NS VAS Stem Installation Instructions
Published –Nov. 2022 ZS230.v0 © Full Speed Ahead
Fig. A
Introduction
Congratulations on your Full Speed Ahead product. Please read these instructions and follow them for correct use. Failure to follow the warnings and instructions could result in damage to product not covered under
warranty, damage to bicycle; or cause an accident resulting in injury or death. Since specific tools and experience are necessary for proper installation, it is recommended that the product be installed by a qualified
bicycle technician. FSA & Vision assumes no responsibility for damages or injury related to improperly installed components.
Warranty
Full Speed Ahead (FSA) warrants all FSA and Vision products to be free from defects in materials or workmanship for a period of two years after original purchase unless otherwise stated in the full warranty policy. The
warranty is non-transferable and valid to the original purchaser of the product only. Any attempt to modify the product in any way such as drilling, grinding, and painting will void the warranty. For more information on
warranty policy and instructions for completing a warranty claim, check out the Full Warranty Policy found at our website:
NS VAS Stem elastomers and bushings are consumables and not covered by the FSA warranty.
Specification
Model Name / Item Number FSA NS VAS Stem / ST-OS-19
FSA road stems are compatible with industry standard steerer tube and handlebar diameters. To choose the correct FSA stem, first check the specific diameter of steerer tube and handlebar to be used.
Components
Follow the assembly order in the illustration:
NS VAS Ste
m Body x1
①
Fixing Bolts M5x18L x2
②
Handlebar (not included )
③
Handlebar Clamp x1
④
⑤ Socket Head bolts M6x20L x 1
Normal Gap
Available for ride.
Elastomer immediately.
Please Check
Fig.B
https://www.fullspeedahead.com/en/technology
⑥ Lock Washer x1
Elastomer x1
⑦
Face plate x2
⑧
Washer x4
⑨
⑩ Round Head bolts M6x20L x4
Advertisement
Related Manuals for FSA NS VAS
Summary of Contents for FSA NS VAS
- Page 1 Warranty Full Speed Ahead (FSA) warrants all FSA and Vision products to be free from defects in materials or workmanship for a period of two years after original purchase unless otherwise stated in the full warranty policy. The warranty is non-transferable and valid to the original purchaser of the product only. Any attempt to modify the product in any way such as drilling, grinding, and painting will void the warranty. For more information on warranty policy and instructions for completing a warranty claim, check out the Full Warranty Policy found at our website: https://www.fullspeedahead.com/en/technology...
- Page 2 Measure Fork Steerer tube and handlebar clamp area before installing stem. Use an accurate measuring device such as a caliper or micrometer. Installing stem onto an undersized steertube or handlebar can cause stem or bar to slip causing loss of control of bicycle; resulting in an accident, damage to bicycle, injury or death. Use FSA Dynamic Assembly Paste between stem, steerer tube, and handlebar to reduce chances of slippage.
