AML Oceanographic AML-3 LGR User Manual page 7

By default, AML-3 LGR instruments come equipped with a shackle, a USB-C connector, a
power switch, and a status indicator LED. The shackle has a hole coincident with the axis of the
instrument to facilitate suspension during deployment.
The end of the instrument opposite the shackle houses the sensor payload which is
mechanically protected by a thread-on cage. In some configurations the cage may be different
lengths depending on the sensors installed.
Typical specifications of an AML-3 LGR are described in the table below.
Specifications:
Model 500m
Depth rating 500 meters [1640 feet]
Material Acetal, 316 stainless steel,
titanium, polycarbonate
GPS Capability Yes
Data storage 30 GB
Software Sailfish
Communication USB-C
WiFi
Maximum 20 Hz
Sample Rate
Note: Sampling by pressure or
sound velocity increment is also
available.
Power 4 cell rechargeable internal battery
45Wh capacity
PC or wall charging over USB
(10W minimum)
Note: USB ports of some PC and
laptops may not meet the minimum
charging requirement of the
instrument. It is highly
recommended to use the included
USB Wall Charger for charging the
instrument.
AML Oceanographic Ltd.
6000m
6000 meters [19685 feet]
Acetal, 316 stainless steel, titanium,
polycarbonate
No
30 GB
Sailfish
USB-C
20 Hz
Note: Sampling by pressure or
sound velocity increment is also
available.
4 cell rechargeable internal battery
45Wh capacity
PC or wall charging over USB (10W
minimum)
Note: USB ports of some PC and
laptops may not meet the minimum
charging requirement of the
instrument. It is highly
recommended to use the included
USB Wall Charger for charging the
instrument.
