19.4.7 Blue & NIR Treatment
Button/ ID Function Requirement
Press the BLUE button to activate blue LED's.
2
This is indicated by the button illuminating in blue.
4 Press the NIR button to activate near infra-red LED's.
This is indicated by the button illuminating in yellow.
In the BLUE & NIR TREATMENT screen, if the PLAY button
5
is pressed the treatment is in progress or paused.
Figure 13: Controller Overview for Blue & NIR Treatment.
* Navigation: Home - Blue & NIR Treatment
PL-027 (Rev 7)
32
19.4.8 Red & NIR Treatment
Button/ ID Function Requirement
Press the RED button to activate red LED's.
3
This is indicated by the button illuminating in red.
Press the NIR button to activate near infra-red LED's.
4
This is indicated by the button illuminating in yellow.
In the RED & NIR TREATMENT screen, if the PLAY button is
5
pressed the treatment is in progress or paused.
Figure 14: Controller Overview for Red & NIR Treatment.
* Navigation: Home - Red & NIR Treatment
