Page 1 D I S H W A S H E R S S O L O SE R V I C E MA N U A L SERIES...
Page 2: Table Of Contents
TABLE OF CONTENTS INTERFACE AND HARDWARE ...................... 4 1.1 Y SERIES W/O DISPLAY(Y11, Y12, Y13,Y14, Y15) ................ 4 1.2 Y SERIES W DISPLAY‐W/O DIVERTER(Y1A, Y1B, Y1C,Y1D, Y1E, Y1F) .......... 4 1.3 Y SERIES W DISPLAY‐W/ DIVERTER(Y21, Y22, Y23,Y24).............. 5 WASHING PROGRAM ........................ 7 2.1 WASHING PROGRAM CROSS TABLE .................... 7 2.2 PROGRAMME SEQUENCES ...................... 8 WASHING SPECIFICATIONS AND PROGRAMS ................ 10 3.1 SELECTING AND STARTING PROGRAM AT POWER ON(BEFORE PROGRAM STARTS) ... 10 3.2 OPENING AND CLOSING DOOR(BEFORE PROGRAM STARTS) .......... 12 3.3 OPENING AND CLOSING DOOR DURING PROGRAM(NOT IN DRY STEPS) ...... 12 3.4 OPENING AND CLOSING DOOR DURING PROGRAM(IN DRY STEPS) ........ 14 3.5 OPENING AND CLOSING DOOR DURING PROGRAM(IN REGENERATION FIRST STEP) .. 14 3.6 OPENING AND CLOSING DOOR DURING PROGRAM(IN REGENERATION SECOND STEP) .. 15 3.7 SELECTING AND STARTING PROGRAM WHEN DOOR IS OPENED(BEFORE PROGRAM STARTS) 16 3.8 TERMINATION OF A PROGRAM(END OF PROGRAM) ............ 17 3.9 CANCELLING OF A PROGRAM(DURING PROGRAM) .............. 17 3.10 IF USER PRESSES ANY BUTTON(AT THE END OF PROGRAM) ........... 18 3.11 MODIFICATION OF A PROGRAM WITHOUT RESET .............. 18 3.12 MODIFICATION OF A PROGRAM WITH RESET ...
Page 3 5.4.1 Delay Timer .......................... 29 5.4.2 Half Load .......................... 30 5.4.3 Tablet (for models with display) .................... 30 5.4.4 Child Lock .......................... 30 5.4.5 Extra Options (for models w/ display) .................. 31 SOFTWARE REQUIREMENTS ...................... 32 6.1 HEATER ............................ 32 6.2 WATER FILL .......................... 32 6.3 WATER DRAIN .......................... 32 6.4 REGENERATION CYCLE ....................... 33 6.5 FEATURE OF TIME PHASE ...................... 34 6.6 VOLTAGE SENSING CONTROL ..................... 35 6.7 NTC VALUES .......................... 36 6.8 WATER HARDNESS SET ....................... 37 SERVICE TEST .......................... 40 7.1 SERVICE FAILURE CODES ...................... 47 FAILURE ROUTINES ........................ 48 8.1 DESCRIPTION OF FAILURES ...
Page 4: Interface And Hardware
1. INTERFACE AND HARDWARE 1.1 Y SERIES W/O DISPLAY(Y11, Y12, Y13,Y14, Y15, Y14_AU,Y13_7,Y15_7,Y1X_W(60CM) The user interface includes:  Program button  Program status with Wash, Rinse, Dry and End leds / Program numbers with 4 leds  Start/Stop and Reset button with 1 led  Delay and Half Load button with integrated led(Half Load led) ...
Page 5: Y Series W Display-W/ Diverter(Y21, Y22, Y23,Y24)
Yı1d AU: 1.3 Y SERIES W DISPLAY‐W/ DIVERTER(Y21, Y22, Y23,Y24,Y21_7,Y22_7,Y23_7,Y24_7) The user interface includes:  Display including Wash, Rinse, Dry and End leds + 3 digits + Program button + Start/Stop/Reset button  Extra button wtih 3 leds(Hygiene led, Rinse led, Dry led)  Delay button with 1 led(Delay led) ...
Page 6 1.5 Y SERIES W DISPLAY‐W/ DIVERTER‐W/BLDC(Y26) The user interface includes:  Display including Wash, Rinse, Dry and End leds + 3 digits + Program button + Start/Stop/Reset button  Extra button wtih 3 leds(Drying, Fast, Silent)  Delay button with 1 led(Delay led)  Half load and Tablet option button with integrated led ...
Page 7: Washing Program
USA ‐ WITH DIVERTER USA 45-60cm YB1-..-YB7 models (Asynchronous) with salt tank: USA 45-60cm YB1-..-YB7 models (Asynchronous) without salt tank: USA 45-60cm YB5-YB6-YB7_B (BLDC) models with salt tank: USA 45-60cm YB5-YB6-YB7_B (BLDC) models without salt tank: 2. WASHING PROGRAM 2.1 WASHING PROGRAM CROSS TABLE Y11 Y12 X ...
Page 8: Programme Sequences
Y1C X X Y1D X X Y1E X X X Y1F/ X X X W Y21 X X X Y22 X X X Y23 X ...
Page 9 P4 Eco 50°C Eco 50°C Eco 50°C Daily 60°C Eco 50°C Eco 50°C P5 Super Daily Normal Super 50’ Super 50’ Super 50’ 50’ 60°C 55°C P6 Intensive Super Daily Auto Dual Dual 65°C 50’ 60°C Delicate Prowash Prowash P7 ‐ Intensive Super Auto Hygiene Hygiene 65°C 50’ Normal 70°C ...
Page 10: Washing Specifications And Programs
3. WASHING SPECIFICATIONS AND PROGRAMS 3.1 SELECTING AND STARTING PROGRAM AT POWER ON(BEFORE PROGRAM STARTS) When the dishwasher is switched on, For models w/o display; COMMANDS Start/Stop Wash Rinse On/Off Switch on Select program ON/OFF* ON/OFF* ON/OFF* ON/OFF* Pressure of Start/Stop button *When user selects a program related program led(s) is ON. After pressing Start/Stop button, related program led(s) is OFF, Wash led is ON.
Page 11 number and 1” duration program are shown alternately Pressure of Start/Stop Duration button program - Default program is “Eco program”. - When the dishwasher is powered off and on again the last executed program and options are not visualized on screen anymore. Each energized of the machine, Eco program is set as default. Note(Y25 &...
Page 12: Opening And Closing Door(Before Program Starts)
For USA models 4 seconds rule: To start the selected program or delay timer, press Start/Pause button and close the door within 4 seconds. If the door is not closed within 4 seconds after Start/Pause button pressed, program / delay timer will be paused. During this 4 seconds, display counts down from 4 to 1.
Page 13 COMMANDS Wash Rinse On/Off Digit Door open ON/OFF ON/OFF Duration program pauses, 3” program number and 1” duration program are shown alternately Door closed ON/OFF ON/OFF Duration program resumes When the door is opened, program is paused and digit blinks. Not: Y1X_W modelleri için kural aşağıdaki gibi olacaktır.  Program çalışıyorken; kapı açılıp tekrar kapandığında veya elektrik gidip tekrar ...
Page 14: Opening And Closing Door During Program(In Dry Steps)
For USA models 4 seconds rule: During the program washing or delay timer is active, if the door is opened and re-closed within 4 seconds program / delay timer resumes. If the door is not closed within 4 seconds after the door is open, program / delay timer will be paused. During this 4 seconds, display counts down from 4 to 1.
Page 15: Opening And Closing Door During Program(In Regeneration Second Step)
During regeneration and resin washing step: if the door is opened and re-closed, the program continues. For models w/o display; COMMANDS Start/Stop Wash Rinse On/Off Door open Blink Door closed led is ON together with the blinking Start/Stop led. *When the door is opened, Dry When the door is closed, Dry led is ON. ...
Page 16: Selecting And Starting Program When Door Is Opened(Before Program Starts)
program are shown alternately Door closed “0” When the door is opened and re-closed, program ends and display shows right aligned “0”. 3.7 SELECTING AND STARTING PROGRAM WHEN DOOR IS OPENED(BEFORE PROGRAM STARTS) For models w/o display; COMMANDS Start/Stop Wash Rinse On/Off Switch on Door open Select program ON/OFF* ON/OFF* ON/OFF*...
Page 17: Termination Of A Program(End Of Program)
Door closed Duration program If user selects a program when the door is open, related program duration and number is seen on the display. Then, if user presses Start/Stop button, duration of the selected program blinks. After closing the door, Wash led is ON and selected program starts. 3.8 TERMINATION OF A PROGRAM(END OF PROGRAM) For models w/o display;...
Page 18: If User Presses Any Button(At The End Of Program)
3.10 IF USER PRESSES ANY BUTTON(AT THE END OF PROGRAM) For models w/o display; COMMANDS Start/Stop Wash Rinse On/Off End of program Selection of new program or ON/OFF* ON/OFF* ON/OFF* ON/OFF* pressed option Pressure of Start/Stop button *When user selects a program at the end of program, related program led(s) and Start/Stop led are ON.
Page 19: Modification Of A Program With Reset
Select new program Blink ON/OFF* ON/OFF* ON/OFF* ON/OFF* Pressure of Start/Stop ON/OFF** ON/OFF** ON/OFF** button * If user selects new program, related new program led(s) is ON. **Program continues with the new parameters and related washing led(s) is ON. For models w/ display; COMMANDS Wash Rinse...
Page 20: Switch Off The Machine During Program And Before Starting Program
For models w/ display; COMMANDS Wash Rinse On/Off Digit Washing cycle is in ON/OFF ON/OFF ON/OFF Duration progress program Pressure of Start/Stop ON/OFF ON/OFF ON/OFF Duration button 3” program Drain of water Blink “1” End of Drain “0” Select new program 3”...
Page 21: Cancelling Of A Program (During Delay Time)
is ON. Selecting any program does not affect the program flow of previously selected program. Therefore, previously selected program is resumed. For models w/o display; COMMANDS Start/Stop Wash Rinse On/Off Washing cycle is in progress ON/OFF ON/OFF ON/OFF Machine is “POWER OFF” Machine is “POWER ON”...
Page 22: Modification Of A Program During Delay Time
COMMANDS Start/Stop Wash Rinse Selected Related On/Off indicators program (delay timer) Pressure of Start/Stop button for 3” End of program While pressing the Start/Stop button for 3”, selected indicator led(3h, 6h or both 3h and 6h) is ON and related program led is ON. *During the cancellation process “End led”...
Page 23: Switch Off The Machine During Delay Time
program are shown alternately Select new program 1” Delay duration, 3” new program number and 1” duration of new program are shown alternately Pressure of Start/Stop Delay duration button Note(Y25 & Y26): When user pauses delay duration, 1” delay duration and 3” program number are shown alternately.
Page 24: Power Fail
4. POWER FAIL  During a Delay Start: At the power on, program consumes the remaining time.  During a Drain + Fill step: At the power on the program restarts the step to the beginning (with the drain).  During a Wash step: At the power on the program consumes the remaining time.
Page 25 -When the machine is switched on again, the last selected options are active and washing must go on remaining. -Due to Eco design requirements, each energized of the machine (by pressing ON/OFF) Eco program must be fixed as default, the options that are chosen before will be cancelled. ...
Page 26: Compatibility Between Options
Extra Fast Extra Silent Extra Drying Child Lock 5.2 COMPATIBILITY BETWEEN OPTIONS Options Delay Timer Half Load Tablet Child Extra Extra Extra ( 3 modes Lock Rinse Hygiene Delay Timer Half Load ( 3 modes ) Tablet Child Lock Extra Rinse Extra Hygiene Extra Dry For Y25 &...
Page 27 Intensive 65°C Daily 60 Normal 55°C Auto Delicate 30- 50°C Auto Normal 50-60°C Auto Intensive 60°-70°C Steamwash *Half load option(with Prewash/Quick 30’ program) cannot be selected for models without diverter. For Y25: Delay Half Load Child Energy Extra Extra OPTIONS Tablet Start (3 modes)
Page 28 Quick 30’ Dual Pro wash Super 50‘ Hygiene 70 C Auto ıntensive 60-70 C Steam Wash For YA7_USA / YB7_USA: YB7_USA Programların OPSİYON uyumu Child delay ½ Sanitize H.Temp Ext Dry Ext Lock HL Rinse Regular X X X X X X ...
Page 29 Extra Fast Reduces the duration of the washing Extra Silent Reduces the sound pressure level of the washing 5.4.1 Delay Timer The delay timer option is selected by pressing the regarding option button before the program starts. It is possible to select the delay before selecting the program. Before program is started, all indicator leds and delay led are OFF.
Page 30: Tablet (For Models With Display)
NOT: SADECE USA Amerka Modeller ‐ Delay iptal (cancel delay 3 sec.) Adı altında bir serigrafi olacak. Mesela delay 6h de iken bunu iptal etmek için ya 19h a kadar gidecek ya da “DELAY / cancel delay 3 sec.” tuşuna 1.8 sn. basıp 6h yazısını ortadan kaldıracak. Herhangi bir program iptali veya drain durumu söz konusu değil. 5.4.2 Half Load For models w/o display; Half load is enabled/disabled by pressing “Delay” button for 1,8”. Delay led is ON. For models w/ display-w/o diverter; Half load is enabled/ disabled by pressing “Options”...
Page 31: Extra Options (For Models W/ Display)
When lock is disabled, all leds blink and Display shows “CL” twice When lock is enabled and a button is touched, all leds blink and Display shows “CL” once Valid from 11.01.2021; in any mode (ready, run, pause, end, delay start), while the child lock is active, ‐ if the machine turns off and on again by on/off button, the child lock will stay active when the machine is energized. It will not be cancelled. ‐ if the mains power (220 V) is cut and machine is energized again, the child lock will be cancelled. (For the first phase of Vel sw’s this behaviour is same with on/off button, this will be implemented on the phase) ‐ If the machine is turned off automatically 15 minutes after any usage, the child lock will stay active when the machine is energized. ‐...
Page 32: Software Requirements
Fifth time: Energy save(Drying for Y26)and Silent leds are ON, Fast led is OFF. Wash is executed with the following steps with both “Energy save” and “Silent” functions instead of the normal. Last time: Energy save(Drying for Y26), Fast and Silent leds are OFF. Normal wash is executed. Note: Fast and Silent options cannot be selected together.
Page 33: Regeneration Cycle
Water drain starts with drain pump ON for 33”. After 30”, circulation pump ON. When empty level is recognized (by pressure switch signal), the circulation pump stops and the machine continues for the request steps. If pressure switch level doesn’t switch in Empty level (during circulation pump on), failure of Water drain works (see 8.failure routines).
Page 34: Feature Of Time Phase
the resin chamber. The resin wash will be: load 2 lt of water with drain pump on. During the resin wash the circulation Pump must be off. Regeneration is not performed at prewash program If water hardness level is changed from lower to higher, regeneration cycle is performed at the end of the first program If water hardness level is changed from higher to lower, regeneration cycle is not performed at the end of the first program.
Page 35: Voltage Sensing Control
 At the beginning of the main wash of eco program, If temperature of water < 30C , Time phase is not activated at the main wash of eco program  At the beginning of the main wash of eco program, If temperature of water > 30C , Time phase is activated at the main wash of eco program ...
Page 36: Ntc Values
6.7 NTC VALUES 36 ...
Page 37: Water Hardness Set
6.8 WATER HARDNESS SET Only service can execute this procedure. This procedure erases the cycle counter. For AU Y models, water hardness level is level 1 as default. For models w/o display; Button combination for Water hardness setting: Level Wash Rinse ...
Page 38  Press program button to set the desired level. At any pressure of program button hardness level is incremented. Hardness level 1 returns after hardness level 6. * If it is the first hardness set, hardness level is level 3. For models w/ display;...
Page 39 1 rinse aid dosage is performed when dispenser is ON during 8” and OFF during 8”. =>1,5cc 2 rinse aid dosages are performed 8” ON-8” OFF-8” ON-8” OFF=>3cc 3 rinse aid dosages are performed 8” ON-8” OFF-8” ON-8” OFF-8” ON-8” OFF=>4,5cc 4 rinse aid dosages are performed 8”...
Page 40 For models w/ display; Press Extra button for 3”. Display shows “Ion” when ionizer function is activated. Figure for Y2# is as below. UVON TECT 6.11 DEFAULT TURBIDITY All 45&60cm Y1 and Y21‐Y22‐Y23 models with sliding dispenser have default turbidity function. Thanks to this, auto program works when turbidity is connected. Intensive program works when turbidity is not connected. Models with turbidity contains FA error, the others does not. 6.12 INNER LIGHT (45&60 cm Y1‐Y2 models, USA models) Machine must be ON position during activation and deactivation of inner light modes. Open or close position of the door is not important.
Page 41 After “Normal Mode” is selected, the inner light will be ON as long as the machine is energized and machine door is open. How to change from “NORMAL MODE” to “ECO MODE” for Inner Light option First energize the machine via On/Off button. (if it is in OFF position). For Y2x:Press “extra”...
Page 42 6.13 AUTOMATIC PROGRAM(TURBIDITY SENSOR) Turbidity sensor is performed in the “auto delicate”, “auto normal” and “auto intensive” programs. Third Fourth Calibration First measure Second measure measure measure (L1) Second Pre wash First optional Main wash Pre wash rinse rinse Pre wash 1) The calibration is executed after reaching P1 level in the first filling step. 2) The first measure is executed at the end of pre-wash.
Page 43 6.14 AUTODOOR OPEN SYTEM Energy save option is not selectable at any time. During program, energy save option cannot be cancelled or cannot be added. If user presses energy save button during program, the buzzer gives a long sound that is activated to warn that this is not a valid command. Button combination for Energy Save Option: Energy save option is enable by firstly pressure of Extra button (Energy save led lights up) before starting the program.
Page 44 TY4 triac is not driven by microcontroller   There is 0 on the display.  FC failure code is saved to memory Machine must be ON position during activation and deactivation of door open system. Position of the door (open/close) is not important to activate/deactivate the system. But during washing cycle, it is not enabled to activate /deactivate to this feature.
Page 45 o TY4 triac is not driven by microcontroller o There is 0 on the display. o Stop to count 2 minutes in the memory  If Auto door is not opened in 2 minutes o TY4 triac is not driven by microcontroller o There is 0 on the display.
Page 46: Service Test
Button Combination for Voice Level Set: First energize the machine via main switch (if it is in OFF position). Press of “Delay” button for 3”. If voice controlling is done first time, at the end of 3 seconds, “S1” is shown in the display and Buzzer gives a long sound.
Page 47: Service Failure Codes
Drain 20” Drain pump; pressure switch. Code error or end led * 3lt in Y1; 2,5lt in Y2. ** 0,5lt in Y1; 1lt in Y2. *** In service test the unsuccessful heating failure routine works with reduced time of recognize (first measure at 2’20”, second measure t 4’20”) If during the service test, the door is opened, Start/Stop led blinks (for models w/ display “SP”...
Page 48: Failure Routines
HIGH VOLTAGE Blink Blink Blink LOW VOLTAGE Blink Blink In the normal work this failure is Turbidity Sensor Blink Blink not visualized. Note: When water tap is closed, FF failure code will be shown in new models. For models w/ display; Name DISPLAY Notes Overflow...
Page 49: Description Of Failures
12 CK Parameters OFF/ON 13 High Voltage Failure OFF/ON 14 Low Voltage Failure OFF/ON *Cycle could be executed with a filling time. Failure Routine If a failure is recognized:  Stop all devices  Stop program flow.  Drain Empty + 30” with circulation pump on If the failure requires the termination of the washing program: ...
Page 50 Overflow/Leakage Recognize: 5” with overflow pressure sensing = on. Action Go to Failure routine. Exit If overflow signal gets off until failure routine finishes (cause is overflow): washing program restarts. It re-fills water according to Re-Fill routine and it continues to wash. If overflow signal persists until failure routine (cause is leakage): OFF/ON.
Page 51 Recognize: After 50” (time out) of load without impulses by the flow meter, circulation pump starts. If pressure Action Exit Service Model Start/Stop(w/o Wash Rinse Display display) Delay(w/display) Blink … (F4) Y1 w/o display All leds blink Y1 w/ display,Y2 Level Empty without Flow meter impulses (perhaps Tap close) Recognize: After water load starts, if pressure switch doesn’t go to full level in 150”.
Page 52 Recognize: With rarely flow meter impulses (time out of absence of flow meter impulses doesn’t expire) it doesn’t reach the second quantity of required water related to the washing cycle) within the time out (100”) Action Go to Failure routine. Exit OFF/ON Service...
Page 53 Service Model Start/Stop Wash Rinse Display Blink Blink …(F6) Y1 w/o display All leds blink Y1 w/ display,Y2 Overheating Recognize: Water temperature >= 77°C . The test is done during all the cycle. Action Go to Failure routine. Exit OFF/ON Service Model Start/Stop(w/o...
Page 54 Voltage failure Recognize: If the card detect high or low voltage level from main supply Action Stop the program . After 3 hours Go to Failure Rutine and show failure code. Exit OFF/ON Service High Voltage Failure: When high voltage (Above 285V, then 275-285VAC) detected during 3 hours Model Start/Stop(w/o Wash...
Page 55: Failure Codes
Model Start/Stop(w/o Wash Rinse Display display) Delay(w/display) All leds blink 8.2 FAILURE CODES Coding failure for models without display: N° Name Start/Stop Wash Rinse Door open Blink Delay before Door closing Overflow Leakage Blink Blink Drain time out Blink Blink Blink Empty Level Empty Level (FF, for new models, 26.04.2020) Blink Blink Re-Fill time out...
Page 56: End Test
11 Diverter opened Blink 12 CK Parameters Blink 13 Parameter set salt incorrect Blink 14 Turbidity Sensing Blink 15 Auto Door Failure Blink 16 High Voltage Failure (HI) Blink 17 Low Voltage Failure (LO) Blink 9. END TEST End test is divided in two parts: end test 1 (functionally test) and end test 2 (heating and leakage test). End test 1: Vestel receives the electronic cards ready to start “end test 1”.
Page 57 -Salt indicator and rinse aid indicator is ON if reed sensors are short cut during end test END TEST 1 or END TEST2 -Salt indicator and rinse aid indicator is OFF if reed sensors are not short cut during end test END TEST 1 or END TEST Note: In cases where the machine is energized, On/Off led is ON.
Page 58: Electrical Components
ELECTRICAL COMPONENTS AQUAZONE DOOR LOCK It is a mechanical lock/release system that is closing the door, supplying the connection of electrical parts in the machine and cutting off the connection. Currency 16 (4 ) A CIRCULATION PUMP Measurement of the primary windings of the washing pump. (118.2-135.9 Ω) Measurement of the secondary windings of the washing pump (white cable –...
Page 59 CN2.10 - CN2.2 0 Ω KN2.9 - KN2.10 0 Ω WATER PRESSURE SWITCH ∞Ω ∞Ω NO WATER PRESSURE SWITCH Voltage 220/240 v Frequency 50/60 Hz 16 A - 3 Pins DIVERTER There is diverter at A15 and A23 models It is assembled to the heater Casing Group.
Page 60 BLDC MOTOR UPPER SPRAY ARM It distributes water from upper spray arm to dirty dishes in the upper basket. It provides to wash the dishes in the upper basket through turning by the holes with various angles. LOWER SPRAY ARM It distributes water from lower spray arm to dirty dishes in the lower basket.
Page 61 CAPACITOR Capacitor is permanently connected to the circulation pump coils. DRAIN PUMP HEATER Voltage 220/240 volt Total power 1800W 27.6-30.6 ohm...
Page 62 FAILURE CODES (Possible Problems) F1 (ALARM IS ACTIVE FOR OVERFLOW) FLOATER Floater switch can be out order or have a problem with the cable connection.  There can be a water leakage from the tub  ELECTRONIC CARD  Electronic card can be out of order. F2 (THE WASTE WATER IN THE MACHINE CANNOT BE DISCHARGED) Draın hose Water outlet hose is clogged...
Page 63 F7 (EXTREME HEATING UP FAULTY) If the water temperature inside machine higher than 77°C, ntc can be out of order.  Electronic card  Electronic card can be out of order. F8 (INADEQUATE HEAT) Heater Check the power and resistance values. ...
Page 64 REGENERATION VALVE Regeneration valve is assembled on the water softener. PARASITE FILTER It is used to prevent parasites from the main supply It has been assemblied to basement. TURBO FAN MOTOR There is a thermal protector shaded pole motor, two pole temperature is between -40-150 °C There is turbo fan motor only at A models.
Page 65 SALT SENSOR Voltage 250 V Currency 50 mA It is assembled to the water softener. It warns if the salt is less than requested quantity. POWER CORD DRAIN HOSE...
Page 66 COMPONENT VALUES MEASUREMENT Precaution: Always remove the plug from the power socket before touching internal components. WASHİNG PUMP: From the electronical card: You can only measure the primary winding value from the electronical card. Resistance value of the primary winding must be Primary winding Secondary winding (from the CN2.3 - CN2.9...
Page 67 FAN MOTOR From the electronical card: FAN MOTOR CN 6.2 - CN 2.9 KN 6.2 - KN 2.8 Above sketch showa-s the connectors of the fan motor on the electronical card. From the comonent: Turbo fan resistance value: 265 ± %10 Ω (The resistance of the torbo fan is measured with the resistor switch).
Page 68 DOOR SWITCH From the electronical card: Above sketch show the connectors of the door switch on the electronical card. From the compoonent: Probes of the tester should be applied on to the related connectors as shown on the pictures.
Page 69 SALT SENSOR From the electronical card: CN5.1 - CN5.2 0 Ω NO SALT KN50.10 - KN 50.11 0 Ω NO SALT Measure just on the electronıc SALT SENSOR ∞Ω THERE IS SALT ∞Ω THERE IS SALT Sketch above show the connectors of the salt sensor on the electronical card. Probes of the tester should be applied on the related connectors.
Page 70 DIVERTER From the electronical Card: Sketch above show the connectors of the diverter on the electronical card. Probes of the tester should be applied on to the related connectors. From the component: Probes of the tester should be applied on to the related connectors as shown on the pictures.
Page 71 PRESSURE SWITCH From the electronical card: CN2.10 - CN2.2 0 Ω KN2.9 - KN2.10 0 Ω Full fıll water PRESSURE SWITCH no water ∞Ω ∞Ω From the component: Probes of the tester should be applied on to the related connectors as shown in the picture above.
Page 72 REGENARATION VALVE From the electronical Card: REGENERATION VALVE CN2.2 - CN2.7 3560 Ω ± %10(25°C) KN2.2 - KN2.10 3560 Ω ± %10(25°C) Above sketch show the connectors of rhe regenaration valve on the electronical card. Probes of the tester should be applied on to the related connectors. From the component:...
Page 73 HEATER It can’ be measured from the electronıcal card. From the component: DETERGENT DISPENSER It can’t be measured from the electronical card: DETERGENT DISPENSER 2300 Ω ±%10 (25 C°) 2300 Ω ±%10 (25 C°) From the component:...
Page 74 WATER INLET VALVE From the electronical Card: WATER INLET VALVE CN2.6 - CN2.9 4200 Ω ± %10 (20°C) KN2.6 - KN2.8 4200 Ω ± %10 (20°C) Above sketch show the connectors of the water inlet valve on the electronical card. Probes of the tester should be applies on to the related connectors.
Page 75 DRAIN PUMP From the electronical Card: DRAIN PUMP / HANYU CN2.2 - CN2.4 220 Ω % ±10 KN2.4 - KN2.10 220 Ω % ± DRAIN PUMP / LEILI CN2.2 - CN2.4 141 Ω % ±10 KN2.4 - KN2.10 141 Ω % ± Above sketch show the connectors of the drain pump on the electronical card.
Page 76 RİNSE AİD SENSOR From the electronical card: CN 5.3 - CN 5.2 0 Ω NO RİNSE AİD KN 50.8 - KN 50.9 0 Ω NO RİNSE AİD Rınse adı off RINSE AID SENSOR Rınse aıd on ∞Ω THERE IS RİNSE AİD ∞Ω...
Page 77 FLOATER From the electronical card: Mıcroswıtch ıs ınactıve (no water ) CN2.1 - CN 2.5 0 Ω KN2.5 - KN 2.10 0 Ω mıcroswıtch ıs actıve (there ıs FLOATER (MICROSWITCH) CN2.1 - CN 2.4 KN2.4 - KN 2.5 ∞Ω ∞Ω water) Position 1 : Yo can check the floater by controlling the specified value intervals.
Page 78 SALT SENSOR From the electronical card: CN5.1 - CN5.2 0 Ω NO SALT KN50.10 - KN 50.11 0 Ω NO SALT Measure just on the electronıc SALT SENSOR ∞Ω THERE IS SALT ∞Ω THERE IS SALT Sketch above show the connectors of the salt sensor on the electronical card. Probes of the tester should be applied on the related connectors.
Page 79 DIVERTER From the electronical Card: Sketch above show the connectors of the diverter on the electronical card. Probes of the tester should be applied on to the related connectors. From the component: Probes of the tester should be applied on to the related connectors as shown on the pictures.
Page 80: Disassemble
DISASSEMBLY CAUTION!: REMOVE ELECTRIC PLUG FROM THE SOCKET DURING THE DISASSEMBLY Top Plate a) Remove two screws that fix the top plate at the back. b) Push the top-plate back and pull it up. Plastic Kick Plate Remove two screws fixing plastic kick plate. Remove the plastic kick plate as it is shown in the picture.
Page 81 INTERNAL FEEDING TUBES AND SPRAY ARMS REMOVAL 1)Unscrew the feed channel tabs with the help of a screwdriver 2)To assemble, manually narrow the feed channel replacement and insert it into the tabs 3)Pull out the top spray channel by turning it clockwise 5)To remove the lower spray arm, 4)Turn it counterclockwise to reinstall it kindly pull it up...
Page 82 The components that are inside the tub course, micro and metal filters a) Open the door. b) Remove lower basket c) To remove microfilter group rotate them in the direction of counter clockwise and pull them up as it is shown in the picture d) To remove microfilter group (course filter and micro filter ) pull them as it is shown in the picture.
Page 83 Draining hose a) Remove the hose connection plastic. b) Remove lower cover. c) Remove the clamp that fixes draining hose to thesump d) Remove draining hose Lower basket a) Open machine’s door. b) Pull the basket to yourself. Upper basket a) Open upper basket rail lock front.
Page 84 Water Inlet valve a) Remove lower cover. b) Remove the wire that is connected to the water inlet valve. c) Remove the clamp that connects water inlet valve and air-break as it is shown in the picture To remove water inlet valve pull it back as it is shown in the direction of picture then release water inlet valve from the pins that is connecte to and rotate it in the direction of counterclockwise.
Page 85 TURBO FAN REMOVAL INSTRUCTIONS 3)Disconnect the condensate unit from the turbo fan. 1)Remove top tray 2)Remove the side panel rear and front screws 4)Remove the turbo fan screws side panel rear screw turbo fan screws 5)Disconnect turbo fan cables 6)Remove the turbo fan from its replacement + to reassemble, Before connect the cables,...
Page 86 5)Disconnect ntc cables 6)Disconnect heater hose 7)Unscrew eco or diverter part(it is changeable) screws 8)Then get the sump To assemle, connect the cables and screws in same way.
Page 87 SUMP GROUP REMOVAL INSTRUCTIONS 1)Remove 2 screws on top 2)Remove the drain pump sump screws drain pump 4) Remove the blue hose from the 3)Remove the drain hose water softener to the pool group blue hose drain hose...
Page 88 HEATER REMOVAL INSTRUCTIONS 1)Remove 2 clamps 2)Disconnect cable connections and get the heater 3)To assemble, the cables are connected first and the screws are attached.
Page 89 Floater a) Remove lower cover. b) Remove two screws that fix floater as it is shown in the picture. c) Remove the two floater hoses. d) Remove the wire that is connected to the floater.
Page 90 Water softener a) To remove salt cup cover, rotate it in the direction of counterclockwise b) To remove salt cup nut, rotate it in the direction of counterclockwise. c) Remove left side panel. d) Derach the connections which are between water softener and air-break.
Page 91 DIVERTER REMOVAL INSTRUCTIONS 1)Disconnect the diverter cables 2)Disconnect pressure switch cables diverter cables pressure switch 3)Disconnect turbidity sensor cables( if the machine has) 4)Unscrew the diverter screws 5)Pull the clamps with pliers (Diverter clamp is next to the circulation pump's clamp. you can see in the circulation pump removal instruction page).
Page 92 Access the components from the lower cover a) Lay the appliance on the rear panel. b) Remove lower cover from the places that are shown in the picture. CIRCULATION PUMP REMOVAL INSTRUCTIONS 1) There are 2 clamps. 3)remove the straps from both sides 2) Push the 2 clamps upwards.
Page 93 To acces the components from in Front of the Machine a) Remove plastic kick plate iron sheet and basement front cover Regenaration valve a) Remove plastic kick plate and kick plate iron sheet. b) Remove the wires c) To remove regenaration Value rotate counterclockwise and pull it as it is shown in the picture.
Page 94 Power cord a) Remove hose connection plastic. b) Remove the lower cover. c) Remove the wires that is between power cord and parasite filter. d) Remove the power cord.
Page 95 Hose connection plastic a) Remove left side panel. b) By using flat tip screwdriver remove hose connection plastic’s hinge from the basement as it shown in the picture c) Push the hose connection plastic. Warning: If you do not obey instrucyions while disassembly od the hose connection plastic it can be broken.
Page 96 Air - break a) Remove the left side panel of the machine. b) Open machine’s door c) Rotate counterclockwise air-break nut and remove it. d) Remove air-break’s connections with salt cap as it is shown in the picture. (be careful about plastic hinges)
Page 97 Door Inside a) Remove side panels. b) Remove Hinge Spring. Door spring c) Pull the door inside up as It is shown in the picture. d) Remove two screws that fix hinge movement sheet iron to the door inside. KNOB REMOVAL INSTRUCTIONS 1)Remove control panel, 2)Remove the pcb box, 3)Remove the plastic tabs around the knob by flexing...
Page 98 DISPANSER REMOVAL INSTRUCTIONS 1)Remove front panel 4)Then the dispenser will drop in 2)Disconnect the dispenser cable harness Dispanser cables dispanser is free 3)Remove the metal tabs on the top, bottom and sides to disengage the dispenser. 5)To assemble, tighten the metal tabs with a pliers After applying silicone oil or liquid soap to dispenser, press down and...
Page 99 DOOR LOCK REMOVAL INSTRUCTIONS 1)Remove control panel screws 2)Disconnect cable connections with door lock 3)Remove two door lock screws...
Page 100 ELECTRONIC CARD REMOVAL INSTRUCTIONS 1)Remove top tray 3)Remove side panel 3)Remove side panel support styrofoam 4)Pull up the pcb box 5)Disconnect cable connections from cable harness 6)Remove the tabs and take the electronic card 7)To assemble, reinsert the pcb box into the tabs.
Page 101 Control Panel a) Remove 6 screws that fix control panel to the door inside sheet iron. b) Remove the control panel group crefully as shown in the picture c) Remove the cable connection plastic which fix cable harness to the control panel as shown in the picture.
Page 102 Control Panel a) Remove 6 screws that fix control panel to the door inside sheet iron. b) Remove the control panel group crefully as shown in the picture c) Remove the cable connection plastic which fix cable harness to the control panel as shown in the picture.
Page 103 Kick Plate Sheet Iron a) Remove top plate, plastic kick plate and side panels. b) Remove the screws (4 screws) that fix the kick plate sheet iron. c) Pull it down as shown in the picture. To remove the side panel, remove the upper plastic hinge and than the above one and pull it up. •...
Page 104 Front Panel a) Remove the screws as it shown in the picture. b) Pull down the front panel after removing the screws.
Page 105 Side panels removal instructions 2) Remove the side panel rear screws 1) Remove top table screws Top Tray screws Side panel rear screws 3) Remove the kick plate plastic after removing the front panel 4)Remove the side panel front screws Plastic kick plate screw side panel front screws 5)remove the side panel rear tabs...
