Hayetsira St. 17, Yokneam, Israel
Tel: +972-48-290-168 | Fax: +972-48-325-251 | www.fit-iot.com
WARNING: Only technically skilled person should open and service the Tensor-PC!
RTC Battery
3, 4
(
)
The RTC battery of Tensor-PC is intended to maintain power to the internal Real Time Clock
circuitry.
Tensor-PC can work without a battery, or when the battery is dead. At these situations, the
internal clock won't be kept on main power loss, and the boot after power loss may take a few
second longer.
In order to replace a depleted RTC battery (4), while the bottom cover is removed and power
from PSU is disconnected, remove the battery wire from the RTC BAT socket on SBC (3) and
replace with the new one.
WARNING:
Risk of explosion if the battery is replaced by incorrect type.
1, 2
RAM
(
)
Tensor-PC motherboard features two SODIMM DDR4 slots supporting DDR4-2400.
Tensor-PC supports up to 64 GB in 2x 32 GB configuration.
Both ECC and Non-ECC RAM is supported
Important note: Buffered (registered) RAM is not supported in Tensor-PC.
www.fit-iot.com
Page 15 of 58
Tensor-PC owner's manual
