PERSONAL LINE WITH
UNITY 4.0
Pre-Installation Requirements
Line: Personal
Equipment Code: D9***Q
Document Code: PIR-00068-EN
Rev: 2.0
Date: 05-12-2019

Advertisement

Table of Contents
loading

Related Manuals for Wellness TECHNOGYM PERSONAL D9C Q Series

Summary of Contents for Wellness TECHNOGYM PERSONAL D9C Q Series

  • Page 1 PERSONAL LINE WITH UNITY 4.0 Pre-Installation Requirements Line: Personal Equipment Code: D9***Q Document Code: PIR-00068-EN Rev: 2.0 Date: 05-12-2019...

  • Page 3: Table Of Contents

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Index GENERAL WARNINGS ..................7 NETWORK DESIGN – CONFIGURATION AND INSTALLATION ......9 INTRODUCTION ......................9 NETWORK DESIGN AND INSTALLATION (BUSINESS TO BUSINESS (B2B)) ..9 CONFIGURATION AND INSTALLATION (BUSINESS TO BUSINESS (B2B))....9 DISPLAY ......................11 BIKE PERSONAL ......................
  • Page 4 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 INTRODUCTION ......................23 VIRTUAL LAN ......................24 LAN ..........................24 UNITY 4.0 DVB-T / T2 / C / ISDB-Tb VERSION (-T) STANDARD OPTIONS .....25 UNITY 4.0 - VERSION (-A) STANDARD OPTIONS - USA/CANADA......28 FIREWALL / ROUTER RULES FOR ACCESS TO MYWELLNESS CLOUD ....28 Proxy (ONLY FOR UNITY 3.0) ..................28 ACKNOWLEDGEMENT AND ACCEPTANCE ...........31 LIST OF CHANGES FOR MANUAL REVISION ..........33...
  • Page 5 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 The information in this manual is intended for QUALIFIED TECHNICAL PERSONNEL - designated by the customer - who are in charge of preparing the electrical and network line, to guarantee the correct functioning of equipment.
  • Page 6 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Blank page Document Code: PIR-00068-EN - 6 - Uncontrolled copy if printed.

  • Page 7: General Warnings

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 GENERAL WARNINGS This manual includes informative notes with specific meanings: Safety signs classified according to the relative seriousness of the potential hazards: DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 8 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Blank page Document Code: PIR-00068-EN - 8 - Uncontrolled copy if printed.

  • Page 9: Network Design - Configuration And Installation

    (Switch, Router, firewall) and any wireless network are at the expense of the customer. ▪ Technogym warns that the efficiency and correct operation of the equipment and of the My- wellness Cloud services depend on the technical characteristics of the hardware that is in- stalled.
  • Page 10 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Blank page Document Code: PIR-00068-EN - 10 - Uncontrolled copy if printed.

  • Page 11: Display

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 DISPLAY 3.1 BIKE PERSONAL The Bike Personal (D9C**Q) product is fitted with UNITY 4.0 display. Fig. 1 3.2 RUN PERSONAL The Run Personal (D94**Q) product is fitted with UNITY 4.0 display. Fig.

  • Page 12: Recline Personal

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 3.3 RECLINE PERSONAL The Recline Personal (D96**Q) product is fitted with UNITY 4.0 display. Fig. 3 3.4 CROSS PERSONAL The Cross Personal (D95**Q) product is fitted with UNITY 4.0 display. Fig. 4 Document Code: PIR-00068-EN - 12 - Uncontrolled copy if printed.

  • Page 13: Technical Characteristics And Requirements

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 TECHNICAL CHARACTERISTICS AND REQUIREMENTS 4.1 TECHNICAL DATA AND POWER REQUIREMENTS 4.1.1 Bike - Recline - Cross PASSIVE PERSONAL EQUIPMENT BIKE RECLINE CROSS Braking power (70rpm) 40÷500W ± 10% 56÷436W ± 10% Power Supply 100÷240Vac 50/60Hz Maximum Absorption (*)

  • Page 14: Electrical Connection

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 (*): Theoretical values. 4.2 ELECTRICAL CONNECTION Technogym recommends a dedicated power supply line for each machine. Before connecting the product to the mains power supply, ensure that the electrical system speci- fications comply to binding regulations.

  • Page 15: Position Of The Product Socket

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 4.3 POSITION OF THE PRODUCT SOCKET Fig. 5 - Bike Personal Fig. 6 - Run Personal Document Code: PIR-00068-EN Uncontrolled copy if printed. - 15 -...
  • Page 16 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Fig. 7 - Recline Personal Fig. 8 - Cross Personal Document Code: PIR-00068-EN - 16 - Uncontrolled copy if printed.

  • Page 17: Network Requirements

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 NETWORK REQUIREMENTS 5.1 INTRODUCTION The equipment supports both wireless and wired internet connection. In all situations, where possible, Technogym recommends connection via network cable. In all cases, the network must be installed and configured by the customer before Technogym deliv- ers the product, in accordance with the technical specifications set out below.

  • Page 18: Wireless Guidelines

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 10, 11, 12. Other channels: 2, 3, 4, 13, 14 might cause interference with Bluetooth signal. - Avoid in any case to broadcast the same SSID, through 2.4 and 5 GHz, at the same time.

  • Page 19: Internet Connection Bandwidth Requirements

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 5.6 INTERNET CONNECTION BANDWIDTH REQUIREMENTS 5.6.1 Home Internet Speed requirements N°1 Equipment 5 Mbps or more for the best audio and video experience: HD quality (up to 1080p) 3 Mbps for viewing medium quality (standard definition video, DVD quality) 1.5 Mbps for viewing low quality video (minimum) (not recommended)
  • Page 20 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Fig. 9 Document Code: PIR-00068-EN - 20 - Uncontrolled copy if printed.

  • Page 21: Firewall / Router Rules For Access To Mywellness Cloud Services

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 5.7 FIREWALL / ROUTER RULES FOR ACCESS TO MYWELLNESS CLOUD SERVICES The Firewall\Router installed locally must be configured with ports 80 and 443 open. These ports must also be opened on the devices of the related ISP (Internet service provider). Free access to the Internet must be guaranteed for correct use of the Mywellness Cloud services, and in particular access to the following DNS names must never be disabled.
  • Page 22 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Blank Page Document Code: PIR-00068-EN - 22 - Uncontrolled copy if printed.

  • Page 23: Standard Tv Technical Specifications

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 STANDARD TV TECHNICAL SPECIFICATIONS 6.1 INTRODUCTION The data useful to antenna installers for checking the suitability of the antenna signal input to the equipment with UNITY 4.0 are detailed below. The readings in the tables below must be taken directly at the antenna input connector on the equipment.

  • Page 24: Virtual Lan

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Fig. 10 (*): DTMB not supported yet. 6.2 VIRTUAL LAN UNITY 4.0 doesn’t manage the VLANs because it has only one CPU port that manages both In- ternet and IPTV on the same network.Therefore it’s not possible to set a VLAN network on IPTV infrastructure.

  • Page 25: Unity 4.0 Dvb-T / T2 / C / Isdb-Tb Version (-T) Standard Options

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 6.4 UNITY 4.0 DVB-T / T2 / C / ISDB-Tb VERSION (-T) STANDARD OPTIONS NOT ENCRYPTED ▪ Analog TV + FM Radio; ▪ Digital TV DVB-T/ DVB-T2 (mpeg2, H264, HEVC) not encrypted; ▪...
  • Page 26 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 - install an external Set Top Box: HDMI-IN input ready for external STB -> Not sup ported. SUPPORTED ANALOGIC STANDARDS (DVB-T / T2 / C) ▪ PAL B/G , PAL I , SECAM DK , SECAM L , SECAM L1; ▪...
  • Page 27 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 COAX QAM Pro:IDIOM®: ATSC/ QAM-B Pro:IDIOM® UNITY 4.0 VERSION “-T“ + UPGRADE KIT A0000845 CABLE TV: QAM-B (64/256 QAM –ITU J83 Annex B) – Channel spa- cing 6 MHz DIGITAL TV : ATSC (free to air) ANALOG TV: Not available Broadcast System RADIO FM: Not available...

  • Page 28: Unity 4.0 - Version (-A) Standard Options - Usa/Canada

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 6.5 UNITY 4.0 - VERSION (-A) STANDARD OPTIONS - USA/CANADA NOT ENCRYPTED ▪ Analog TV (e.g. NTSC) + FM Radio; ▪ Digital TV (coax ATSC) not encrypted; ▪ Cable TV (coax QAM-B 64/256) not encrypted; ▪...
  • Page 29 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 STANDARD (NOT ENCRYPTED) ATSC/ QAM-B / ANALOG NTSC / IPTV UNITY 4.0 VERSION “-A“ Broadcast System CABLE TV: QAM-B (64/256 QAM –ITU J83 Annex B) – Channel spa- cing 6 MHz DIGITAL TV : ATSC (free to air) ANALOG TV: YES RADIO FM: YES...
  • Page 30 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 COAX QAM Pro:IDIOM®: ATSC/ QAM-B Pro:IDIOM® UNITY 4.0 VERSION “-A“ + UPGRADE KIT A0000845 Broadcast System CABLE TV: QAM-B (64/256 QAM –ITU J83 Annex B) – Channel spa- cing 6 MHz DIGITAL TV : ATSC (free to air) ANALOG TV: Not available RADIO FM: Not available...

  • Page 31: Acknowledgement And Acceptance

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 ACKNOWLEDGEMENT AND ACCEPTANCE Date: ____________________________________________ Acknowledged and accepted __________________________ Document Code: PIR-00068-EN Uncontrolled copy if printed. - 31 -...
  • Page 32 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Blank page Document Code: PIR-00068-EN - 32 - Uncontrolled copy if printed.

  • Page 33: List Of Changes For Manual Revision

    PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 LIST OF CHANGES FOR MANUAL REVISION The main changes made to this manual, are listed below in chronological order. 8.1 REVISION 1.0 First released version. 8.2 REVISION 2.0 Added information about Run, Cross and Recline products with Unity 4.0 display. Document Code: PIR-00068-EN Uncontrolled copy if printed.
  • Page 34 PERSONAL LINE with UNITY 4.0 Pre-Installation Requirements Rev. 2.0 Blank page Document Code: PIR-00068-EN - 34 - Uncontrolled copy if printed.
