E2S BExTBG05D Instruction Manual

1) Introduction
The BExTBG05D is a flameproof Flashtel which is certified to
meet the requirements of the ATEX directive 94/9/EC and
IECEx scheme. The Flashtel produces a visual warning
signal when triggered by a telephone ringing signal and can
be used in hazardous areas where potentially flammable gas
and dust atmospheres may be present. The BExTBG05D has
a flash energy level of 5 joules and can be used in Zone 1
and Zone 2 areas with gases in groups IIA, IIB and IIC and
Temperature Classifications of T1, T2, T3 andT4. The unit
can also be used in a temperature classification T5, if the
upper ambient temperature is restricted to +55ºC and T6 if
the upper ambient temperature is restricted to +40ºC. The
unit can be used in Zone 21 and Zone 22 areas for
combustible dusts and has an IP rating of IP 67 and a surface
temperature rating of T110ºC or T95ºC if the upper ambient
temperature is restricted to +55ºC and T85ºC if the upper
ambient temperature is restricted to +40ºC.
2) Marking
All units have a rating label, which carries the following
important information:-
BExTBG05D
Unit Type No.
Input Voltage: 230V or 115V
Codes: Ex d IIC T4 for Ta –50ºC to +70ºC
Ex d IIC T5 for Ta –50ºC to +55ºC
Ex d IIC T6 for Ta –50ºC to +40ºC
Ex tD A21 IP67 T115ºC based on max. Ta of +70ºC
KEMA 00ATEX2006
Certificate No's
IECEx KEM 10.0002
Epsilon x
Equipment Group and
Category:
CE Marking
Notified Body No.
"Warnings"
DO NOT OPEN WHEN AN EXPLOSIVE
GAS OR DUST ATMOSPHERE IS PRESENT
COVER BOLTS CLASS A4-80
USE HEAT RESISTING CABLES AND CABLE GLANDS
(Rated 110ºC) AT AMB. TEMPERATURES OVER 40ºC
Year of Construction /
Serial No.
3)
Type Approval Standards
The Flashtel has EC Type Examination and IECEx
certificates issued by KEMA and has been approved to the
following standards:-
_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. IS 2462-P Issue E
INSTRUCTION MANUAL (ATEX / IECEx)
BExTBG05D Flameproof Flashtel
For use in Flammable Gas and Dust
II 2G/D
0518
10 1DTB1300001
i.e. /
12-03-10
Atmospheres
EN60079-0:2006 IEC60079-0:2004 (Ed4)
EN60079-1:2007 IEC60079-1:2007 (Ed6)
EN61241-0:2006 IEC61241-0:2004 (Ed1)
EN61241-1:2004 IEC60079-1:2004 (Ed1)
4)
Installation Requirements
The Flashtel must be installed in accordance with the latest
issues of the relevant parts of the EN60079 standards or the
equivalent IEC standards – Selection, Installation and
maintenance of electrical apparatus for use in potentially
explosive atmospheres (other than mining applications or
explosive processing and manufacture):-
EN60079-14:2008
IEC60079-14:2007 (Ed4)
EN60079-10:2003
IEC60079-10:2008 (Ed1)
The installation of the units must also be in accordance with
any local codes that may apply and should only be carried
out by a competent electrical engineer who has the
necessary training.
5)
Zones, Gas Group, Category, IP Rating and
Temperature Classification
The BExTBG05D beacons have been certified Ex d IIC T4 for
Ta –50ºC to +70ºC, Ex d IIC T5 for Ta –50ºC to +55ºC and
Ex d IIC T6 for Ta –50ºC to +40ºC for gas and IP67 T115ºC
based on max. Ta of +70ºC for dust. This means that the
units can be installed in locations with the following
conditions:-
Area Classification Gas:
Zone 1 Explosive gas air mixture likely to occur in
normal operation.
Zone 2 Explosive gas air mixture not likely to occur,
and if it does, it will only exist for a short time.
Gas Groupings:
Group IIA
Group IIB
Group IIC
Temperature Classification:
T1
T2
T3
T4
T5
T6
