Kyocera KM-1620 Error Code List

Kyocera KM-1620/ KM-2020 Error Code List
Self-diagnosis
(1) Self diagnostic codes
Code
C0100
(A0100*)
C0110
(A0110*)
C0150
(A0150*)
C016
(A016*)
C0170
C0180
C0210
(A0210*)
C0410
(A0410*)
"A" is displayed on the operation panel.
Downloaded from www.coronatechnical.com
Contents
Backup memory read/write problem
(main PCB)
• Read and write data does not match.
Backup memory data problem (main
PCB)
• Data in the specified area of the
backup memory does not match the
specified values.
Backup memory read/write problem
(engine PCB)
• Read and write data does not match.
Backup memory data problem (en-
gine PCB)
• Data in the specified area of the
backup memory does not match the
specified values.
Accounting count problem
• When the power is turned on, the to-
tal count and the scan count are ab-
normal both on the main PCB and the
engine PCB.
Machine number mismatch
• When the power is turned on, the ma-
chine number does not match be-
tween the main PCB and the engine
PCB.
Communication problem between
the main PCB and engine board PCB
• When the power is turned on, the ma-
chine does not detect the low level of
SBSY and the high level of SDIR for
three seconds.
Optional DP communication problem
• Communication fails five times suc-
cessively.
manuals search
Remarks
Causes Check procedures/corrective measures
Defective backup Replace the main PCB and check for cor-
RAM or main rect operation.
PCB.
Problem with the Turn safety switch off and back on and run
backup memory maintenance item U020 to set the contents
data. of the backup memory data again.
Defective backup If the C011 is displayed after re-setting the
RAM. backup memory contents, replace the
backup RAM or main PCB.
Defective backup Replace the engine PCB and check for
RAM or engine correct operation.
PCB.
Problem with the Turn safety switch off and back on and run
backup memory maintenance item U020 to set the contents
data. of the backup memory data again.
Defective backup If the C016 is displayed after re-setting the
RAM. backup memory contents, replace the
backup RAM or engine PCB.
Defective main Replace the main PCB or engine PCB and
PCB or engine check for correct operation.
PCB.
Correct EEPROM Install the correct EEPROM. If it does not
is not installed. solve the problem, contact the Service Ad-
ministrative Division.
Data damage of Contact the Service Administrative Divi-
EEPROM. sion.
Poor contact in Check the connection of connectors YC6
the connector ter- on the main PCB and YC1 on the engine
minals. PCB, and the continuity across the connec-
tor terminals. Repair or replace if neces-
sary.
Defective main Replace the main PCB or engine PCB and
PCB or engine check for correct operation.
PCB.
DP installed incor- Check the installation state of the DP and
rectly. adjust it if it is not properly installed.
Defective main Replace the main PCB or DP driver PCB
PCB or DP driver and check for correct operation.
PCB.
