Summary of Contents for Caple CM106
- Page 4 Space for ventilation Minimum cabinet aperture 560mm Fasten the "Bottom Spacer" to the MWO fasten the "Rear Spacer" to the MWO base with two screws rear with two screws...
- Page 5 Fasten the 2 "Front Frame Clips" to the fasten the upper DUCT with 4 screws ensuring the left side of the oven with screws opening in the duct points to the rear of the MWO. Fasten the 2 "Front Frame Clips" to the right side of the oven with screws place the oven into cabinet...
- Page 6 fasten the oven into the cabinet with 4 screws place the oven in the middle of cabinet IMPORTANT:- ENSURE THE FRAME IS FITTED THE CORRECT WAY UP.THE WORD"TOP"IS MARKED ON THE BACK OF THE FRAME MOULDING Push the "Front Frame" onto the 4 "Front Frame Clips"...
- Page 7 Installation complete insert pry TO REMOVE FRAME Insert flat bladed screwdriver and pry the front frame from the fixing clips.
-
Page 10: Parts And Components List
CM104 - Caple Microwave Oven & Grill Parts and Components List Art. Name Count Art. Name Count door (with inlaids) h.v. fuse door window h.v. diode fuse socket h.v. capacitor capacitor holder wave filter fan shroud fan motor fan blade...
