Efficiency Statement - Evince ELITE EV-ELT-948-1.0 Owner's Manual

EFFICIENCY STATEMENT

This product is efficiency rated according to NSF/ANSI 44. The stated efficiencies are valid only at the specified Sodium Chloride dosages and maximum service flow rate.
MODEL NUMBER
QTY HIGH CAPACITY RESIN
RATED SERVICE FLOW (GPM)
PRESSURE DROP AT RATED SERVICE FLOW (PSI)
RATED SOFTENING CAPACITY (GRAINS)
EFFICIENCY (GRAINS/LB SALT)
MAX. FLOW RATE TO DRAIN (GPM)
WORKING PRESSURE
OPERATING TEMPERATURE
These refiners conform to NSF/ANSI 44 for the specific performance claims as verified and substantiated by test data. These models are efficiency rated. The efficiency rating
is valid only at the stated salt dose and maximum service flow rate. They have a demand initiated regeneration (D.I.R.) feature that complies with specific performance
specifications intended to minimize the amount of regenerant brine and water used in their operation. These refiners have a rated refiner efficiency of not less than 3350
grains of total hardness exchange per pound of salt (based on sodium chloride) and shall not deliver more salt than their listed ratings. The rated salt efficiency is measured by
laboratory tests described in NSF/ANSI Standard 44. These tests represent the maximum possible efficiency that the systems can achieve. Operational efficiency is the actual
efficiency after the system has been installed. It is typically less than the efficiency due to individual application factors including water hardness, water usage, and other
contaminants that reduce the refiner's capacity. These systems are not intended for use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system. For best results, use plain, white block salt. Refer to Installation/operation manual and warranty for further details on installation, parts
and service, maintenance and further restrictions or limitations to the use of the product.
Certified by IAPMO R&T according to NSF/ANSI 44 for
effective reduction of hardness (calcium and magnesium)
as verified and substantiated by test data.
4
PERFORMANCE DATA SHEET
EV-ELT-948-1.0 EV-ELT-1054-1.0
1.0 FT3 1.5 FT3
11.0 11.2
15.0 15.0
13,629 @ 3LBS 20,443 @ 4.5LBS
4,543 4,543
2.0 2.4
MIN 39 - MAX. 100 DEGREES FAHRENHEIT
EV-ELT-1252-1.0
2.0 FT3
12.4
15.0
27,258 @ 6LBS
4,543
3.5
MIN. 20 - MAX. 125 PSI
EV-ELT-1354-1.25
2.5 FT3
12.6
15.0
34,072 @ 6LBS
4,543
4.0
