Marvel 6OBAR-SS-F Datasheet

www.dexpress.com
This Data Sheet Includes Information On
Marvel
• Product Model Number (s):
Outdoor Refrigerator:
6OBAR
• Dimensions (Actual Size)
Depth not including door:
Height at full leg adjustment:
Height at 0" leg adjustment:
Height without legs installed:
Toe Kick height:
Recommended opening width:
Recommended opening height:
Recommended opening depth:
• Additional Information
• Electrical requirements: 120 volts, 3 amps running
max. 15 amp GFI protected circuit required.
• Locate a 3-prong grounded receptacle in one of three
locations: 1) On the wall in the adjacent cabinet
opening. 2) Flush on the back wall of the refrigerator
opening (add 1" to the overall depth of the unit to
accommodate the thickness of the plug). 3) Recessed
1" into the back wall of the refrigerator opening.
• Unit can be built-in under countertop with zero
clearance at top back and sides.
• Door is reversible in field.
• Does NOT Accept custom 1/4" door panel.
• Shipping weight: 130 pounds.
• U.L. Listed for outdoor application.
• 6OBAR: Stainless Steel.
• Special order options: Castors, 230V-50Hz
Compressor.
Subject to change without notice. This system is designed to
be updated daily if necessary. Dimension Express is not
responsible for use of superseded, voided, or outdated data
sheets. Because of the difficulty or impracticability of deter-
mining actual damages, liability of Dimension Express shall
not exceed $50.00.
Copyright © Dimension Express, 2000.
• NEVER reuse Data Sheets. Data Sheets are subject to change without
notice. Dimension Express is a FREE service bureau and is updated daily,
it makes far more sense to spend the time necessary to request new Data
Sheets for each project, as opposed to the problems, time, costs, and risks
associated with reusing old Data Sheets.
DIMENSION EXPRESS
•
•
Overall depth: 24 1/8"
22"
35"
34 1/4"
34"
Width: 23 7/8"
3"
24"
34 1/2"
24" min.
•
318
Fax on Demand (775) 833-3600
23 7/8"
Front View
35" max (not to scale)
34" min
24 1/8"

Side View

(not to scale)
35" max
34" min
• Call Dimension Express if you have any questions at (775) 833-3633 •
• Always refer to a current Code at a Glance or manufacturer directory •
• Data Sheet codes change on the first of odd numbered months at 12:01am •
3"
22"
BN • A318 • 31004 • 000308 • 6118 • 45179
