19.4.3 Red 633nm Treatment

Button/ ID Function Requirement
Press the RED button to activate the red LED's.
3
This is indicated by the button illuminating in red.
In the RED TREATMENT screen, if the PLAY button is
5
pressed the treatment is in progress or Paused.
Figure 9: Controller Overview for Red Treatment.
* Navigation: Home - Red Treatment
PL-027 (Rev 7)
28

19.4.4 Blue 415nm Treatment

Button/ ID Function Requirement
Press the BLUE button to activate the blue LED's.
2
This is indicated by the button illuminating in blue.
In the BLUE TREATMENT screen, if the PLAY button is
5
pressed the treatment is in progress or paused.
Figure 10: Controller Overview for Blue Treatment.
* Navigation: Home - Blue Treatment
