1. Page 18 of this manual contains important maintenance procedures for the continued proper
operation of your unit. These MUST be performed regularly for your warranty to remain valid.
2. Read all instructions carefully before operation.
3. Avoid pinched o-rings during installation by applying NSF certified lubricant to all seals (provided with install kit).
4. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system.
Evince™ Direct Phone Number: 951.734.7400
108 Business Center Dr
Corona, CA 92880

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INSIGHT EV-IN-BW-948-1.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Evince INSIGHT EV-IN-BW-948-1.0

  • Page 1 3. Avoid pinched o-rings during installation by applying NSF certified lubricant to all seals (provided with install kit). 4. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Evince™ Direct Phone Number: 951.734.7400 108 Business Center Dr Corona, CA 92880...
  • Page 4: Table Of Contents

    PREPARATIONS INSTALLATION STEPS INSTALLATION STARTUP INSTRUCTIONS DURING REGENERATION PLUMBING SYSTEM CLEAN-UP SYSTEM MAINTENANCE SERVICING EVINCE INSIGHT VALVE DIAGNOSTIC SCREEN REPLACE PISTON AND/OR BRINE VALVE ASSEMBLY CLEAN INJECTOR ASSEMBLY REPLACE TIMER REPLACE MOTOR REPLACING THE BYPASS AND METER CABLE DISPLAY REPLACEMENT...
  • Page 5: Read This Page First

    READ THIS PAGE FIRST BEFORE STARTING INSTALLATION   Read this manual thoroughly to become familiar with the Avoid pinched o-rings during installation by applying device and its capabilities before installing or operating your (provided with install kit) NSF certified lubricant to all seals. Water Conditioner.
  • Page 6: Specifications

    15 psig. etc. • The manufacturer reserves the right to make product improvements which may Note: Evince Systems can be installed into homes and small commercial applications with up to 1.25" plumbing. Optional 1.25" connections available upon request. SYSTEM DIMENSIONS Models...
  • Page 7: Water And Time Consumed During Regeneration

    WATER AND TIME CONSUMED DURING REGENERATION Total Backwash Rapid Rinse Total Water Consumed during Models Time of Minutes Minutes Regeneration (GAL) Regeneration V-ELA-TT- Step 3 Step1 Step 2 CONTROL VALVE REGENERATION SEQUENCE The regeneration cycle goes through 3 steps. Backwash (minimum 30 psi inlet pressure required): During the backwash cycle, water flows upwards through the bed, expanding the media and carrying any...
  • Page 8: Unpacking / Inspection

    UNPACKING / INSPECTION Be sure to check the entire unit for any shipping damage or parts loss. Also note damage to the shipping cartons. Contact the transportation company for all damage and loss claims. The manufacturer is not responsible for damages in transit. Small parts, needed to install the Conditioner, are in a parts box.
  • Page 9: Find And Record Valve Type & Serial Numbers

    FIND AND RECORD VALVE TYPE & SERIAL NUMBERS There are two labels located on your Unit: 1) Control valve label and 2) System number label. Find and record your product model number, serial number, and valve serial number in the Records & Contacts section as they will be important if you need to troubleshoot. Item # Model # Control Valve Serial #...
  • Page 10: Before Installation

    BEFORE INSTALLATION NOTE Make sure you have a copy of your most recent water test results. If your water has not been tested previously you can contact All government codes and your supplier of this product to obtain a water sample bottle to be sent to one of our facilities for a free analysis. It is important regulations governing the that this product not be installed until you have this information.
  • Page 11: Preparations

    PREPARATIONS CAUTION! The unit should be 1. Media Installation (When Necessary). Models larger than 2.0 CF of media are shipped with separate media in pails or boxes. Models lower than 1.5 CF of media come loaded with media and this step can be skipped for new installation. depressurized before installing or replacing media Plug the Riser...
  • Page 12: Installation Steps

    INSTALLATION STEPS 1. Determine the best location for your water filter, bearing in mind the location of your water supply lines, drain line and 120 volt AC electrical outlet. Subjecting the filter to freezing or temperatures above 43°C (110°F) will void the warranty. Please notice the inlet and outlet arrows on the valve as shown here to determine the position of the equipment...
  • Page 13: Installation

    INSTALLATION Cold (Filtered water) Cold (Raw water) To Outside Faucet Cold (Filtered Water) Filter Hot (Filtered Water) Water Heater AC120V/10A Current Protect Socket Water Pipe Inlet Water Pipe Outlet 5/8” Clean-Out Line 5/8” Clean-Out Line Laundry Drain AG100-001 Optional Air Gaps Pipes Fixed 1 1/2 or 2 inch Structure...
  • Page 14 INSTALLATION (CONTINUED) Evince INSIGHT Units Open the inlet on the bypass valve slightly and very slowly allow water to enter the unit. (If the water enters too quickly it will push the media up into the control valve and get plugged).
  • Page 15: Startup Instructions

    STARTUP INSTRUCTIONS 2. Screen Display System initializing When power is supplied to the Please wait 1. Connect the Transformer to the Valve MENU control, the screen will display “INITIALIZING WAIT PLEASE” Plug the 12-volt transformer into a 120 VAC 60 Hz outlet. while it finds the service position.
  • Page 16: During Regeneration

    STARTUP INSTRUCTIONS (CONTINUED) 4. set up date and time of day The Valve is already programmed from factory for refiner models. Set Up Current Time of Day and Regeneration Time When Refiner Should Regenerate When No one uses Water in House.Press Menu Key and Select “Date and Time”...
  • Page 17: Plumbing System Clean-Up

    DURING REGENERATION (CONTINUED) New Sounds You may notice new sounds as your water conditioner operates. The regeneration cycle lasts approximately 1.5 hours to 3.0 hours depending on the specific model. During this time, will be able to hear water running intermittently to the drain, depending on proximity of the unit to sleeping area and time of regeneration.
  • Page 18: System Maintenance

    — Your inlet water quality and water consumption will determine how often the media should be replenished or replaced. Check with your water treatment expert for the media bed change frequency. SERVICING EVINCE INSIGHT VALVE Before Servicing 1. Turn off water supply to conditioner : a.
  • Page 19 MASTER PROGRAMMING Below is how the settings are set at factory: PRESS MENU KEY AND SCROLL TO PRESS ‘+’ AND ‘-’ FOR 8 SECONDS ‘MAIN MENU’ . THEN VALVE SETTINGS PRESS ‘SET’ TILL IT BEEPS MODELS LANGUAGE REGION VALVE METER SALT VS AUTO REGEN.
  • Page 20 Dealer Information Dealer Information Main Menu Main Menu = = Dealer Information = = = = Date and Time = = Evince 17 - Feb - 2016 108 Business Center Dr 12:25PM Corona, CA 92880 Press To Cancel TEL 951.734.7400Press...
  • Page 21: Diagnostic Screen

    DIAGNOSTIC SCREEN PRESS “MENU” KEY AND SCROLL TO “MAIN MENU”. THEN PRESS “SET” TILL IT BEEPS. SCROLL TO ADVANCED MENU Press “Menu” key . Press - to advance to Main Menu. Press “SET” PRESS “MENU” KEY AND SCROLL or until you hear a beep. Press - to advance to Advanced Menu TO “MAIN MENU”.
  • Page 22: Replace Piston And/Or Brine Valve Assembly

    REPLACE PISTON AND/OR BRINE VALVE ASSEMBLY Piston Remove 4 X Assembly Seal and Screws Spacer Plate Brine Valve Assembly 1. Follow steps 1 to 6 of 3. Remove the plate from the valve body and pull the Piston 5. Replace piston assembly followed by timer assembly. timer /Powerhead replacement.
  • Page 23: Replace Timer

    REPLACE TIMER 4 X Screws Meter Cable Front Cover 1. Disconnect the meter cable from the meter. (If flow 2. Remove four screws from the back of the valve cover 3. Remove the front cover of the valve. meter is attached) 2 X Screws from Powerhead Powerhead Piston Screw...
  • Page 24: Replacing The Bypass And Meter Cable

    REPLACING THE BYPASS AND METER CABLE Grey Meter Cable 60010267 Bypass comes with Meter 60095101 and Grey Meter Cable Step 1 Step 2* Disconnect the meter cable from Unplug the Remove 2 screws and the bypass. clips from bypass. power from the wall socket.
  • Page 25: Display Replacement

    DISPLAY REPLACEMENT 1. Remove the screws from the back of the valve and pull the front cover 2. Remove all connections from the circuit board 3. Remove the four screws from the circuit board and pull it out REPLACE MICROSWITCHES Front Cover 4X Screws Microswitches...
  • Page 26: Replace Drain Line Flow Control

    REPLACE DRAIN LINE FLOW CONTROL Drain Line Washer Clip 1. Pull the drain line clip and remove the drain line elbow Drain Line Elbow and washer 2. Clean/replace drain line washer REPLACE BRINE LINE FLOW CONTROL Clip Brine Line Washer 1.
  • Page 27: Parts Breakdown

    PARTS BREAKDOWN Control Valve Bypass 60010004 Distributor CONTROL VALVE # PRESSURE SYSTEM MODEL DISTRIBUTOR # CONTROL VALVE # TANK SIZE EV-IN-BW-948-1.0 9 x 48 25020213 EV-IN-BW-1054-1.0 10 x 54 25020214 940956 EV-IN-BW-1252-1.0 12 x 52 25010060 EV-IN-BW-1354-1.0 13 x 54 25010066...
  • Page 28 Locating wheel(UF) 05056141B Washer on Locating Wheel 05033004 Screw 2.2×13 05056166B Screw on Locating Wheel 05041011 Micro Switch 13000332 Screws on Micro Switch 13000401 Screws on PCB 92388 05033008B 05033027 PCB Absorb Shock Foam 05033011F Front Cover(White) 05033007E Controller Touch Panel(Evince®)
  • Page 29 PARTS BREAKDOWN Parts list of control valve body: Part # Part # Description (Water Group) (Canature) 60010184 21389033 Brine Line Elbow Nut 60010172 30020013M Brine Line Elbow 60010044 05056134 O-ring of Brine Line Elbow 60010188 05031033 O-ring of BLFC Holder 60010173 05031010M BLFC Holder...
  • Page 30: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Problem Cause Possible Solutions 1. FILTER BLEEDS TASTE AND ODOR OR A. Bypass valve is open A. Close bypass valve SEDIMENT B. Electrical service to unit has been interrupted B. Assure permanent electrical service (check fuse, plug or switch) C.
  • Page 32: Warranty

    Life Time Warranty on Mineral Tanks and Brine Tanks Evince® will provide a replacement mineral tank or brine tank to any original equipment purchaser in possession of a tank that fails provided that the water conditioner is at all times operated in accordance with specifications and not subject to freezing or vacuum.
