F e a t u r e s
F e a t u r e s
Processor The mainboard uses a micro PGA 478-pin socket that has the
following features:
•
Accommodates Intel/P4 Willamette/Northwood 478-pins
CPU
•
For L4IBMGL6 – Incorporates the 845GL and supports
400/533MHz front side bus (FSB) with memory speed of
266 MHz
•
For L4IGVM6 – Incorporates the 845GV and supports
533MHz front side bus (FSB) with memory speed of 333
MHz
Chipset Intel's innovative 845GL/845GV (GMCH) and 82801DB (ICH4)
chipsets are based on an innovative and scalable architecture
with proven reliability and performance. A few of the advanced
features of the chipsets are:
•
Host interface controller supports 400/533 MHz front side
(system) bus frequency
•
Supports system bus Dynamic Bus Inversion (DBI).
•
Supports 266/333 MHz DDR SDRAM devices
•
AGTL+ Host Bus with Integrated Termination supporting
32-Bits host addressing.
•
Supports AGP 2.0 including 1X/2X/4X AGP data transfers
and 2X/4X Fast Write Protocol
•
Supports 3D / 2D graphic
•
Supports up to 2 double-sided DIMM (4 device rows)
•
PCI Rev. 2.2, 3.3V (5V Tolerant), 33 MHz interface com-
pliant and PCI to System Memory Data Streaming up to
132 MB/sec
•
Upstream Hub Interface for access to the Intel GMCH.
•
2 Channel Ultra ATA/100 Bus Master IDE Controllers
•
Supports six USB 2.0 ports for serial transfers at
480Mbits/sec
Additional key features include support for an AC 97 link for audio
and modem, hardware monitoring, and ACPI/OnNow power man-
agement.
Memory The mainboard accommodates two unbuffered 2.5V 184 pin
slots with a total maximum capacity of 2 GB.
•
L4IBMGL6 supports DDR 266 SDRAM
•
L4IGVM6 supports DDR 333 SDRAM
AC' 97 Audio The AC' 97 Audio codec is compliant with the AC 97 2.2 speci-
Codec fication that meets the PC2001 requirements and supports
S/PDIF Out. It also has a built-in buffer and internal PLL. Fea-
tures include support for analog switch for rear-out (share), the
line-in jack (share), center/bass (share), and MIC jack to output
6 channels audio.
Expansion The mainboard comes with the following expansion options:
Options
•
Two 32-bit PCI slots
•
A Communications Network Riser (CNR) slot (AC97 inter-
face only)
•
Two IDE connectors which support four IDE channels and
a floppy disk drive interface
2
