INGICS
Guide
Ver.0c
Introduction
This application note is a guide for user to operate iBS04 beacon. To quickly verify it, please download INGICS iBS01
Tag Utility APP from below link(Android only):
https://play.google.com/store/apps/details?id=com.ingics.tag.igstagconfig
Operation
Power on
One CR2032 battery is pre-installed in each iBS04 beacon at shipment. Please remove the isolation plastic sheet to power on
it. You will see the LED flash when power on. At power on, user can configure it within 15 seconds.
Button
As pressing the button, the LED will light up. In the meantime, it will trigger a burst of BLE transmission in 300ms with button
active event. As back end server received this status change, it can be used as warning or alarming.
INGICS iBS01 Tag Utility
When powered on, iBS04 start to advertise immediately. User can use iBS01 Tag Utility to scan iBS04 and configure transmit
power and advertising internal of iBS04.
The basic configuration steps is
1.
At power on, iBS04 will be in configure mode within 15 seconds.
2.
Connect with the utility.
3.
Change the parameters and save
4.
Disconnect and then the parameter will be effective.
Details is as below
INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM
T ECHNOLOGY
iBS04 User Guide
1
