Ecodan EHPT15X-UKHLDW1S Service Manual page 11

Dimensions - 22mm Slimline Models
B & D
F
E
KEY
A OVERALL HEIGHT
B HEAT PUMP FLOW CONNECTION (22mm O/D COPPER)
C TUNDISH OUTLET CONNECTION (22mm COMPRESSION)
D HEAT PUMP RETURN CONNECTION (22mm O/D COPPER)
E HEATING ZONE 1 CIRCUIT FLOW CONNECTION (22mm O/D COPPER)
F HEATING ZONE 1 CIRCUIT RETURN CONNECTION (22mm O/D COPPER)
G COLD WATER INLET CONNECTION (22mm COMPRESSION)
H HOT WATER OUTLET CONNECTION (22mm COMPRESSION / 3/4" BSP M)
J THW5A SENSOR POCKET
K WI-FI ADAPTOR (INCLUDED, INSTALLER TO LOCATE AND MOUNT)
CAPACITY
A
B
C
D
E
F
J
K
Installer to locate and mount
491
H
B D
K
150 170
1516 1690
1127 1127
909 1083
1127 1127
350 350
194 194
943 1117
G
A
J
C
676
11
