1. Page 18 of this manual contains important maintenance procedures for the continued proper
operation of your unit. These MUST be performed regularly for your warranty to remain valid.
2. Read all instructions carefully before operation.
3. Avoid pinched o-rings during installation by applying NSF certified lubricant to all seals (provided with install kit).
4. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system.
IAPMO R & T Certified
against CSA B483.1
Evince™ Direct Phone Number: 951.734.7400
108 Business Center Dr
Corona, CA 92880
IAPMO R & T Certified
against NSF/ANSI 44
Advertisement
Table of Contents
Related Manuals for Evince ELITE EV-ELT-948-1.0
Summary of Contents for Evince ELITE EV-ELT-948-1.0
- Page 1 3. Avoid pinched o-rings during installation by applying NSF certified lubricant to all seals (provided with install kit). 4. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Evince™ Direct Phone Number: 951.734.7400 108 Business Center Dr Corona, CA 92880...
-
Page 2: Table Of Contents
STARTUP INSTRUCTIONS DURING REGENERATION / PLUMBING SYSTEM CLEAN-UP MAINTENANCE INSTRUCTIONS AND SCHEDULE IMPORTANT WARRANTY AND MAINTENANCE INFORMATION RES-UP® FEEDER INSTALLATION INSTRUCTIONS (OPTIONAL) SERVICING EVINCE ELEVATE VALVE MASTER PROGRAMMING DIAGNOSTIC SCREEN REPLACEMENT REPLACE PISTON AND/OR BRINE VALVE ASSEMBLY / CLEAN INJECTOR ASSEMBLY... -
Page 3: Read This Page First
READ THIS PAGE FIRST BEFORE STARTING INSTALLATION Read this manual thoroughly to become familiar with the Avoid pinched o-rings during installation by applying device and its capabilities before installing or operating your (provided with install kit) NSF certified lubricant to all seals. Water Conditioner. -
Page 4: Efficiency Statement
EFFICIENCY STATEMENT This product is efficiency rated according to NSF/ANSI 44. The stated efficiencies are valid only at the specified Sodium Chloride dosages and maximum service flow rate. PERFORMANCE DATA SHEET MODEL NUMBER EV-ELT-948-1.0 EV-ELT-1054-1.0 EV-ELT-1252-1.0 EV-ELT-1354-1.25 QTY HIGH CAPACITY RESIN 1.0 FT3 1.5 FT3 2.0 FT3... -
Page 5: Specifications
Min. 20 - Max. 125 psi For satisfactory operation, the pumping rate Note: Evince® Systems can be installed into homes and small commercial applications with up to 1.25" plumbing. Optional 1.25" of the well system must equal or exceed connections available upon request. -
Page 6: System Dimensions
SYSTEM DIMENSIONS Models A (Inches) B (Inches) C (Inches) EV-ELT-TT-948-1.0 59 3/4” 9" 13” EV-ELT-TT-1054-1.0 65 3/4” 10" 13” EV-ELT-TT-1252-1.0 63 3/4” 12" 13” EV-ELT-TT-1354-1.0 65 3/4” 13" 13” BRINE TANK DIMENSIONS Model Liquid Volume Tank Dimensions 5 Pack Carton Salt Capacity 5 Pack Carton (inches) -
Page 7: Unpacking / Inspection Of Twin Tank Model
UNPACKING / INSPECTION OF TWIN TANK MODEL SYSTEM CONTENTS: There are 8 black clips. Please MODELS: check to make sure you have EV-ELT-948-1.0 all of them. EV-ELT-1054-1.0 EV-ELT-1252-1.0 EV-ELT-1354-1.0 Bypass (not YOU WILL EXPECT THE FOLLOWING. attached) SHIPPING CARTON QUANTITY – 1 1. - Page 8 UNPACKING & INSPECTION For Models EV-ELT-1252-1.0 and EV-ELT-1354-1.0, the media and Control Valve is packaged separately in carton and bags 4. Control Valve WHAT IS INCLUDED WITH EV-ELT-1252-1.0 AND EV-ELT-1354-1.0 MODELS? YOU WILL EXPECT THE FOLLOWING. SHIPPING CARTON QUANTITY – 1 1.
-
Page 9: Brine Tank Assembly
Pipe connector - 14” - 18” / 8” - 12” Tanks 6. Install the connectors with Make sure all black clips are firmly in place before applying fitting as shown. Also install pressure the valve on the parallel adapter BRINE TANK ASSEMBLY c) Drop the brine grid with brine well inside the d) Take the brine tube and insert the nut and plastic sleeve as brine tank such that the nut fitting faces the... -
Page 10: Check Valve Type And Valve Serial
CHECK VALVE TYPE AND VALVE SERIAL # Check to make sure Valve Type is Upflow (UF) (left Sticker shown below). The right Sticker shows the serial # of the control valve. The middle sticker is a dataplate which provides information of Serial # and Date of Manufacture of complete system. Both Serial # labels are important for troubleshooting. Please record these numbers on the back page of this manual for future reference. -
Page 11: Before Installation
BEFORE INSTALLATION NOTE Make sure you have a copy of your most recent water test results. If your water has not been tested previously you can contact All government codes and your supplier of this product to obtain a water sample bottle to be sent to one of our facilities for a free analysis. It is important regulations governing the that this product not be installed until you have this information. -
Page 12: Preparations
PREPARATIONS CAUTION! The unit should be 1. Media Installation (When Necessary). Models larger than 2.0 CF of media are shipped with separate media in pails or boxes. Models lower than 1.5 CF of media come loaded with media and this step can be skipped for new installation. depressurized before installing or replacing media Plug the Riser... -
Page 13: Installation Steps
INSTALLATION STEPS 1. Determine the best location for your water filter, bearing in mind the location of your water supply lines, drain line and 120 volt AC electrical outlet. Subjecting the filter to freezing or temperatures above 43°C (110°F) will void the warranty. Please notice the inlet and outlet arrows on the valve as shown here to determine the position of the equipment... -
Page 14: Water Conditioner Installation
WATER CONDITIONER INSTALLATION Connect Conditioner to the HousePlumbing Any solder joints near the valve must be done before connecting any piping to the valve. Always leave at least 6” (152 mm) between the valve and joints when soldering pipes that are connected to the valve. Failure to do this could cause damage to the valve. Tee to outside or high demand un ltered water Cold (Raw water) Cold (Raw water) -
Page 15: Startup Instructions
STARTUP INSTRUCTIONS 2. Screen Display System initializing When power is supplied to the control, Please wait 1. Connect the Transformer to the Valve MENU the screen will display “INITIALIZING WAIT PLEASE” Plug the 12-volt transformer into a 120 VAC 60 Hz outlet. while it finds the service position. - Page 16 NOTE** All units are factory programmed for the correct size and regeneration cycle alteration should only be done by a factory trained technician or after consultation with one of our technical representatives if you have any questions please contact: Evince® Direct Phone Number: 951.734.7400 Service Related Matters: customerservice@Evincewater.com General questions: info@Evincewater.com...
-
Page 17: During Regeneration / Plumbing System Clean-Up
DURING REGENERATION Automatic Water Bypass The regeneration cycle lasts approximately 1.5 hours to 3.0 hours depending on the specific model, after which treated water service will be restored. During regeneration, untreated water is automatically bypassed for use in the household. Hot water should be used as little as possible during this time to prevent hard water from filling the water heater. -
Page 18: Maintenance Instructions And Schedule
MAINTENANCE INSTRUCTIONS AND SCHEDULE System Check List NOTE** All units are factory programmed for the correct size and regeneration cycle alteration should only be done by a factory trained technician or after consultation with one of our technical representatives if you have any questions please call: 951.734.7400 4a. -
Page 19: Important Warranty And Maintenance Information
MAINTENANCE INSTRUCTIONS AND SCHEDULE Checking the Sodium Chloride Level Check the Sodium Chloride level monthly. Remove the lid from the cabinet or brine tank, make sure Sodium Chloride level is CAUTION! always above the brine level. Add Sodium Chloride to the Brine Tank Incorrect start up, water Put 40 kgs of crystal water conditioner Sodium Chloride in the brine tank. -
Page 20: Res-Up® Feeder Installation Instructions (Optional)
Care of Your Conditioner To retain the attractive appearance of your new water conditioner, clean occasionally with a mild soap solution. Do not use abrasive cleaners, ammonia or solvents. Never subject your conditioner to freezing or to temperatures above 43°C (110°F). Servicing Components Ÿ The injector assembly should be cleaned or replaced every year depending on the inlet water quality and water usage. -
Page 21: Servicing Evince Elevate Valve
Insert the other end of the tube completely into the hole in the brine well cap. Automatic feeding will start in a few hours. SERVICING EVINCE ELITE VALVE Before Servicing 1. Turn off water supply to conditioner : a. If the conditioner installation has a 3 valve bypass system first open the valve in the bypass line, then close the valves at the conditioner inlet & outlet. -
Page 22: Master Programming
MASTER PROGRAMMING Below is how the settings are set at factory: PRESS MENU KEY AND SCROLL TO ‘MAIN MENU’ . THEN PRESS ‘SET’ TILL IT BEEPS. PRESS ‘+’ AND ‘-’ FOR 8 SECONDS SCROLL TO ADVANCED MENU Sodium VS AUTO RESIN REGEN BW/rinse... - Page 23 Dealer Information Dealer Information Main Menu Main Menu = = Dealer Information = = = = Date and Time = = Evince® Water Technol - 17 - Feb - 2018 ogies 12:25PM 108 Business Center Dr, Press To Cancel Corona, CA 92880, USA...
-
Page 24: Diagnostic Screen
Diagnostic Screen PRESS “MENU” KEY AND SCROLL TO “MAIN MENU”. THEN PRESS “SET” TILL IT BEEPS. SCROLL TO ADVANCED MENU Press Menu key . Press - to advance to Main Menu. Press SET Press Menu key and scroll or until you hear a beep. Press - to advance to Advanced Menu to Main Menu. -
Page 25: Replace Piston And/Or Brine Valve Assembly / Clean Injector Assembly
REPLACE PISTON AND/OR BRINE VALVE ASSEMBLY Piston Remove 4 X Assembly Seal and Screws Spacer Plate Brine Valve Assembly 1. Follow steps 1 to 6 of 3. Remove the plate from the valve body and pull the Piston 5. Replace piston assembly followed by timer assembly. timer /Powerhead replacement. -
Page 26: Replace Timer / Replace Motor
REPLACE TIMER 4 X Screws Meter Cable Front Cover 1. Disconnect the meter cable from the meter. (If flow 2. Remove four screws from the back of the valve cover 3. Remove the front cover of the valve. meter is attached) 2 X Screws from Powerhead Powerhead Piston Screw... -
Page 27: Replacing The Bypass And Meter Cable
REPLACING THE BYPASS AND METER CABLE Grey Meter Cable 60010267 Bypass comes with Meter 60095101 and Grey Meter Cable Step 1 Step 2* Disconnect the meter cable from Unplug the Remove 2 screws and the bypass. clips from bypass. power from the wall socket. -
Page 28: Display Replacement / Replace Microswitches
DISPLAY REPLACEMENT 1. Remove the screws from the back of the valve and pull the front cover 2. Remove all connections from the circuit board 3. Remove the four screws from the circuit board and pull it out REPLACE MICROSWITCHES Front Cover 4X Screws Microswitches... -
Page 29: Replace Drain Line Flow Control /Replace Brine Line Flow Control
REPLACE DRAIN LINE FLOW CONTROL Drain Line Washer Clip 1. Pull the drain line clip and remove the drain line elbow Drain Line Elbow and washer 2. Clean/replace drain line washer REPLACE BRINE LINE FLOW CONTROL Clip Brine Line Washer 1. -
Page 30: Parts Breakdown
PARTS BREAKDOWN Part # Control Valve Straight Connector 1” - 60010068 60090003 Part # Elbow Connector 1” - 60010012S 60090026 Part # 18280 Tank 1 Tank 2 Pipe connector - 14” - 18” / 8” - 12” Tanks Red Clips (4pcs) O Ring / 1”... -
Page 31: Powerhead
Locating wheel(UF) 05056141B Washer on Locating Wheel 05033004 Screw 2.2×13 05056166B Screw on Locating Wheel 05041011 Micro Switch 13000332 Screws on Micro Switch 13000401 Screws on PCB 92388 05033008B 05033027 PCB Absorb Shock Foam 05033011F Front Cover(White) 05033007E Controller Touch Panel(Evince®) -
Page 32: 89 Valve Body
PARTS BREAKDOWN Parts list of control valve body: Part # Part # Description (Water Group) (Canature) 60010184 21389033 Brine Line Elbow Nut 60010172 30020013M Brine Line Elbow 60010044 05056134 O-ring of Brine Line Elbow 60010188 05031033 O-ring of BLFC Holder 60010173 05031010M BLFC Holder... -
Page 33: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE SOLUTIONS 1. CONDITIONER DELIVERS HARD WATER A. Close bypass valve A. Bypass valve is open B. Add sodium to brine tank and maintain sodium level above water level B. No sodium in brine tank C. Replace injectors and screen C. -
Page 34: Master Programming Guide
TROUBLE SHOOTING GUIDE Problem Possible Solutions 11. DRAIN FLOWS CONTINUOUSLY A. Remove piston assembly and inspect bore. Remove foreign material and check control in various regeneration positions A. Foreign material in control B. Replace seals and/or piston assembly B. Internal control leak C. - Page 35 MASTER PROGRAMMING GUIDE (CONTINUED) MASTER PROGRAMMING - DYNAMIC Master Programming (V1.5) PRESS MENU KEY AND SCROLL TO ‘MAIN MENU’. THEN PRESS ‘SET’ TILL IT BEEPS. SCROLL TO ADVANCED MENU BRINE BACK WASH RINSE BRINE AUXILIARY SERVICE BACKLIGHT HISTORY SODIUM ALARM SODIUM RINSE REFILL...
- Page 36 ADVANCED MENU DYNAMIC PRESS “MENU” KEY . PRESS - TO ADVANCE TO MENU PRESS “MENU” KEY AND SCROLL TO “MAIN MENU MENU ADVANCED MENU. PRESS AND HOLD “SET” MENU MENU”. THEN PRESS “SET” TILL IT BEEPS. SECONDS OR UNTIL YOU HEAR A BEEP. PRESS MENU MENU SCROLL TO ADVANCED MENU...
- Page 37 ADVANCED MENU DYNAMIC MENU Press “MENU” key . Press - to advance to Advanced Menu. Press and hold “SET” MENU MENU seconds or until you hear a beep. Press to choose menu option. Press “SET” MENU MENU MENU MENU to enter. Press to change option.
- Page 38 HOW TO SET DATE AND TIME, MANUAL REGENERATION AND DEALER INFORMATION MENU PRESS “MENU” KEY AND SCROLL TO “MAIN MENU”. THEN PRESS “SET” TILL IT BEEPS. MENU Press “MENU” key MENU PRESS “MENU” KEY AND SCROLL TO “MAIN MENU”. THEN MENU MENU Press...
- Page 41 Life Time Warranty on Mineral Tanks and Brine Tanks Evince® will provide a replacement mineral tank or brine tank to any original equipment purchaser in possession of a tank that fails provided that the water conditioner is at all times operated in accordance with specifications and not subject to freezing or vacuum.
