Installation Guide
For DC Electric Thruster Models
SE80, SE100, SE120, SE130, SE150
DOCUMENT ID:
2687
REVISION:
23
DATE:
2022
EN
LANGUAGE:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE80 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sleipner SE80

  • Page 1 Installation Guide For DC Electric Thruster Models SE80, SE100, SE120, SE130, SE150 DOCUMENT ID: SLEIPNER MOTOR AS 2687 REVISION: P.O. Box 519 DATE: N-1612 Fredrikstad 2022 Norway LANGUAGE: www.sleipnergroup.com...
  • Page 2: Table Of Contents

    SE100/185T-12V - SE100 Tunnel thruster, 12V SE80/185T-24V - SE80 Tunnel thruster, 24V SE80/185T-12V - SE80 Tunnel thruster, 12V Sleipner Motor AS P.O. Box 519, Arne Svendsensgt. 6-8 N-1612 Fredrikstad, Norway MC_0020 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 3: Responsibility Of The Installer

    Sleipner products. The recommendations given in this document are guidelines ONLY, and Sleipner strongly recommends that advice is obtained from a person familiar with the particular vessel and applicable regulations.
  • Page 4: Product Measurements

    *Valid for SE & SEP Propeller position will vary with each thruster model Twin Propeller The gear leg/ propeller(s) must never extend out of the tunnel Tunnel centre line MG_0075 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 5: Product Specifications

    150 kg / 330 lbs (21V) 8.8 kW / 11.8 hp 38 kg / 79 lbs * SE and SE-IP are measured at motor terminals when the thruster is operated for on/off thrusters SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 6: Positioning Of The Tunnel / Thruster

    (NB: This can be overlooked depending on the installation methods defi ned in this manual.) Pivot point important Lowered rotation power performance Stronger rotation power performance Water line Ø min 1/4 Ø (Recommended) min 1/4 Ø (Recommended) MG_0001 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 7: Tunnel Length

    Increase tunnel length to protect never extend out of the tunnel cavity between the propeller and the propeller from water forces the hull of the boat. when high-speed cruising. MG_0048 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 8: Tunnel Installation In Sailboats

    This can also be an installation method for flat bottomed barges to avoid extremely long tunnels and large oval tunnel openings in the hull.   Pos. A Pos. B MG_0004 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 9: Water Deflection

    High water force event when the boat is traveling at high speeds it while underway will commonly pound upon the water surface. High water force while underway from wave contact MG_0003 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 10: Tunnel Ends

    (NB: A Side-power thruster propeller does not produce cavitation at working speed. Therefore, any cavitation and cavitation noise in the tunnel will be caused during improper tunnel installation.) R = 0,1 x D (10%) Cavitation   Angled tunnel ends for steel/ aluminium hulls MG_0002 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 11: Tunnel Installation

    fi breglass, a resin/ fi breglass mixture must be used in that area.) 8 x layers of fiberglass and resin 8 x layers of fiberglass and resin MG_0005 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 12 *Fiberglass *Steel/ Hull Aluminium Hull Hull R = D x 0,1 Layers of fiberglass R = D x 0,1 and resin Tunnel Additional Layers of fiberglass and resin MG_0006 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 13: Stern Tunnel Installation

    Stern Tunnel Installation MC_0003 For Stern Thruster installation please refer to the supplied manual in your Sleipner product delivery Installation Guide For DC Electric Thruster Models SE80, SE100, SE120, SE130, SE150 Stern Thruster SLEIPNER AS DOCUMENT ID: 222222 REVISION: P.O. Box 519...
  • Page 14: Gear Leg & Motor Bracket Installation

    *P*IP *P*IP IMPORTANT FASTEN Do not apply sealant to 18 Nm (13.28 lb/ft) the holes. Motor bracket *P*IP *P*IP *P*IP *P*IP *P*IP FASTEN 33 Nm (24 lb/ft) MG_0055 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 15: Propeller Installation

    Apply anti-fouling to the gear leg and propeller. Do not apply anti-fouling to any rubber elements of the gear leg or anodes. Drive Pin Propeller Washer Lock Nut Anti-fouling Anode Apply Loctite 243 or similar Anode Holding Screw MG_0033 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 16: Motor Installation

    Ensure the holding key and coupling are aligned when fitted Holding Key > 30° Motor FASTEN (33 Nm) (24 lb/ft) IMPORTANT Do not position support on the motor cap. Motor support MG_0043 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 17: Electrical Installation

    Do NOT use washers between lugs, this causes overheating Ensure lug faces and fire. Spring washers must be placed in the outer are back to back. position before tightening nut. MG_0533 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 18: Electrical Reference Guide

    2 x 3/0 2 x 3/0 2 x 3/0 2 x 4/0 2 x 4/0 2 x 4/0 24*2 mm² DIN: 400 400-450A 300/300TC SAE: 760 ANL 325 (48V) EN: 680 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 19: Wiring Diagram 12V Thruster

    After all electrical connections have been completed check with an ohm meter that there is no electrical connection between the motor casing and positive terminal on the motor and between the motor casing and the negative terminal on the motor. MG_0567 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 20: Wiring Diagram 24V Thruster

    After all electrical connections have been completed check with an ohm meter that there is no electrical connection between the motor casing and positive terminal on the motor and between the motor casing and the negative terminal on the motor. MG_0578 SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 21: Control Panel Installation

    For Control Panel installation please refer to the Installation Guide accompanying the control panel to be installed. Installation Guide Control Panel SLEIPNER MOTOR AS DOCUMENT ID: REVISION: P.O. Box 519 N-1612 Fredrikstad DATE: Norway www.sleipnergroup.com LANGUAGE: SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 22: Pre-Delivery Checklist

    The compartment for the thruster has been isolated from general bilge water and has no obvious or suspected risks for flooding: .................................................................................................................................. Other comments by installer: ........................................................................................................................SE80 & SE100 & SE120 & SE130 & SE150 2687 2022...
  • Page 23: Service And Support

    11. This warranty gives you specific legal rights, and you may also have other rights which vary from country to country. Patents MC_0024 At Sleipner we continually reinvest to develop and offer the latest technology in marine advancements. To see the many unique designs we have patented visit our website www.sleipnergroup.com/patents SE80 & SE100 & SE120 & SE130 & SE150...
  • Page 24 © Sleipner Group, All rights reserved The information given in the document was right at the time it was published. However, Sleipner Group cannot accept liability for any inaccuracies or omissions it may contain. Continuous product improvement may change the product specifi cations without notice.
