General Information
A
Q
P
O
Figure 2-3. 20 kW–26 kW—Components and Control Locations
A Lock with cover
B Main line circuit breaker
(generator disconnect)
C Airbox with air cleaner
D Control panel
E Battery compartment
(battery not supplied)
F Exhaust enclosure
G Status LED indicators
7
R
T
S
N
M
H Oil drain hose
J
K Oil filter
L
M Oil dipstick
N Sediment trap
O Fuel regulator
B
F
C
D
E
J
L
K
H
Oil fill cap
Composite base
Owner's Manual for 60 Hz Air-Cooled Generators
P Fuel inlet
Q Wi-Fi module
R Data decal location
S Auxiliary shutdown switch
T Auxiliary shutdown switch
