6.4 Mounting & Connection (w/ Heater)
Step 1:
•
Slide the heat guard over
the fluid manifold. The
alignment is done by the
nozzle adjustment nut and
the fluid manifold with
heating module.
Step 2:
•
Use the 4 mm hex wrench
to install the provided M6
screw from the bottom to
secure the heat guard in
place.
Caution:
over-tighten the screw
because it can damage the
heat guard.
Step 3:
•
Connect the heater cable (4-
pins)
from
heating
'HEATER'
controller.
connecting,
locking sleeve to secure the
connection.
Do not
the
valve's
module
to
the
port
of
the
Caution:
After
tighten
the
techcon.com/contact-us
TS9800 & TS980
Jet Valve Dispensing System User Guide
21
