INGICS
Guide
Ver.0b
Introduction
The document is a guide for iBS06. To quickly verify it, please download INGICS iBS01 Tag
Utility APP from below link(Android only):
https://play.google.com/store/apps/details?id=com.ingics.tag.igstagconfig
Overview
Operation
Basically, iBS06 will always transmit BLE payload in the configured time interval(by default is 5s) after power on. The
transmitted BLE payload/message is then received and uploaded to the internet/cloud server by the beacon gateway, such
as iGS01S or iGS03W/M/E..
Power on
Two CR2012 batteries are pre-installed in each iBS06 beacon at shipment. Please remove the isolation plastic sheet to
power on it. You will see the LED flash when powered on. At power on, the user can configure it within 20 seconds.
INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM
TECHNOLOGY
iBS06 User Guide
1
Advertisement
Table of Contents
Related Manuals for Ingics iBS06
Summary of Contents for Ingics iBS06
- Page 1 Overview Operation Basically, iBS06 will always transmit BLE payload in the configured time interval(by default is 5s) after power on. The transmitted BLE payload/message is then received and uploaded to the internet/cloud server by the beacon gateway, such as iGS01S or iGS03W/M/E..
- Page 2 1. Power on iBS06 2. Open iBS01 Tag Utility APP and Press “START SCAN”. 3. Wait for a while, you should see the BLE payload of iBS06 received by the APP. Below is an explanation of the payload shown in the APP.
- Page 3 Level iBS06 uses two pieces of CR2012 coin battery as the power source. It consumes only a little power and keeps working for a long time. Below is a suggestion for translating the battery voltage to the remaining capacity at room temperature.
- Page 4 *PLEASE MAKE SURE THE POLARITY IS CORRECT.. Configuration When powered on, iBS06 will be in configuration mode for 20 sec. Users can use iBS01 Tag Utility to scan and connect iBS06 to configure the transmit power and ADV(advertising) interval. Steps 1.
- Page 5 Our customer has the responsibility to comply with the requirement of the directive too. To help our customers, when necessary, we will provide a WEEE compliant assessment report for registering and communicating with the local authorities and recycling agency. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
- Page 6 (2) This device must accept any interference received, including interference that may cause undesired operation. NCC 警語 「取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射 頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理 法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及 醫療用電波輻射性電機設備之干擾。」 Revision History DATE REVISION CHANGES Mar 18, 2022 Initial release Jun 7, 2022 Add Statement section INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
- Page 7 INGICS TECHNOLOGY INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
