the electrodes to prevent damage of the electrodes, box rupture or injury of handling persons. Before commissioning, remove the caps. CLS–23 © Dinel, s.r.o. - Page 21 Dinel, s.r.o. U Tescomy 249 760 01 Zlín Czech Republic Phone: +420 577 002 002 Fax: +420 577 002 007 E-mail: sale@dinel.cz www.dinel.cz Find the updated version at www.dinel.cz 11/2018 version: 08/2017...
