DIMENSIONS
Figure 3
SETTINGS SMARTPASS 120T
168mm/6⅝ inches
Smart alternator cable (red)
Type of alternator
Not connected
Conventional alternator
Connected
Smart alternator
Ignition signal, +15 clamp
Smart alternator cable (red)
(DIN 72552)
Chassis/Earth
Negative cable connection (black)
Temperature sensor
250mm / 9.84inches
8 •
