ROOMS TO GO GINA YO11-T Assembly Instructions

ROOMS
TO GO
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts, which may have come loose inside the carton during shipment. Identify and count
all parts and compare with the HARDWARE LIST below.
Caution: Please read instructions thoroughly before unpacking assembly parts.Sharp, exposed
staple tips can cause injury, therefore, for your protection, please remove any exposed
staple used in packing.
1. We recommend that you should assemble this product with the assistance of another person;
this will make assembly easier, and will help to eliminate damage to the product or injury to
persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
NO: HARDWARE LISTS
A
Iron tie bars(497x20 x
B
Left Plastic Plate (150x25x15)
C
Right Plastic Plate (150x25x15)
D
Screw(M4x12)
E Bolt(5/32"x12)
Step 3
Assembly Instructions
GINA TRUNDLE YO11-T SKU 34731225
GINA TRUNDLE YO12-T SKU 36131225
GINA TRUNDLE YO13-T SKU 35431220
GINA TRUNDLE YO21-T SKU 34731237
GINA TRUNDLE YO22-T SKU 35431232
Q'TY
1
5)
1
1
6
8
A
GINA TRUNDLE YO23-T SKU 36131237
GINA TRUNDLE YO31-T SKU 34731249
GINA TRUNDLE YO32-T SKU 35431244
GINA TRUNDLE YO33-T SKU 36131249
NO: PARTS LISTS
1
Drawer face
2
Drawer side
3
Panel
4
Bottom shelf (SET)
Step 1
2
1
Q'TY
2
2
1
2
Phillips head screwdriver
Not included
Step 2
