Wiring DC Power out of the Click 204

+DC (red)
-DC (black)
GND (ground)
Note. Do not wire out of the DC OK terminal; it supplies only 20 mA and should only be used to monitor the status
of the power supply.
© 2022 Wavetronix LLC. All rights reserved. Protected in the US by patents viewable at www.wavetronix.com/en/legal. Protected by Canadian Patent Nos. 2461411; 2434756; 2512689; and European Patent Nos. 1435036; 1438702;
1611458. Other US and international patents pending. Wavetronix, SmartSensor, Click, Command and all associated logos are trademarks of Wavetronix LLC. All other product or brand names as they appear are trademarks or regis-
tered trademarks of their respective holders. Product specifications are subject to change without notice. This material is provided for informational purposes only; Wavetronix assumes no liability related to its use.
WX-501-0521 • 05.22
Click 202/204 DC Out
L
N
GND
3 of 3
