DOCUMENT LAYOUT
This document describes how to use the MPLAB ICD 3 In-Circuit Debugger as a
development tool to emulate and debug firmware on a target board, as well as how to
program devices. The document is organized as follows:
Part 1 – Getting Started
•
Chapter 1. About the Debugger
and how it can help you develop your application.
•
Chapter 2. Operation
operation. Explains configuration options.
Part 2 – Features
•
Chapter 3. Debugger Usage
MPLAB X IDE when the MPLAB ICD 3 In-Circuit Debugger is chosen as the
debug tool. This includes the debug features for breakpoints and stopwatch.
Part 2 – Troubleshooting
•
Chapter 4. Troubleshooting First Steps
are having issues with debugger operation.
•
Chapter 5. Frequently Asked Questions (FAQs)
questions, useful for troubleshooting.
•
Chapter 6. Error Messages
resolutions.
•
Chapter 7. Engineering Technical Notes (ETNs)
Part 3 – Reference
•
Appendix A. Debugger Function Summary
available in MPLAB X IDE when the MPLAB ICD 3 debugger is chosen as the
debug or program tool.
•
Appendix B. Hardware Specification
specifications of the debugger system.
•
Appendix C. Revision History
2012-2014 Microchip Technology Inc.
– What the MPLAB ICD 3 In-Circuit Debugger is
– The theory of MPLAB ICD 3 In-Circuit Debugger
– A description of basic debug features available in
– The first things you should try if you
– A list of error messages and suggested
– A summary of debugger functions
– The hardware and electrical
Preface
– A list of frequently asked
DS50002081B-page 7
