CAT# 271
MIG QUICK START GUIDE
140 MP WELDER
1.
Read user manual
2.
Select
3.
Set polarity for MIG (Solid wire)
or Flux-cored
Solid wire
4.
Connect MIG gun and ground clamp
7.
Feed wire and set pressure
Pressure knob
Knob set ~2-3
marks
9.
Remove
consumables
and depress
trigger until
wire comes out.
Replace
consumables.
(NOT RECOMMENDED FOR ALUMINUM)
process
Flux-cored
5.
Install wire spool
0.023" (0.6mm) - 0.030" (0.8mm) diameter
8" (200mm)
wire spool
4" (100mm)
wire spool
8.
Connect to Input Power
• Generator OK with continuous output >
4,000 W
• Extension cord: #12 AWG or larger;
25' (8m) or shorter
10.
Adjust wire feed
speed (
voltage ( )
See chart on welder
for correct settings
FIND MIG WELDING TIPS AT WWW.ASKFORNEY.COM
QUESTIONS OR TROUBLE? Contact Forney Industries at 1-800-521-6038
customerservice@forneyind.com • askforney.com • forneyind.com
MIG Gun
120VAC, 20A
outlet, 30A breaker
recommended
) and
6.
Set drive roll
Solid
wire
* Face the appropriate groove
towards the inside of machine
NOTE: If using gas:
1. Attach gas hose
2. Attach hose to
to machine.
regulator and
regulator to
gas bottle.
11.
With contact tip
1/4" from metal,
depress trigger
completely to
initiate arc
Ground
Clamp
Flux-
cored
EN_v1-4
