Storage
NVMe
Tensor-PC supports up to 8 NVMe M.2 2280 devices, each with PCIe 3 x4 interface
The NVMe cards are installed by fastening each to the TEL-NVME element as described below.
Note:
In case you have received an assembled flat cable on an aluminum TEL element (without NVMe module), you
must firstly de-touch the flat cable from the plate by unscrewing two fillips screws as shown below:
1. Remove protective film from the pink heatsink
www.fit-iot.com
Page 16 of 58
Tensor-PC owner's manual
