3. OPERATING INSTRUCTION

3-1. IDENTIFICATION OF PARTS

SOFT SAFETY DOOR
TEMPERED GLASS
POWDER AND LIQUID
DETERGENT BOX
BLEACH
DISPENSER
FUNCTION
SELECTOR
TUB
START/PAUSE
BUTTON
Use to start or stop
the washing
machine
temporarily.
10
* WATER SUPPLY
HOSE
Make sure the water
does not leak.
* POWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid a hazard.
JET SPRAY CAP
* DRAIN HOSE
for pump model
Check if the drain
hose is placed into
the laundry tub and
secured before
operating the
washing machine.
DOOR SWITCH
* DRAIN HOSE
for non pump
model
BASE
