Forney 180 ST+ Quick Start Manual

ITEM# 321
QUICK START GUIDE
180 ST+ WELDER
1.
Read user manual
2.
Select DC TIG process
3.
Connect TIG torch lead
Connect TIG torch and
to gas (100% Argon)
ground clamp
7.
Use lift arc technique to initiate a welding
arc
ELECTRODE IS ALWAYS ELECTRICALLY
HOT WHILE IN TIG MODE
1.
Select STICK process
3.
Connect to Input power
Dedicated Circuit
240VAC - 50A
breaker
recommended or
120VAC - 20A
outlet, 30A breaker
• Generator OK with continuous output
> 4,000 W (120V) or 10,500 W
(240V)
• Extension cord: (120V) #12 AWG or
#10 AWG (240V) or larger. 25' (8m)
or shorter recommended
• Always follow local electrical codes
(NOT RECOMMENDED FOR ALUMINUM)

TIG WELDING SET-UP

TIG Torch
* TIG Torch Sold Separately
4.

STICK WELDING SET-UP

2.
4.
Adjust amperage per
settings chart
QUESTIONS OR TROUBLE? Contact Forney Industries at 1-800-521-6038
customerservice@forneyind.com • askforney.com • forneyind.com
Electrode Holder
5.
Adjust amperage per
material thickness
Connect electrode
holder and ground
clamp according to
desired polarity
Usually DCEP - Electrode Positive
5.
Recommended electrodes
Diameter
Electrode
Inches MM
2,4
3/32
E6010
3,2
1/8
&
E6011
4,0
5/32
1,6
1/16
2,4
3/32
E6013
3,2
1/8
5/32 4,0
2,4
3/32
3,2
E7014 1/8
4,0
5/32
3/32 2,4
E7018 1/8 3,2
4,0
5/32
Ground
Clamp
6.
Connect to Input power
Dedicated Circuit
240VAC - 50A
breaker recommended
or 120VAC - 20A
outlet, 30A breaker
• Generator OK with continuous output
> 4,000 W (120V) or 10,500 W
(240V)
• Extension cord: (120V) #12 AWG or
#10 AWG (240V) or larger. 25' (8m)
or shorter recommended
• Always follow local electrical codes
Amperage Pulse Recommendations
AMPS Hz % On
30-75
35-125 3.5-4.2 50-55%
80-160
10-50
40-90
>5 >50%
50-130
90-180
40-90
2-2.4 40-45%
60-130
90-180
50-80
80-160 5.5-6.5 50-90%
90-180
*Performance may vary by brand
EN_v1
