L4IBMG2 / L4IBMGL2 V1.0b
Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without w ritten consent of the au-
thor.
Version 1.0b
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication
and to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi -
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.
i
Preface

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L4IBMG2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ECS L4IBMG2

  • Page 1 L4IBMG2 / L4IBMGL2 V1.0b Preface Copyright This publication, including all photographs, illustrations and software, is protected un- der international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without w ritten consent of the au- thor.
  • Page 2 L4IBMG2 / L4IBMGL2 V1.0b Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the follow - ing conditions: − This device may not cause harmful interference, and − This device must accept any interference received, including interference that may cause undesired operation.
  • Page 3: Table Of Contents

    L4IBMG2 / L4IBMGL2 V1.0b Preface 錯誤! 尚未定義書籤。 Features and Packing List Translations CHAPTER 1 Introducing the Mainboard Introduction......................1 Checklist.........................1 Standard Items ....................1 Features........................2 Choosing a Computer Case................3 Mainboard Components..................4 CHAPTER 2 Installing the Mainboard Safety Precautions....................6 Quick Guide......................6 Installing the Mainboard in a Case..............7 Checking Jumper Settings...................7...
  • Page 4 L4IBMG2 / L4IBMGL2 V1.0b Integrated Peripherals ..................36 Power Management Setup................39 PNP/PCI Configurations ................. 42 PC Health Status....................44 Frequency/Voltage Control................45 Load Fail-Safe Defaults Option ..............46 Load Optimized Defaults Option ..............46 Set Supervisor/User Password................. 46 Save & Exit Setup Option ................47 Exit Without Saving ..................
  • Page 5: Introducing The Mainboard

    Retention module • This user’s manual Notice to user: This manual is provided to accommodate the L4IBMG2 and L4IBMGL2 mainboards. To identify the type of mainboard you have, please refer below: • L4IBMG2 mainboard incorporates the Intel 845-G (GMCH) and Intel 82801DB chipsets.
  • Page 6: Features

    The mainboard comes with the following expansion options: Options • Three 32-bit PCI slots • One 4xAGP slot (support 1.5V only) for L4IBMG2 main- board only • Two IDE connectors which support four IDE channels and a floppy disk drive interface •...
  • Page 7: Choosing A Computer Case

    L4IBMG2 / L4IBMGL2 V1.0b fer rates of 33/66/100 MB/sec. Integrated I/O The mainboard has a full set of I/O ports and connectors: • Two PS/2 ports for mouse and keyboard • One serial port • One VGA port • One parallel port •...
  • Page 8: Mainboard Components

    L4IBMG2 / L4IBMGL2 V1.0b...
  • Page 9 L4IBMG2 / L4IBMGL2 V1.0b Table of Mainboard Components Label Component AGP1 Accelerated Graphics Port (present on L4IBMG2 mainboard only) ATX12V Power connector ATX1 Standard 20-pin ATX power connector AUDIO1 Front panel MIC/Speaker Out header Three volt realtime clock battery CDIN1...
  • Page 10: Installing The Mainboard

    L4IBMG2 / L4IBMGL2 V1.0b Installing the Mainboard Follow these safety precautions when installing the mainboard: • Wear a grounding strap attached to a grounded device to avoid damage from static electricity. • Discharge static electricity by touching the metal case of a safely grounded object before working on the mainboard.
  • Page 11: Installing The Mainboard In A Case

    L4IBMG2 / L4IBMGL2 V1.0b Refer to the following illustration and instructions for installing the mainboard in a case: This illustration shows an ex- 2. Secure the mainboard with ample of a mainboard being screws where appropriate. installed in a tower-type case:...
  • Page 12: Checking Jumper Settings

    L4IBMG2 / L4IBMGL2 V1.0b Checking Jumper Settings The following illustration shows the location of the mainboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Type Description Setting 3-pin Clear CMOS 1-2: Normal (default) 2-3: Clear CMOS 2-pin BIOS Flash Open: Flash (Default)
  • Page 13 L4IBMG2 / L4IBMGL2 V1.0b VID4~VID0 12-pin Core voltage See table for settings. VID4 ~ VID0 selector jumper JP1 – Enables you to clear the BIOS. Refer to the following in- structions: 1. Turn the system off. 2. Remove all ATX power connectors (including ATX1 and ATX12V).
  • Page 14 L4IBMG2 / L4IBMGL2 V1.0b VID4 VID3 VID2 VID1 VID0 VDAC 1.175 1.200 1.225 1.250 1.275 1.300 1.325 1.350 1.375 1.400 1.425 1.450 1.475 1.500 1.525 1.550 1.575 1.600 1.625 1.650 1.675 1.700 1.725 1.750 1.775 1.800 1.825 1.850...
  • Page 15: Connecting Case Components

    L4IBMG2 / L4IBMGL2 V1.0b After you have installed the mainboard into a case, you can begin connecting the mainboard components. Refer to the following: Connect the Pentium 4 processor auxiliary case power supply connector to ATX12V Connect the standard power supply connector...
  • Page 16 L4IBMG2 / L4IBMGL2 V1.0b ATX12V: ATX 12V Power Connector Signal Name +12V +12V Ground Ground CPUFAN1/PWRFAN1/CASFAN1: FAN Power Connectors Signal Name Function System Ground +12V Power +12V Sense Sensor SPEAKER1: Internal speaker Signal Name Signal Ground...
  • Page 17: Front Panel Connector

    L4IBMG2 / L4IBMGL2 V1.0b Front Panel Connector The front panel connector (PANEL1) provides a standard set of switch and LED connectors commonly found on ATX or micro-ATX cases. Refer to the table below for information: Signal Name Function HD_LED_P Hard disk LED pull up (330 ohm) to +5V...
  • Page 18: Installing Hardware

    L4IBMG2 / L4IBMGL2 V1.0b nizes another on/off signal. Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the mainboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the mainboard, you may cause serious damage to the mainboard or its components.
  • Page 19 L4IBMG2 / L4IBMGL2 V1.0b CPU Installation Procedure The following illustration shows CPU installation components: Note: The pin -1 corner is marked with an arrow Follow these instructions to insta ll the CPU: Install and secure the Retention Module on the mainboard.
  • Page 20 L4IBMG2 / L4IBMGL2 V1.0b Lower the CPU cooling fan onto the heatsink. Snap the four retention legs of Cooling Fan the cooling fan into place. Heatsink Retention Module Swing both lock levers on top of the cooling fan to their opposite sides to secure the cooling fan on top of the heatsink.
  • Page 21: Installing Memory Modules

    L4IBMG2 / L4IBMGL2 V1.0b Installing Memory Modules This mainboard accommodates two 184-pin 2.5V unbuffered Double Data Rate (DDR) SDRAM memory modules. You must install at least one module in any of the two slots. Each module can be installed with 64 MB to 512 MB of memory. Total capacity is 2GB.
  • Page 22: Installing A Hard Disk Drive/Cd-Rom

    L4IBMG2 / L4IBMGL2 V1.0b Installing a Hard Disk Drive/CD-ROM This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your mainboard has a primary and secondary IDE channel interface (IDE1 and IDE2).
  • Page 23: Installing A Floppy Diskette Drive

    L4IBMG2 / L4IBMGL2 V1.0b Installing a CD-ROM/DVD Drive Install the CD-ROM/DVD drive into the drive cage in your system case. Plug the IDE cable into IDE1 (A). If you have already installed an HDD, use the other connec- tor on the IDE cable.
  • Page 24: Installing Add-On Cards

    PCI slots are used to install expansion cards that have the 32-bit PCI Slots PCI interface. The L4IBMG2 mainboard comes with an Accelerated Graphics Port Pro slot that supports AGP cards for high performance, component level interconnect targeted at 3D graphical applications using a 4X 4xAGP Slot mode bus.
  • Page 25 L4IBMG2 / L4IBMGL2 V1.0b Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot.
  • Page 26: Connecting Optional Devices

    L4IBMG2 / L4IBMGL2 V1.0b Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: AUDIO1: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access.
  • Page 27 L4IBMG2 / L4IBMGL2 V1.0b COM2: Onboard serial port connector Connect a serial port extension bracket to this header to add a second serial port to your system. Signal Name Function DCDB Data Carrier Detect SINB Serial Input SOUTB UART B Serial Output...
  • Page 28 L4IBMG2 / L4IBMGL2 V1.0b USB2/USB3: Front panel USB ports The mainboard has two USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connectors USB2 and USB3 to connect the front-mounted ports to the mainboard.
  • Page 29 L4IBMG2 / L4IBMGL2 V1.0b Connecting I/O Devices The backplane of the mainboard has the following I/O ports: Parallel port (LPT1) Game port PS/2 port mouse ports PS/2 Serial port Microphone keyboard COM 1 port Line-in Line-out Use the upper PS/2 port to connect a PS/2 pointing PS/2 Mouse device.
  • Page 30: External Connector Color Coding

    L4IBMG2 / L4IBMGL2 V1.0b External Connector Color Coding Many connectors now use standard colors as shown in the table below. Connector Color Audio line-in Light blue Audio line-out Lime Digital monitor/flat panel White Microphone Pink MIDI/game Gold Parallel Burgundy PS/2-compatible keyboard...
  • Page 31: Using Bios

    Using BIOS The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the mainboard contains the ROM setup instructions for configuring the mainboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system's configuration status and provides you with options to set system parameters.
  • Page 32: Entering The Setup Utility

    L4IBMG2 / L4IBMGL2 V1.0b Entering the Setup Utility When you power on the system, BIOS enters the Power-On Self Test (POST) routines. POST is a series of built-in diagnostics performed by the BIOS. After the POST routines are completed, the following message appears:...
  • Page 33: Using Bios

    L4IBMG2 / L4IBMGL2 V1.0b If your mainboard has an item called Firmware Write Protect in Advanced BIOS features, disable it. (Firmware Write Protect prevents BIOS from being overwritten.) Create a bootable system disk. (Refer to Windows online help for info r- mation on creating a bootable system disk.)
  • Page 34: Standard Cmos Features

    L4IBMG2 / L4IBMGL2 V1.0b Standard CMOS Features This option displays basic information about your system. Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Item Help Date (mm:dd:yy) Tue, July 11 2001 Time (hh:mm:ss) 12 : 8 : 59 Menu Level...
  • Page 35 L4IBMG2 / L4IBMGL2 V1.0b IDE HDD Auto-Detection Press <Enter> while this item is highlighted to prompt the Setup Utility to automatically detect and configure an IDE device on the IDE channel. Note: If you are setting up a new hard disk drive that supports LBA mode, more than one line will appear in the parameter box.
  • Page 36: Advanced Bios Features

    L4IBMG2 / L4IBMGL2 V1.0b Advanced BIOS Features This option defines advanced information about your system. Phoenix – AwardBIOS CMOS Setup Utility Advanced BIOS Features Item Help CPU L1 & L2 Cache [Enabled ] Quick Power On Self Test [Enabled] Menu Level...
  • Page 37 L4IBMG2 / L4IBMGL2 V1.0b drive with 360K capacity. Boot Up NumLock Status (On) This item defines if the keyboard Num Lock key is active when your system is started. Gate A20 Option (Fast) This item defines how the system handles legacy software that was written for an earlier generation of processors.
  • Page 38: Advanced Chipset Features

    L4IBMG2 / L4IBMGL2 V1.0b Advanced Chipset Features These items define critical timing parameters of the mainboard. You should leave the items on this page at their default values unless you are very famil- iar with the technical specifications of your system hardware. If you change the values incorrectly, you may introduce fatal errors or recurring instability into your sys tem.
  • Page 39 L4IBMG2 / L4IBMGL2 V1.0b DRAM Data Integrity Mode (Non-ECC) Select Parity or ECC (error-correcting code), according to the type of installed DRAM. Memory Frequency For (Auto) This item sets the main memory frequency. When you use an external graph- ics card, you can adjust this to enable the best performance for your system.
  • Page 40: Integrated Peripherals

    L4IBMG2 / L4IBMGL2 V1.0b Integrated Peripherals These options display items that define the operation of peripheral compo- nents on the system's input/output ports. Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals Item Help On-Chip Primary PCI IDE [Enabled ] IDE Primary Master...
  • Page 41 L4IBMG2 / L4IBMGL2 V1.0b USB Keyboard Support (Disabled) Enable this item if you plan to use a keyboard connected through the USB port in a legacy operating system (such as DOS) that does not support Plug and Play. AC97 Audio (Auto) Enables and disables the onboard audio chip.
  • Page 42 L4IBMG2 / L4IBMGL2 V1.0b UART Mode Select (Normal) This field is available if the Onboard Serial Port 2 field is set to any option but Disabled. UART Mode Select enables you to select the infrared communica- tion protocol-Normal (default), IrDA, or ASKIR. IrDA is an infrared communication protocol with a maximum baud rate up to 115.2K bps.
  • Page 43: Power Management Setup

    L4IBMG2 / L4IBMGL2 V1.0b This item sets the I/O address fo r the game port. Midi Port Address (330) This item sets the I/O address for the Midi function. Midi Port IRQ (10) This item sets the interrupt request for the Midi function.
  • Page 44 L4IBMG2 / L4IBMGL2 V1.0b This mainboard supports ACPI (Advanced Configuration and Power man- agement Interface). Use this item to enable or disable the ACPI feature. Note: ACPI is a power management specification that makes hardware status information available to the operating system. ACPI enables a PC to turn its p eripherals on and off for improved power management.
  • Page 45 L4IBMG2 / L4IBMGL2 V1.0b The IDE hard drive will spin down if it is not accessed within a specified length of time. Options are from 1 Min to 15 Min and Disable. Soft-Off by PWR-BTTN (Instant-Off) Under ACPI (Advanced Configuration and Power management Interface) you can create a software power down.
  • Page 46: Pnp/Pci Configurations

    L4IBMG2 / L4IBMGL2 V1.0b When these items are enabled, the system will restart the power-saving tim e- out counters when any activity is detected on any of the drives or devices on the primary or secondary IDE channels. FDD, COM, LPT Port (Disabled)
  • Page 47 L4IBMG2 / L4IBMGL2 V1.0b If you cannot get a legacy ISA (Industry Standard Architecture) expansion card to work properly, you might be able to solve the problem by changing this item to Manual, and then opening up the IRQ Resources and Memory Re- sources submenus.
  • Page 48: Pc Health Status

    L4IBMG2 / L4IBMGL2 V1.0b PC Health Status On mainboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, critical temperatures, and fan speeds. Phoenix – AwardBIOS CMOS Setup Utility PC Health Status Item Help Shutdown Temperature [70°C/158°F]...
  • Page 49: Frequency/Voltage Control

    L4IBMG2 / L4IBMGL2 V1.0b Frequency/Voltage Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system.
  • Page 50: Load Fail-Safe Defaults Option

    L4IBMG2 / L4IBMGL2 V1.0b Load Fail-Safe Defaults Option This option opens a dialog box that lets you install fail-safe defaults for all ap- propriate items in the Setup Utility: Press <Y> and then <Enter> to install the defaults. Press <N> and then <En- ter>...
  • Page 51: Save & Exit Setup Option

    L4IBMG2 / L4IBMGL2 V1.0b Save & Exit Setup Option Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the...
  • Page 52: Using The Mainboard Software

    Using the Mainboard Software The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bun- dled products. Below you can find a brief description of each software program, and the location for your mainboard version.
  • Page 53: Running Setup

    L4IBMG2 / L4IBMGL2 V1.0b Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support CD.
  • Page 54 L4IBMG2 / L4IBMGL2 V1.0b Note: The following screens are examples only. The screens and driver lists will be different according to the mainboard you are installing. The mainboard identification is located in the upper left-hand corner. Click Next. The following screen appears: Check the box next to the items you want to install.
  • Page 55: Manual Installation

    L4IBMG2 / L4IBMGL2 V1.0b Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your mainboard. Look for the chipset and mainboard model; then browse to the directory and path to begin installing the drivers.
  • Page 56 L4IBMG2 / L4IBMGL2 V1.0b We strongly recommend users to install this free anti-virus software to help protect your system against viruses. MediaRing Talk – Telephony Software To install the MediaRing Talk voice modem software for the built-in modem, go directory...
