CompuLab Tensor-I20 Owner's Manual page 12

TEL Kind TEL name
[FH] COM TEL-SERX4
[FHA] COM TEL-SERX1
[FHB] COM TEL-SERDB9
[FS] COM TEL-GPIO
[FV] COM TEL-GPIOEXT
[FD] I/O TEL-AUDIO
[FEA] I/O TEL-USB3X4V
[FEC] I/O TEL-USB2X4V
[FEC] I/O TEL-USB3PCIV4 4x USB3.0 type PCI
[FC] Network TEL-LANX2
[FCA] Network TEL-LANX4
[FI] Network TEL-M2B
[FJ] Network TEL-M2E
[FL] Network TEL-MINIPCIE
[FU] Network TEL-POEX2
[FA] Output TEL-DPHDMI
[FK] Output TEL-DPmHDMI
[FG] Output TEL-STD
[FO] Power FO
[FP] Power FP
[FF] Storage TEL-NVME
[FT] Storage TEL-SATA1
www.fit-iot.com
TEL to TRIP list
Description
4x RS232 / RS485 with DB9 connectors
1x RS232 by DB9
1x RS232/RS485 by DB9 (to be used with TEL-SERX4)
20x GPIO - terminal block of 4x GPIO + 4 headers of 4 GPIO each
4x GPIO by a terminal block (to be used with TEL-GPIO)
Headphones / line-out + microphone using 2x 3.5mm
4x USB3.1 type A
4x USB2.0 type A
2x Gbit Ethernet ports using RJ45
4x Gbit Ethernet ports using RJ45
an M.2 key-B socket with SIM card tray + 2x Pentaband
antennas (each with a panel and MHF cable)
an M.2 key-E socket + 2x Wi-Fi antennas (each with a
panel and MHF cable)
a mini PCIe socket with SIM card tray + 2x Pentaband
antennas (each with a panel and U.FL cable)
2x Gbit Ethernet with PoE PSE by RJ45
Display Port + HDMI, designed for TRIP-M
mini Display Port + HDMI
Display Port + Gbit Ethernet
A power module for 12VDC PSU with twist lock, Incl. 60W PSU and AC
cord.
A power module for 12V - 56V DC, ATX connector with
locking, Incl. 120W PSU and AC cord.
M.2 2280 NVMe card or M.2 SATA
2x 2.5" SSD / HDD
Page 12 of 58
