Wavecom TR2126SE Installation And Operation Manual

Mds/mmds transceiver

Advertisement

Quick Links

MDS/MMDS Transceiver
TR2126SE
INSTALLATION AND OPERATION
GUIDE FOR SYSTEM OPERATORS

Advertisement

Table of Contents
loading

Summary of Contents for Wavecom TR2126SE

  • Page 1 MDS/MMDS Transceiver TR2126SE INSTALLATION AND OPERATION GUIDE FOR SYSTEM OPERATORS...
  • Page 2 WaveCom Electronics Inc. WaveCom Electronics Inc. reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of WaveCom Electronics Inc. to provide notification of such revision or change.
  • Page 3 No doubt you’ve been thinking that the future of your television delivery system includes new technologies such as Digital TV, Internet Over Cable, Wireless Cable. By selecting WaveCom, you are benefiting from the same design powerhouse that since 1988 has created custom RF and digital products for technology leaders such as AT&T, Cisco Systems, Cogeco, Comcast, and Cox Communications.
  • Page 4 Important Installation Instructions CAUTION: To comply with FCC RF exposure requirements in section 1.1307, a minimum separation distance of 1.5 meters is required between this antenna and all persons. WaveCom Electronics Inc TR2126SE Manual; ml_tr2126se_04 (May 2003) Approved: C.H.
  • Page 5: Table Of Contents

    4.0 WARRANTY STATEMENT AND SERVICE POLICY ............15 4.1 Warranty Statement ..........................15 4.2 Service Policies: How to Return an Item for Service:............... 15 4.3 Repair Charges and Warranty Exemptions ..................16 WaveCom Electronics Inc TR2126SE Manual; ml_tr2126se_04 (May 2003) Approved: C.H.
  • Page 6: General Information

    1.0 GENERAL INFORMATION 1.1 Functional Overview The WaveCom TR2126SE is an MDS/MMDS Transceiver for use in wireless systems. The TR2126SE integrates an LNA, downconverter, upconverter, power amplifier, RF and IF diplexers to provide a one-box solution for two-way wireless RF communications. The TR2126SE and antenna are situated outdoors and connected to a cable modem indoors by standard RG-59 cable.
  • Page 7: Specifications

    -40 to +60°C (-40 to +140°F) Size 6" x 8" x 0.9" (15.24 x 20.32 x 2.29 cm) Mounting Pole mount (1” to 1.75” (25mm to 44mm) diameter) Specifications subject to change without notice. WaveCom Electronics Inc TR2126SE Manual; ml_tr2126se_04 (May 2003) Approved: C.H.
  • Page 8: Installation

    2 ¼”x20 flange locknuts for connecting V-bolt and pole catch to the pole The TR2126SE was designed for mounting to a pole with a diameter of 1.0" to 1.75". Please ensure that the pole used is attached securely to the building or other mounting location. Simply secure the TR2126SE unit to a pole as shown in Figure 2.2A with F-Connector on the bottom.
  • Page 9: Mounting The Antenna

    Dipole/parabolic reflector ☛ Included with the TR2126SE unit is a self-adhesive label for application to the antenna. To operate the TR2126SE in compliance with FCC regulations, you must apply the included label to the antenna. Peel off the protective backing from the label and affix it to the antenna such that the label is readable from a distance of 5 feet.
  • Page 10: Connection To The Antenna

    2.3 Connection to the Antenna Connect the TR2126SE to the Antenna via the N-Connector D D D D A A A A IAGRAM IAGRAM IAGRAM IAGRAM A A A A ONNECTION TO THE ONNECTION TO THE ONNECTION TO THE ONNECTION TO THE...
  • Page 11: Connection To The Power Inserter And Cable Modem

    Connect the TR2126SE F-Connector to the power inserter, located indoors with the cable modem. Connect the power inserter to the Cable Modem. If the TR2126SE is equipped with the optional self install feature, insure that the power inserter is connected to the Cable Modem, only after the antenna is aligned.
  • Page 12: Waterproofing Connections

    STEP 1 Use one 6” section of rubber sealing tape. Starting at the TR2126SE end, stretch the tape and wrap it around the connector as close as possible to the wall of the TR2126SE. Overlap the tape by approximately one-half of it’s width so that it can form a seal with itself.
  • Page 13 C C C C – – – – S S S S 3 3 3 3 IAGRAM IAGRAM C C C C ATERPROOFING ATERPROOFING ONNECTION ONNECTION IAGRAM IAGRAM ATERPROOFING ATERPROOFING ONNECTION ONNECTION WaveCom Electronics Inc TR2126SE Manual; ml_tr2126se_04 (May 2003) Approved: C.H.
  • Page 14: Tuning The Antenna

    TR2126SE. To use the aid, first mount the TR2126SE and the antenna with the antenna mounts left loose to permit alignment. Connect the antenna to the TR2126SE ANTENNA port, and apply DC power to the TR2126SE through the MODEM port when you are ready to begin.
  • Page 15: Warranty Statement And Service Policy

    4.1 Warranty Statement WaveCom warrants its products to be free from defects in workmanship or materials for a period of two years. The warranty begins on the date of the original shipment from WaveCom to its customer. No claim may be allowed for expenses incurred in installation or use.
  • Page 16: Repair Charges And Warranty Exemptions

    Descriptions of these charges and warranty exemptions are below: 1) Repair turnaround time is typically 5-14 business days after receipt of the item at WaveCom. A Flat Rate Repair Charge will apply to all out-of-warranty items. Flat Rate Repair Charges are subject to change without notice.
  • Page 18 150 Cardinal Place Saskatoon, Saskatchewan S7L 6H7 Canada Tel: (306) 955-7075 Fax: (306) 955-9919 www.WaveCom.ca sales@WaveCom.ca...
