Summary of Contents for CHORTAU B-T47
- Page 1 Dash Cam 4K GPS High Speed Dual Dash Cam USER MANUAL Please Read WIFI Loop Recording Parking Monitor G-Sensor MODEL:B-T47...
- Page 3 INDEX Pre-Cautions Warnings Getting Started Specification Package Contents Interface and Button Function Basic Key Function Set Up and Installation Video Interface Video Recording Mode Photo Taking Interface Photo Taking Mode Playback Mode System Setting Menu WIFI Connection WIFI Feature Battery Information Problems and Solutions Warranty &...
- Page 4 Pre-Cautions Please read this manual very carefully before using the camera of installation and keep it safe for future reference. It will be helpful if you have any questions or encounter any operational problems. Warnings • This product is intended for use in motor vehicle only. Do not install the camera where it might block the driver's view of road (including the mirrors) or the deployment of the air bags.
-
Page 5: Getting Started
Before first time use, you MUST format the memory card in the camera or computer to prevent any errors. 3.The B-T47 dash cam is programmed to turn ON and START RECORDING automatically when it receives power, and STOPS RECORDING and turns OFF automatically when power gets disconnected within 4-5 seconds. - Page 6 If you want to view GPS tracking recording, you can download GXPlayer on your PC/MAC.(See page 23 for details) 6.WIFI: You can also connect Dash Cam B-T47 to your smart phone directly by using built-in WIFI feature. (See page 28, 29...
-
Page 7: Specification
Specification Model B-T47 Chipset / Sensor NOVATEK 96675 Screen 2 inch LCD Display Lens Front 170° Wide Angle Lens +Inside 110°Lens Lens Aperture F1.8 Front 2880x2160P @30fps (4K) Front 2560x1440P @30fps (2K) Video Resolution Front 2560P+Inside 1080P @30fps Front 1080P+Inside 1080P @30fps... -
Page 8: Package Contents
Operating -22°F(-30°C) ~176°F(80°C) temperature Package Contents Car charger USB Data Cable Dash Cam 4K GPS High Speed Dual Dash Cam USER MANUAL Please Read WIFI Loop Recording Parking Monitor G-Sensor MODEL:B-T47 2 Suction Mounts GPS module User Manual... - Page 9 Interface and Button Function Mini USB Power Input Speaker and Reset Microphone Micro SD Card Slot OK Button/ Power Button Lens Mode Button/ Up Button Menu Button/WIFI off Button/ Inside Lens Emergency Lock Button Split Screen Button/Down Button/ Audio on or off Button Windshield Mount Latch...
-
Page 10: Basic Key Function
Basic Key Function To Turn ON The Camera: Long press power button To Turn OFF The Camera: Long press & hold power button Short press power button to turn on /off screen Power In video recording mode, short press to start and stop recording Button In photo taking mode, short press to take a photo In playback, short press to start/stop playing the video... -
Page 11: Setup And Installation
Set Up and Installation 1.When charge, please using the supplied car charger, make sure the car camera and cable are well connected. When the dash cam is charging, the battery icon on the screen will show charging. 2. Insert a memory card Please turn off... - Page 12 Cigarette lighter Socket 8.Start the car, the power cord car charger red indicator will light up. The dash cam will auto power on and start recording.
-
Page 13: Video Interface
Video Interface S/N ICONS WHAT DOES IT MEAN Video Mode Icon Recording Status Audio Recording Status GPS Icon WIFI Icon Recording Time Power Status Resolution SIZE Memory Card Status Speed km/h Date and Time 2022/05/30 18:01:30... - Page 14 Exposure Value G-sensor Motion Detection Loop Recording NOTE: The GPS Icon flashes, which indicates that the GPS has been recognized, but not in place. The GPS Icon is green, which indicates that the GPS is in place.
-
Page 15: Video Recording Mode
Video Recording Mode In standby mode, short press the Menu button to enter the setting menu of video recording mode, press the Menu button twice to enter the system setting menu. If camera is in recording situation, click OK button to stop recording first (enter into standby mode), then short press Menu button to enter video setting menu. - Page 16 Motion Detection: This function allows the camera to start recording when it detects movement.(We suggest you turn off this function when driving) •ON •OFF (Default) Record Audio: The B-T47 dash cam has built-in Microphone to record audio with video. •ON •OFF (Default)
- Page 17 Date Stamp: The date and time marks in video files. •ON •OFF (Default) Inside mirror: You can turn on/ turn off inside lens’s mirror. •ON •OFF (Default) Image rotation: If you install dash cam upside town, you can turn on this feature. •ON •OFF (Default)
- Page 18 Photo Taking Interface S/N ICONS WHAT DOES IT MEAN Photo Taking Mode Icon Exposure AUTO Anti-shaking Power Status Memory Card Status Resolution 01922 Remaining Photo Storage Date and Time 2022/05/27 18:05:03...
-
Page 19: Photo Taking Mode
Photo Taking Mode In standby mode（Video Recording interface）Short press the M button to switch from Video Recording interface to Photo Taking interface.Then short press the MENU button to enter the setting menu of photo taking mode, short press the MENU button again to enter the system setting menu. - Page 20 Anti-Shaking: Turn ON / OFF. 1 Date Stamp: The date and time marks in picture files.
-
Page 21: Playback Mode
Playback Mode Viewing Video/Photos on the Camera When camera is recording, click“OK” button to stop recording, short press the “M” button twice to enter the playback mode. If camera is not recording which in standby mode, just short click twice of “M” button to enter playback mode directly. When you enter the playback mode and choose a file, then press menu button to option Delete, Protect or Slide Show. - Page 22 Delete: This menu will allow you to delete current video or delete all. •Delete Current •Delete All Protect: This feature will allow you make desired changes to saved video & photo files on memory card. •Lock Current •Unlock Current •Lock All •Unlock All Slide Show: This feature allows you to view slide show of your captured photo images from memory card.
- Page 23 Viewing video/photo on a computer 1)Connect with USB data cable You will see “Mass Storage”, “ PC Camera” on the camera screen, just select “Mass Storage” and press OK button to transfer video from dash cam to your computer. Connect with Card Reader...
- Page 24 Depending on your computer OS, the device will appear either as a removable drive or a removable volume. NOTE: When connected to your computer under “Mass Storage” status, standard camera setup and operations will be disabled. On windows On MAC...
- Page 25 NOTE: Movie File includes unlocked video, F.MP4 means front video, R.MP4 means Inside video. RO File includes locked video. How to review the recorded videos with GPS information on your computer?/How to download the application that can play the recorded video with GPS function? Before Recording: 1.Insert the micro SD card into the camera, and then turn...
- Page 26 Click “gxplayer” to install the player...
- Page 27 4.Open the GXPlayer, find the recorded video that you want to view, stop playing, after adjust setting then start playing. 5.Click setting to adjust setting, choose Language, Speed unit (KMH/PMH), Maps(amap/Google maps/Open street map).
- Page 28 , or contact us at our after service email support@chortau.cc, we will send a installation package to you. What are the GXPlayer features? 1.To see the Exact GPS route with the video on Google...
-
Page 29: System Setting Menu
Viewing video/photo on a Smart Phone To play on Smart Phone, simply turn on WIFI first from the camera, then connect the B-T47 Dash Cam WIFI by entering the default password “12345678”. Once connected, simply open the correct OKCAR app for your model. - Page 30 WIFI WIFI Connection This feature will allow you to turn wifi broadcast on from the camera so you can connect your phone with Dash Cam B-T47 to access videos, photos and settings. WIFI Name SSID Dash Cam B-T47*** Password 12345678 NOTE: You can short press “M”...
-
Page 31: Wifi Feature
WIFI range is 10FT from this small device. 3.Can I watch videos or surveillance around my car remotely? No, B-T47 dash cam is NOT made to broadcast footage over the cloud or internet. It is NOT a cloud or an IP camera and it... - Page 32 Inside Night Mode: Off/On/ Auto If you turn on night mode function, inside videos and pictures will be black and white mode. Screen Saver: Set the time to automatically turn off the LCD display after no operation. •15 Seconds, 30 Seconds, 1Minute. •...
- Page 33 文 Language : English / French / Spanish / Portuguese / German / Italian / Simplified Chinese/ Traditional Chinese / Japanese Frequency : Set light frequency to 50Hz or 60Hz, and press GPS: This feature allow you to see your current geographical location in Latitude &...
- Page 34 Go to http://www.greenwichmeantime.com/time-zone/usa to find out your correct GMT value based on your location in USA. NOTE: If you drive to another state which is another time zone, please adjust the time zone to local time zone to make sure the GPS show local location with real time. It is the same as our cellphone, when we fly to another country, we also need to adjust the time zone to local country time zone in cellphone settings.
- Page 35 Speed Unit: Turn ON/OFF speed display, Press OK to select either KMH or MPH. Daylight Saving: Turn ON/OFF. Parking Monitor: This feature is designed to work when camera is shaken during Hit & Run event while your car is parked. When someone hits your car and shaking is detected based on your G-sensor setting, the camera will turn on automatically, then start recording for about 30S on internal battery, then lock...
- Page 36 Default Setting: Here you can restore all the settings to factory default settings. •Cancel •OK Version: Here you can check firmware version installed on your camera. Auto Power Off: Set the time for the camera to automatically power off. •1Min, 2Mins, 3Mins. •OFF (Default)
-
Page 37: Battery Information
Battery Information This Product contains Lithium-ion inbuilt battery. With a full charge battery should last up to 2-10 minutes. Internal battery is NOT meant to last long time. The purpose of in-built battery is to save the last video file safely without any data loss and turn off... -
Page 38: Problems And Solutions
Removed the protective film of the suction mount. Please kindly soak suction mount to warm water for a moment. If it is still not working, just contact us at support@chortau.cc to get a replacement. Q: The recorded video is unclear? A: Make sure there are no fingerprints or dirt on the lens, Try... -
Page 39: Warranty And Support
Warranty & Support Warranty B-T47 dash cam comes with 2 Years warranty. Support If you have any questions regarding this dash cam, please do not hesitate to contact us at support@chortau.cc will get back to you within 24 hours. Email...
