A+ Server
AS -2024S-TR
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro AS -2024S-TR

Summary of Contents for Supermicro AS -2024S-TR

  • Page 1 A+ Server AS -2024S-TR USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 A+ Server AS -2024S-TR. Installation and maintenance should be performed by experienced technicians only. Please refer to the AS -2024S-TR server specifications page on our website for updates on supported memory, processors and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................12 Drive Carrier Indicators ....................12 Rear Features ........................13 Power Supply Indicators ....................14 1.5 Motherboard Layout ......................15 Quick Reference Table ......................16 Chapter 2 Server Installation 2.1 Overview ..........................19...
  • Page 5 A+ Server AS -2024S-TR User's Manual Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................28 3.2 Accessing the System ......................29 Removing the Top Cover ....................29 3.3 Motherboard Components ....................30 Processor and Heatsink Installation ..................30 Memory Support ........................37 Memory Support ......................37 DIMM Module Population ....................38...
  • Page 6 Preface Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................66 5.2 Driver Installation ........................68 5.3 SuperDoctor 5 ........................69 ® 5.4 BMC ............................70 BMC ADMIN User Password ....................70 Chapter 6 UEFI BIOS 6.1 Introduction .........................71 Starting the Setup Utility ....................71 6.2 Main Setup .........................72 6.3 Advanced ..........................74 6.4 IPMI ............................93 6.5 Event Logs .........................96...
  • Page 7 A+ Server AS -2024S-TR User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Overview

    Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the AS -2024S-TR. The AS -2024S-TR is based on the H12DSi-N6 motherboard and the CSE-LA26TS-R920LPP1 chassis. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the AS -2024S-TR. Please refer to Appendix C for additional specifications. System Features Motherboard H12DSi-N6 Chassis CSE-LA26TS-R920LPP1 Dual AMD EPYC™ 7002/7003 Series Processors...

  • Page 10: Server Chassis Features

    A+ Server AS -2024S-TR User's Manual 1.4 Server Chassis Features Control Panel Power buttons and status LEDs are located on the control panel at the front of the chassis. The locations and descriptions of these buttons and LEDs are provided below. See Chapter 4 for details on the control panel connections.
  • Page 11 Chapter 1: Introduction Information LED Color, Status Description Red, solid An overheat condition has occurred. Red, blinking at 1Hz Fan failure, check for an inoperative fan. Red, blinking at 0.25Hz Power failure, check for a non-operational power supply. Red, solid, with Power LED blinking green Fault detected Blue and red, blinking at 10 Hz Recovery mode...

  • Page 12: Front Features

    A+ Server AS -2024S-TR User's Manual Front Features The CSE-LA26TS-R920LPP1 is a 2U chassis See the illustration below for the features included on the front of the chassis. Control Panel Service/Asset Tag with BMC Password Figure 1-2. System Front View...

  • Page 13: Rear Features

    Chapter 1: Introduction Rear Features The illustration below shows the features included on the rear of the chassis. The power supply modules also have status LEDs (see Chapter 3 for details). IPMI LAN Port UID LED VGA Port CPU1 CPU2 USB Ports LAN Ports Power Supplies...

  • Page 14: Power Supply Indicators

    Indicates that the power supply has a warning condition and continues to operate. Indicates that the power supply is plugged in, and is in an abnormal state. The Solid Amber system might need service. Please contact Supermicro technical support. No AC power to modules...

  • Page 15: Motherboard Layout

    Chapter 1: Introduction 1.5 Motherboard Layout Below is a layout of the H12DSi-N6 with jumper, connector and LED locations shown. See the table on the following pages for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4. UID_SW JLAN2 JLAN1...

  • Page 16: Quick Reference Table

    A+ Server AS -2024S-TR User's Manual Quick Reference Table Jumper Description Default Setting JBT1 Clear CMOS Open (Normal) Power LED and Speaker/Buzzer Pins 4-7 JPFR1 Manufacturer Mode Open (Normal) JPFR3 PFR Function Open (Normal) JPL1 Onboard LAN Enable/Disable Pins 1-2 (Enabled)
  • Page 17 Connector Description SATA0-7 Onboard SATA3 Ports SGPIO1/2 Serial General Purpose I/O Ports 1/2 Slot1- Slot6 PCIe Expansion Card Slots SUPERDOM1/2 Supermicro SATA3 DOM Ports UID_SW UID Switch (push-button to toggle UID on/off) USB1 Rear USB 2.0 Ports (USB1/USB2) VGA Port...
  • Page 18 A+ Server AS -2024S-TR User's Manual 64MB BMC RJ45 x 2 Flash 25 MHz -NT6 DDR4 DDR4 256MB RGMII 1000BASE-T 125 MHz RTL8211F-CG 250 MHz RS232 2 x USB 2.0 480 Mbps 33 MHz PCIe 2.0 x1 5.0 GT/s HEADER PCIe 3.0 x4...

  • Page 19: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 20: Rack Precautions

    A+ Server AS -2024S-TR User's Manual Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.

  • Page 21: Mechanical Loading

    Chapter 2: Server Installation Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 22: Installing The Rails

    A+ Server AS -2024S-TR User's Manual 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. This rail set fits a rack between 26.8" and 36.4" deep. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 23: Releasing The Inner Rail

    Chapter 2: Server Installation Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. Releasing Inner Rail from the Outer Rails 1.

  • Page 24: Installing The Inner Rails On The Chassis

    A+ Server AS -2024S-TR User's Manual Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 25: Installing The Outer Rails Onto The Rack

    Chapter 2: Server Installation Installing the Outer Rails onto the Rack 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks on the front of the outer rail onto the square holes on the front of the rack.

  • Page 26: Installing The Server Into The Rack

    A+ Server AS -2024S-TR User's Manual 2.4 Installing the Server into the Rack Once rails are attached to the chassis and the rack, you can install the server. 1. Pull the middle rail out of the front of the outer rail and make sure that the ball bearing shuttle is locked at the front of the middle rail.

  • Page 27: Removing The Chassis From The Rack

    Chapter 2: Server Installation Removing the Chassis from the Rack Caution! It is dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have sufficient assistance supporting the chassis when removing it from the rack.

  • Page 28: Chapter 3 Maintenance And Component Installation

    A+ Server AS -2024S-TR User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 29: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The system features a removable top cover, which allows access to the inside of the system. Removing the Top Cover 1. Press the two release buttons and slide the cover toward the rear. 2.

  • Page 30: Motherboard Components

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing the Processor and Heatsink 1. Unscrew the screws holding down Force Frame in the sequence of 3-2-1. The screws are numbered on the force frame next to each screw hole.
  • Page 31 Chapter 3: Maintenance and Component Installation 2. The spring-loaded force frame will raise up after the last screw securing it (#1) is removed. Gently allow it to lift up to its stopping position. 3. Lift the rail frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the rail frame, lift it to a position so you can do the next step of removing the external cap.
  • Page 32 A+ Server AS -2024S-TR User's Manual 4. Remove the external cap from the Rail Frame by pulling it upwards through the rail guides on the rail frame. External Cap PnP Cover Cap 5. The CPU package is shipped from the factory with the blue carrier frame pre-assembled.
  • Page 33 Chapter 3: Maintenance and Component Installation Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the rail frame plate.
  • Page 34 A+ Server AS -2024S-TR User's Manual 9. Gently lower the force frame down onto the rail frame and hold it in place until it is seated in the Socket housing. Note that the force frame is spring loaded and has to be held in place before it is secured.
  • Page 35 Chapter 3: Maintenance and Component Installation 11. After the force frame is secured and the CPU package is in place, now you must install the heatsink to the frame. Lower the heatsink down till it rests securely over the four screw holes on CPU package on the socket frame.
  • Page 36 A+ Server AS -2024S-TR User's Manual Un-installing the Processor and Heatsink 1. Remove the heatsink attached to the top of the CPU package by reversing the installation procedure. 2. Clean the Thermal grease left by the heatsink on the CPU package lid to limit the risk of it contaminating the CPU package land pads or contacts in the socket housing.

  • Page 37: Memory Support

    Chapter 3: Maintenance and Component Installation Memory Support Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The H12DSi-N6 supports up to 4TB of registered ECC DDR4-3200 SDRAM in 16 DIMM slots.

  • Page 38: Dimm Module Population

    A+ Server AS -2024S-TR User's Manual DIMM Module Population When installing memory, please keep the following in mind: • It is recommended that DDR4 DIMM modules of the same type, size and speed should be installed. • Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the slowest DIMM.

  • Page 39: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Follow the instructions given in the memory population guidelines listed in the previous sections to install memory modules on your motherboard. For the system to work properly, please use memory modules of the same type and speed on the motherboard.

  • Page 40: Pci Expansion Cards

    A+ Server AS -2024S-TR User's Manual PCI Expansion Cards The system can accommodate six PCIe 4.0 expansion cards as noted below. CPU1 CPU2 Figure 3-3. Expansion Card Slots Expansion Slot Descriptions Item Description PCIe 4.0 x8 (low-profile) PCIe 4.0 x16 (low-profile) PCIe 4.0 x8 (low-profile)

  • Page 41: Installing Expansion Cards

    Chapter 3: Maintenance and Component Installation Installing Expansion Cards 1. Power down the system and remove the cover. 2. In the rear of the chassis, remove the blank PCI shields that covers the chassis slot. 3. Mount the riser card onto the bracket (if not already mounted) using four screws. 4.

  • Page 42: Motherboard Battery

    A+ Server AS -2024S-TR User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1.

  • Page 43: Chassis Components

    NVMe or SAS/SATA drives. Drive carrier status indicators are described in Section 1.2 Note: Enterprise level hard disk drives are recommended for use in Supermicro servers. For compatible storage drives, see the AS -2024S-TR server web page.
  • Page 44 A+ Server AS -2024S-TR User's Manual Removing a Hot-Swap Drive Carrier from the System 1. Press the release button on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis.
  • Page 45 Chapter 3: Maintenance and Component Installation Installing a 3.5" Drive 1. Position the drive above the carrier with the PCB side facing down and the connector end toward the rear of the carrier. 2. Tilt the drive to insert it onto the two posts on the left inside of the carrier. Post Insert this side first Post...
  • Page 46 A+ Server AS -2024S-TR User's Manual Insert this side second Figure 3-9. Installing a 3.5" Drive into a Carrier Installing a 2.5" Drive 1. Install the drive directly into the tray with four screws underneath. 2. Insert the drive carrier into its bay, keeping the release button on the right. When the carrier reaches the rear of the bay, the release handle will retract.

  • Page 47: Hot-Swap For Nvme Drives

    Chapter 3: Maintenance and Component Installation Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Ejecting a Drive 1. IPMI > Storage > Physical View 2.

  • Page 48: System Cooling

    A+ Server AS -2024S-TR User's Manual System Cooling Three 8-cm fans provide the cooling for the system. Make sure the chassis top cover makes a good seal so the cooling air circulates properly through the chassis. Fan speed is controlled by system temperature via BMC. If a fan fails, the remaining fans will ramp up to full speed and the overheat/fan fail LED on the control panel will turn on.

  • Page 49: Air Shroud

    Chapter 3: Maintenance and Component Installation Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. The AS -2024S-TR includes a single air shroud, which covers the CPU and memory area of the motherboard. Installing the Air Shroud 1. Power down the system as described in Section 3.1.

  • Page 50: Checking The Server Air Flow

    A+ Server AS -2024S-TR User's Manual Checking the Server Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. • Do not operate the server without drives or drive trays in the drive bays.

  • Page 51: Power Supply

    Power Supply The chassis features redundant power supplies. The power modules can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120v or 180-240v.
  • Page 52 A+ Server AS -2024S-TR User's Manual Handle Release Tab Figure 3-14. Installing a Power Supply Module...

  • Page 53: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 54: Headers And Connectors

    A+ Server AS -2024S-TR User's Manual +12V 8-pin Auxilliary Power Connectors JPWR1 and JPWR2 are 8-pin ATX power inputs to provide auxiliary power to the processors that are installed in the system. Refer to the table below for pin definitions.
  • Page 55 NGFF). This particular PCIe M.2 supports M-Key (PCIe x4) storage cards. Form factors 2280 and 22110 are supported. SuperDOM The SUPERDOM1 and SUPERDOM2 ports are Supermicro SATA DOM (Disk on Module) ports. SuperDOM, is a small SATA3 (6Gb/s) flash memory module that conveniently inserts directly into the mothrboard.
  • Page 56 A+ Server AS -2024S-TR User's Manual TPM Header/Port 80 Connector (TPM Port) The JTPM1 and JTPM2 headers are used to connect a Trusted Platform Module (TPM), which is available from a third-party vendor. A TPM is a security device that supports encryption and authentication in hard drives.
  • Page 57 Chapter 4: Motherboard Connections SGPIO Headers The SGPIO1 and SGPIO2 (Serial General Purpose Input/Output) headers are used to communicate with the enclosure management chip on the backplane. SGPIO Headers Pin Definitions Pin# Definition Pin# Definition Ground DATA IN Ground DATA Out Load Ground Clock...

  • Page 58: Control Panel

    A+ Server AS -2024S-TR User's Manual Control Panel JF1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.
  • Page 59 Chapter 4: Motherboard Connections Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Power Fail LED Pin Definitions (JF1) Pin# Definition 3.3V PWR Supply Fail OH/Fan Fail LED The Overheat (OH) / Fan Fail LED is located on pin 8 of JF1. When this is on, it indicates that there is a system overheat or the internal fan(s) have failed.
  • Page 60 A+ Server AS -2024S-TR User's Manual Power LED The Power LED connection is located on pins 15 and 16 of JF1. Power LED Pin Definitions (JF1) Pin# Definition 3.3V Power LED NMI Button The non-maskable interrupt button header is located on pins 19 and 20 of JF1.

  • Page 61: Ports

    Chapter 4: Motherboard Connections 4.3 Ports Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-2. Rear I/O Ports Rear I/O Ports Description Description COM Port LAN1 Port* IPMI LAN Port LAN2 Port*...

  • Page 62: Jumpers

    A+ Server AS -2024S-TR User's Manual 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 63 Chapter 4: Motherboard Connections Watch Dog (JWD1) JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 64: Led Indicators

    A+ Server AS -2024S-TR User's Manual 4.5 LED Indicators LAN Port LEDs The LAN ports have two LED indicators. The Activity LED is yellow and the Link LED may be green, amber, or off to indicate the speed of the connection. Refer to the tables below for more information.
  • Page 65 LED turns on when initiated via the UID Switch or IPMI to easily identify a system in a rack. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com...

  • Page 66: Chapter 5 Software

    If you will be using RAID, you must configure RAID settings before installing the Windows OS and the RAID driver. Refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Please note that RAID is not natively supported, a RAID controller card is required.
  • Page 67 Chapter 5: Software 3. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 68: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 69: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 70: Bmc

    A+ Server AS -2024S-TR User's Manual 5.4 BMC The motherboard provides remote access, monitoring and management through the baseboard management controller (BMC) and other management controllers distributed among different system modules. There are several BIOS settings that are related to BMC.

  • Page 71: Chapter 6 Uefi Bios

    Chapter 6: UEFI BIOS Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for H12DSi-N6 motherboards that are equipped with the AMD EPYC™ 7003/7002 Series processor. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 72: Main Setup

    A+ Server AS -2024S-TR User's Manual 6.2 Main Setup When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The Main BIOS setup screen is shown below.
  • Page 73 Chapter 6: UEFI BIOS Build Date This item displays the date when the version of the BIOS ROM used in the system was built. CPLD Version This item displays the CPLD version of the BIOS ROM used in the system. Memory Information Total Memory This feature displays the total system memory detected.

  • Page 74: Advanced

    A+ Server AS -2024S-TR User's Manual 6.3 Advanced Use the arrow keys to select a top item and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 75 Chapter 6: UEFI BIOS Bootup NumLock State Use this feature to set the Power on state for the <Numlock> key. The options are On and Off. Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 76 A+ Server AS -2024S-TR User's Manual Trusted Computing Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM (Trusted Platform Module) support to enhance data integrity and network security.
  • Page 77 Chapter 6: UEFI BIOS ACPI SRAT L3 Cache As NUMA Domain Use this setting to enable/disable ACPI SRAT L3 Cache As NUMA Domain. The options are Disabled, Enabled, and Auto. Super IO Configuration The following Super IO information will display: •...
  • Page 78 A+ Server AS -2024S-TR User's Manual Serial Port Console Redirection COM1 Console Redirection Select Enabled to enable console redirection support for a serial port specified by the user. The options are Disabled and Enabled. *If the item above set to Enabled, the following items will become available for user's configuration: Console Redirection Settings...
  • Page 79 Chapter 6: UEFI BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 80 A+ Server AS -2024S-TR User's Manual Redirection After BIOS POST Use this feature to enable or disable legacy Console Redirection after BIOS POST. When set to Bootloader, legacy Console Redirection is disabled before booting the OS. When set to Always Enable, legacy Console Redirection remains enabled when booting the OS.
  • Page 81 Chapter 6: UEFI BIOS Data Bits EMS Use this feature to set the data transmission size for Console Redirection. The options are 7 Bits and 8 Bits. Parity EMS A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even.
  • Page 82 A+ Server AS -2024S-TR User's Manual L1 Stream HW Prefetcher / L2 Stream HW Prefetcher This setting is used to enable or disable the L1/L2 Stream Hardware Prefetcher. The options are Disabled, Enabled, and Auto. SMEE This feature sets the option to enable or disable Secure Memory Encryption. The options are Disabled and Enabled.
  • Page 83 Chapter 6: UEFI BIOS Preferred IO Options include Manual and Auto. EDC Control Electrical Design Current (EDC) is the total current capacity in amps that can be supplied to the socket. Auto = use the fused VDDCR_CPU EDC limit. Manual = user can set a customized VDDCR_CPU EDC limit.
  • Page 84 A+ Server AS -2024S-TR User's Manual CPU1/2 Memory Information These sections are for informational purposes. They will display details about the detected memory according to the CPU, such as: • Detected Size (per slot, in MB) • Current Speed (MT/s) PCIe/PCI/PnP Configuration...
  • Page 85 Chapter 6: UEFI BIOS VGA Priority Use this setting to select between onboard or offboard VGA support. The options are Onboard and Offboard NVMe Firmware Source Use this setting to select between the AMI Native firmware support or the device vendor- defined firmware support.
  • Page 86 A+ Server AS -2024S-TR User's Manual Onboard NVMe4 Option ROM Select which firmware function is to be loaded for onboard NVMe4. The options include Disabled and EFI. Onboard Video Option ROM Select Legacy to boot the system using a legacy video device installed on the motherboard.
  • Page 87 Chapter 6: UEFI BIOS Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which in turn, will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices. The options are Enabled, and Disabled. Network Configuration Network Stack This setting allows you to Disable or Enable the UEFI Network Stack.
  • Page 88 A+ Server AS -2024S-TR User's Manual  MAC:3CDCEF76D89F-IPv6 Network Configuration This setting allows you configure the network parameters for the listed MAC address. SATA Configuration This section displays the detected SATA devices installed on the system. SATA Information SATA Enable This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
  • Page 89 Chapter 6: UEFI BIOS HTTP Boot Configuration HTTP Boot Policy Sets the HTTP boot policy to Apply to all LANs, Apply to each LAN, or Boot Priority #1 instantly. Instance of Priority 1 Default to 1. Select IPv4 or IPv6 Choose to set the targeted LAN port to boot from IPv4 or IPv4.
  • Page 90 A+ Server AS -2024S-TR User's Manual MBA Configuration Menu Legacy Boot Protocol Selects the non-UEFI boot protocol. Options are PXE, iSCSI, and None. Boot Strap Type Selects the boot strap type. Options are Auto Detect, BBS, Int 18h, and Int 19h.
  • Page 91 Chapter 6: UEFI BIOS DHCP Vendor ID Configures DHCP vendor ID (up to 32 bytes long). Link Up Delay Time Configures link up delay time in seconds (0 to 255). Use TCP Timestamp Enables or Disables TCP timestamp. Options are Disabled and Enabled. Target as First HDD Enables or Disables target appearing as first HDD in the system.
  • Page 92 A+ Server AS -2024S-TR User's Manual TLS Authenticate Configuration This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification using File Use this feature to enroll certification from a file. Certification GUID Use this feature to input the certification GUID.

  • Page 93: Ipmi

    Chapter 6: UEFI BIOS 6.4 IPMI This tab allows you to configure the following IPMI settings for the system. Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI STATUS This item indicates the status of the IPMI firmware installed in your system.
  • Page 94 A+ Server AS -2024S-TR User's Manual Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
  • Page 95 Chapter 6: UEFI BIOS Station MAC Address This item displays the Station MAC address for this computer. Mac addresses are 6 two- digit hexadecimal numbers. Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1).

  • Page 96: Event Logs

    A+ Server AS -2024S-TR User's Manual 6.5 Event Logs This tab allows the user to configure the following event logs settings for the system. Enabling/Disabling Options Change SMBIOS Event Log Settings Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 97 Chapter 6: UEFI BIOS When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events.

  • Page 98: Security

    A+ Server AS -2024S-TR User's Manual 6.6 Security This tab allows you to configure the following security settings for the system. Administrator Password Press Enter to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well.
  • Page 99 Chapter 6: UEFI BIOS Security Function Options are Disabled, Set Password, Security erase - Password, and Security Erase -0 Without Password. . Password Set the password here.

  • Page 100: Boot

    A+ Server AS -2024S-TR User's Manual 6.7 Boot Use this tab to configure Boot Settings: Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are Legacy, UEFI, and Dual.
  • Page 101 Chapter 6: UEFI BIOS Add New Boot Option Use this feature to add a pre-defined boot device from which the system will boot during startup. Delete Boot Option Use this feature to remove a pre-defined boot device from which the system will boot during startup.

  • Page 102: Save & Exit

    A+ Server AS -2024S-TR User's Manual 6.8 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 103 Chapter 6: UEFI BIOS Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility Program. Default Options Restore Optimized Defaults To set this feature, select Restore Optimized Defaults from the Save & Exit menu and press <Enter>.

  • Page 104: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 105 Appendix A: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 106 A+ Server AS -2024S-TR User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 107 Appendix A: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 108 A+ Server AS -2024S-TR User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 109 Appendix A: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 110 A+ Server AS -2024S-TR User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬...
  • Page 111 Appendix A: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 112 A+ Server AS -2024S-TR User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 113 Appendix A: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 114 A+ Server AS -2024S-TR User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가...
  • Page 115 Appendix A: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 116 A+ Server AS -2024S-TR User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 117 Appendix A: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 118 A+ Server AS -2024S-TR User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 119 Appendix A: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 120 A+ Server AS -2024S-TR User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 121 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 122 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 123 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 124: Appendix B Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 125 Appendix C: UEFI BIOS Recovery Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into a USB flash device and rename it "Super.ROM". 2. While the system is turned off, insert the USB device that contains the new BIOS binary image (SUPER.ROM).
  • Page 126 • SUPERMICO BIOS Update: https://www.youtube.com/watch?v=S8z6iOEHGwY • If the BIOS flash recovery fails, contact our RMA Department to have the BIOS chip reprogrammed. This will require shipping the board to Supermicro for repair. • Submit your RMA request at https://www.supermicro.com/support/rma •...

  • Page 127: Appendix C System Specifications

    Appendix C: System Specifications Appendix C System Specifications Processor Support Dual AMD EPYC™ 7002/7003 Series Processors in SP3 type sockets Notes: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset System on Chip BIOS 256Mb SPI AMI BIOS ®...
  • Page 128 A+ Server AS -2024S-TR User's Manual Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032...
