- Page 1 SERVICE MANUAL Y SERIES Y SERIES (WITHOUT ON-OFF BUTTON AND KNOB) WITH AND WITHOUT DISPLAY PRODUCTS...
- Page 2 SERVICE MANUAL Y SERIES PROGRAM CANCELLATION OF Y SERIES 1) The machine must be open position to do the cancellation process. 2) Push the Start/Pause button for 3 sec. while the machine is operating. On-off 3) After 3 sec, the drying light lights up and then it starts draining by the drain pump operates.
- Page 3 2) The machine will be opened when the on/off button is on. On/Off light lights up. If machine has no display, also Start/Stop and Eco program lights turn on. THE SERVICE TEST OF Y SERIES 1) Power OFF; press Start/Stop button.
- Page 4 4) During the first 6” of test, if a failure code is stored in memory, its codification blinks. Also at the end of the test if an error occurs its error code blinks. Note: Service program can be cancelled with cancellation operation. SALT SETTING OF Y SERIES For models w/o display; 1) Power OFF; press program button.
- Page 5 SERVICE MANUAL Y SERIES For models w/ display; Power OFF; press program button. Power ON and continue to press program button at least for 3”. If “Hardness set” is recognized “SL” is shown for 2”. Release program button. The last setting level is viewed*.
- Page 6 SERVICE MANUAL Y SERIES REPAIR TECHNIQUES A simpler and special control procedure is obtained to test the components efficiency. In this control procedure, you can measure the resistance of the components and compare with the normal resistance values. Then you can understand that if the components are faulty or not.
- Page 7 SERVICE MANUAL Y SERIES CN 3.2 25°- 5000Ω %±5.0 CN 3.1 35°- 3300Ω %±5.5 55°- 1520Ω %±6.5 SET NTC SENSOR 63°- 1174Ω %±7.5 80°- 670Ω %±8.0 90°- 488Ω %±8.5 MICROSWITICH IS INACT VE (NO CN2.1 – CN 2.5 0 Ω...
-
Page 8: Failure Codes
SERVICE MANUAL Y SERIES FAILURE CODES PRODUCTS WITHOUT DISPLAY... - Page 9 SERVICE MANUAL Y SERIES PRODUCTS WITHOUT DISPLAY W/O DIVERTER(Y1A, Y1B, Y1C,Y1D, Y1E, Y1F) W/ DIVERTER(Y21, Y22, Y23,Y24)
- Page 10 SERVICE MANUAL Y SERIES Water is not enough Is it controlled that if the w ater Tell the consumer that is f low ing f rom the tap has a problem. the tap? Is the w ater pressure Make the...
- Page 11 SERVICE MANUAL Y SERIES Not washing clean Are there any soil or detergent Give some inf ormations about residue on the detergent usage to the consumer. dishes? 1-The pow der detergents must be preseved in closed packets. 2-The pow der detergents must not be preserved in moist rooms.
- Page 12 SERVICE MANUAL Y SERIES MACHINE IS NOT WORKING Is the start/pause button lighting Check the supplying w hen you give voltage, On/Off button energy to the and cable connections. machine? Check the PCB card. ☺ Is the w ashing led...
- Page 13 SERVICE MANUAL Y SERIES Not taking the detergent / Not dissolved Operate the service program. Go Operate the on controlling according to the machine w ith the failure description. service program. The dishes can be situated as preventing to open the detergent...
- Page 14 SERVICE MANUAL Y SERIES Water overflow/water leakage Operate the Operate the service machine w ith the program. Go on service program. controlling according to the failure description. If the failure that seen in service program is Is the draining pump...
