Marantz SR5500 Specification Sheet

SR5500 Dolby Digital EX
The SR5500 is an embarrassment of riches. Each "current feedback" amplifier produces 90 Watts RMS, sufficient for all but the largest rooms
or most inefficient speakers. The 32-Bit microprocessor decodes all Dolby, DTS surround sound formats, and SRS' Circle Surround II. Consider
the SR5500's multi-source/multi-room capabilities. Look no further than the front panel inputs to conveniently plug in a camcorder, portable
DVD player and/or game console. You'll appreciate the SR5500's enhanced video conversion capabilities as you watch a full complement of
sources through your monitor's high quality component video input. Want a customized system? The RS232 port allows total control for
external sources. The on-screen display quickly guides you through setup. The SR5500's "Lip Sync" circuit assures you that sounds reach your
ears at exactly the moment your eyes say they should. And its all covered by a three-year warranty.
• 90 Watts (into 8 ohms)
x 7 ch Amps
• Dolby Digital EX , Pro Logic
®
IIx (Movie/Music/Game),
®
• DTS 96/24, ES ® (Discrete
6.1/Matrix 6.1), Neo:6
(Cinema/Music)
• SRS Circle Surround II ®
• All Discrete "Current Feedback"
Amplifier Stages
• 32-Bit DSP
® /DTS ES
• 192kHz/24-Bit D/A Converters
for all Channels
• Dolby Headphone
• Video Up-conversion:
Composite/
S-Video to Component
• Multi-room/Multi-source
Capability with Discrete
Commands
• Multi Speaker "B" Output
• Lip Sync Control
® Surround Receiver
• On Screen Display
• Pure Direct Mode
• Video Off Mode
• Variable Cross-over
• Assignable HD Compatible
Component Video Switching
(2 in/1 out)
• 4 Assignable Digital Inputs
(2 optical/2 coaxial)
• 2 Digital Outputs
(1 optical/1 coaxial)
• Front Panel A/V Inputs
• 50 Station Presets
• Manual Station Naming
• RS232C Terminal for
System Control
• 1 Switched and 1 Un-switched
AC Convenience Outlets
• D-BUS (RC-5 In/Out) Remote
Connection
• Includes Pre-programmed
System Remote
®
Compatible
