MultiTrode MultiSmart Integrator Manual page 11

P2 Pump efficiency,
MotorProt.Pump._2.EfficiencyYesterday
yesterday
P2 Power, KW IO.Unit._1.BottomBoard.Power._2.Power
P2 power factor IO.Unit._1.BottomBoard.Power._2.PowerFactor
P2 Energy, KWHr,
IO.Unit._1.BottomBoard.Power._2.EnergykWh
yesterday
Insulation Resistance of Motor Windings
P1 IRT IO.Unit._1.BottomBoard.Irt._1.Value
P2 IRT IO.Unit._1.BottomBoard.Irt._2.Value
Note 3:
The default Modbus tag list (as of v1.5.6) does not include scaled level. Level in % is tag: PumpControl.Well._1.CurrentLevel and Modbus Input Register 38.
To add via the LCD, go to Settings – More – Communications – Modbus – Modbus slave – Input Registers and press Add New. This allows you to choose the Point Number (or accept the default).
Navigate down to Tag and press Select.
You are now in the Tag Browser. Navigate through to Pump Control – Well – Well 1 – Scaled Level and press OK. This has now configured a new Modbus analog (input register) as Scaled Level.
Scaled level has 4 decimal places by default. Therefore, in order to fit this within a 16 bit register (which is all that Modbus supports), this value needs to be scaled. For current level, we scale this by
10,000 in order to display from 0-100%. For scaled level, you may want to have some decimal places (e.g., 0.00 – 10.00 ft: In this case, the scale factor should be 100).
Note 4:
The default Modbus tag list (as of v1.5.6) does not include pump efficiency.
To add via the LCD, go to Settings – More – Communications – Modbus – Modbus slave – Input Registers and press Add New. This allows you to choose the Point Number (or accept the default).
Navigate down to Tag and press Select.
You are now in the Tag Browser. Navigate through to Motor Protection – Pump – Pump 1 – Efficiency Yesterday and press OK. This has now configured a new Modbus analog (input register) as
pump efficiency. Use a similar process to add pump 2.
Page 11 of 20
Q-Pulse Id VM357
Lobley St SPS SP331 General (Electrical Manual (MPA) Multismart Manual Multitrode System Integrator Guide) General
Frozen
Counters See Note 4 Gals or litres / kWHr
138
Input
Analog
Register
Input 87
159
Input
Analog
Register
Input 88
160
Input To capture energy used yesterday (for daily analysis) use
Analog
Register IO.Unit._1.BottomBoard.Power._2.EnergyYesterdaykWh, which is DNP Frozen
Input 89
161 Counters 134 (no default Modbus equivalent)
Analog
Value in MOhms
Input 165
Analog
Value in MOhms
Input 166
Active 26/09/2013
MultiSmart Integrator Guide
MultiSmart_Integrator_Guide_R01.doc
Page 11 of 20
