Product options and specifications can be changed without notice. The information in this manual is furnished for informational use only and should not be construed as a commitment by Marshall Electronics, Inc. Marshall Electronics, Inc. assumes no responsibility or liability for any errors or inaccuracies that may appear in this publication. Safety Precaution We appreciate your video decoder purchase.
1. Introduction .......................... 4 1.1 About this Manual ......................4 1.2 Features ........................4 1.3 Product and Accessories ....................5 1.4 System Connections ..................... 6 2. Installation ..........................9 2.1 Check If It Works ......................9 3. System Operation ......................10 3.1 Remote Video Monitoring ...................
User Interface Diagnose and upgrade through dedicated program called VS Manager System Configuration using Internet Explorer High Reliability Reliable Embedded System System Recovery by Dual Watch-Dog Functions User Manual VS-104D-3GSDI – V1.0 Page 4 of 39 5/2016...
Audio and Serial data are transferred in either direction. An Encoder and Decoder can be connected by setting the Encoder’s Address for the Decoder’s Remote IP. User Manual VS-104D-3GSDI – V1.0 Page 6 of 39 5/2016...
Page 7
In this arrangement, video and audio can be re-transmitted from one center to another center. The arrangement is useful when the network bandwidth at the site is limited while there is more than one center wanting to monitor the site. User Manual VS-104D-3GSDI – V1.0 Page 7 of 39 5/2016...
Page 8
VMS (Video Management System) is a Windows based remote monitoring program to access multiple encoders for real-time monitoring or control of the encoders and connected cameras. Please refer to the VMS User Manual for more information on VMS. User Manual VS-104D-3GSDI – V1.0 Page 8 of 39 5/2016...
LINK Red Blinking Decoder Only: Trying to connect to an Encoder Illegal Connection (unsupported combination of Orange system modes) Green Data Transmission in Progress DATA Data Loss No Data Transmission User Manual VS-104D-3GSDI – V1.0 Page 9 of 39 5/2016...
Open Internet Explorer and enter the Camera’s IP Address. The system will ask for confirmation to install Active-X Control. Once authorized, Internet Explorer will begin to display video images from the camera as shown below: Default IP Address : http://192.168.10.100 User Manual VS-104D-3GSDI – V1.0 Page 10 of 39 5/2016...
Page 11
Sensor Input. When the sensor of the camera is working, the sensor light turns red. Operate the Alarm Device by pressing the number icon. This camera supports One Alarm Output. A number icon indicates the status of the alarm device. User Manual VS-104D-3GSDI – V1.0 Page 11 of 39 5/2016...
3. Once the system reboots, IP Address will be set to the System Default as below: IP Mode IP Address 192.168.10.100 Fixed IP Subnet Mask 255.255.255.0 Gateway 192.168.10.1 Base Port HTTP Port 2222 User Manual VS-104D-3GSDI – V1.0 Page 12 of 39 5/2016...
Event, Record, Device, PTZ, System, and User. To save configuration changes, click “Apply”. Leaving the page without clicking “Apply” will discard any new changes. 4.2 Video & Audio Configuration Information The information provides current information for Video and Audio Settings. User Manual VS-104D-3GSDI – V1.0 Page 13 of 39 5/2016...
Page 14
Select the Audio Operation Mode: Mode Action No Operation Tx-Only Transmit Only Rx-Only Receive Only Tx & Rx Transmit and Receive Input Gain Audio Input Gain ranges from 0 to 31. User Manual VS-104D-3GSDI – V1.0 Page 14 of 39 5/2016...
Page 15
Select the number of video frames to be buffered. A larger value results in smoother video by sacrificing the latency. A setting of 10-15 frames is generally used for most situations. User Manual VS-104D-3GSDI – V1.0 Page 15 of 39 5/2016...
Selection Description Local IP Fixed IP Address Fixed IP Local Gateway Gateway IP Address Local Subnet Subnet Mask DHCP Contact your ISP provider or network manager for IP address information. User Manual VS-104D-3GSDI – V1.0 Page 16 of 39 5/2016...
Page 17
Decoder, VMS or NVR software is connected in the Multicast Mode. The Multicast IP Address selection range is between 224.0.0.0 and 239.255.255.255. The selection can be used only when the media protocol is set to Multicast. User Manual VS-104D-3GSDI – V1.0 Page 17 of 39 5/2016...
Page 18
RTMP: RTMP connection with RTMP stream via RTMP Port. MPEG-TS: Decode Mpeg-TS steam via specific port defined by user. ONVIF: Decode steaming from ONIVIF Device. User can access profile list from ONVIF device. User Manual VS-104D-3GSDI – V1.0 Page 18 of 39 5/2016...
Page 19
When Zeroconf is ON, it allows the discovery of the client according to Zeroconf Protocol. WS Discovery Discovery function based on web service is enabled. It allows the discovery by the client SW which is supporting Onvif. SNMP User Manual VS-104D-3GSDI – V1.0 Page 19 of 39 5/2016...
Page 20
SNMP trap when it is out of paper. DDNS Select DDNS (Dynamic DNS) Encoder to use. One of the two can be selected. User Manual VS-104D-3GSDI – V1.0 Page 20 of 39 5/2016...
Page 21
IP in the network. IP Filtering IP Filtering is simply a mechanism that decides which types of IP datagrams will be processed normally and which will be discarded. User Manual VS-104D-3GSDI – V1.0 Page 21 of 39 5/2016...
Page 22
4. Remote Configuration Connecting IP Addresses that are currently connected are listed here. Decode List Decoder will change RTSP URL automatically. User can automatically stream from several encoders. User Manual VS-104D-3GSDI – V1.0 Page 22 of 39 5/2016...
Configure the actions when the link (connection) with peer system is disconnected. Multiple actions can be set for a single event. This event happens when the last client which has been receiving video from the video encoder loses the connection. User Manual VS-104D-3GSDI – V1.0 Page 23 of 39 5/2016...
Page 24
Set the duration of the Alarm or Beep Activation in case of an event. If Continuous is selected, the alarm will be in an active state until the operator resets it manually. User Manual VS-104D-3GSDI – V1.0 Page 24 of 39...
Choose Video Encoder Serial Port: RS-232 or RS-422/485; Select RS-422 or RS-485 for the RS-422/485 port. Serial Port Configuration: The Serial Port configuration is as follows (must be same as the connecting device): User Manual VS-104D-3GSDI – V1.0 Page 25 of 39 5/2016...
Preset Position by Event. Edit Label: Assign a Label to the Preset Position. Only the first 15 Preset Entries can have Assigned Labels (Preset-1 - Preset-15). User Manual VS-104D-3GSDI – V1.0 Page 26 of 39 5/2016...
Press Add button. The following window will appear. Enter User ID and password (Up to 15 characters) and select Privilege Level. Delete User Select the User to be deleted and press Delete button. User Manual VS-104D-3GSDI – V1.0 Page 27 of 39 5/2016...
Page 28
Privilege Level After Login Skipped. Authentication HTTP authentication based on RFC 2617(HTTP Authentication: Basic and Digest Access Authentication) is supported User Manual VS-104D-3GSDI – V1.0 Page 28 of 39 5/2016...
DDNS Encoder, the MAC address is used in DDNS registration. Set Current Time Display Current Date and Time Current Domain In case the encoder is registered at DDNS Encoder, the registered domain name is displayed. User Manual VS-104D-3GSDI – V1.0 Page 29 of 39 5/2016...
Page 30
Restore: Stored configuration can be browsed and restored. The encoder is rebooted once the Config Restore button is selected. Reboot Reboot Encoder: Do not press Reboot button unless the encoder needs a reboot. User Manual VS-104D-3GSDI – V1.0 Page 30 of 39 5/2016...
Page 31
(Coordinated Universal Time). In casual use, GMT (Greenwich Mean Time) can be considered equivalent to UTC. Local time is UTC plus the current time zone offset for the considered location User Manual VS-104D-3GSDI – V1.0 Page 31 of 39 5/2016...
Page 32
Note: Size of Burnin OSD display varies according to the encoding resolution setting. This is inevitable because Burnin OSD is inserted to the frames before encoding is performed. The following table describes the rule for BurnIn OSD display. User Manual VS-104D-3GSDI – V1.0 Page 32 of 39 5/2016...
Page 33
X-Coordinate or Y-Coordinate For example, if you enter 500, 500 values, OSD is placed in center of images. Language Language Select the Language to be used for Web-Based Configuration. User Manual VS-104D-3GSDI – V1.0 Page 33 of 39 5/2016...
Once VS Manager installed, select IP Discovery, create servers. On main page go to Tools, Options and change to this path below. In the address window, after the word "Files" type a space then (x86). User Manual VS-104D-3GSDI – V1.0 Page 34 of 39 5/2016...
H.264 / MJPEG Over 35 types of PTZ protocol USB recording Embedded Stereo and Analog Audio Dual Power (DC/PoE) RTSP / RTP / Onvif ______________________________________________________________________ User Manual VS-104D-3GSDI – V1.0 Page 35 of 39 5/2016...
Page 36
6. Data Sheet User Manual VS-104D-3GSDI – V1.0 Page 36 of 39 5/2016...
Relay Type Contact Rating : 1A 30VDC Switching Power : Max 30W 62.5VA Switching Voltage : Max 60VDC Alarm Signal Output Type NO/NC Contact Signals Connection to External Device User Manual VS-104D-3GSDI – V1.0 Page 37 of 39 5/2016...
Page 38
Pin No. Pin Name Description RS422 RX- RS422 RX+ RS422 TX- or RS485 TRX- It is selectable by S/W Setup RS422 TX+ or RS485 TRX+ It is selectable by S/W Setup User Manual VS-104D-3GSDI – V1.0 Page 38 of 39 5/2016...
Page 39
Marshall Electronics, Inc. 1910 East Maple Ave. El Segundo, CA 90245 Tel: (800) 800-6608 / (310) 333-0606 Fax (310) 333-0688 www.LCDRacks.com sales@lcdracks.com User Manual VS-104D-3GSDI – V1.0 Page 39 of 39 5/2016...
