Mounting & Installation
1) Remove the thermostat from its packaging.
2) Choose a mounting location so that the thermostat can measure
the room temperature as accurately as possible.
- Mount the thermostat 1.5 metres above the floor level.
- Prevent direct exposure to sunlight or other heating / cooling
sources.
3) To open the front housing
a) use a philips screwdriver to loosen the screw on the bottom
right of the thermostat.
b) insert and rotate a 3.5mm flat screwdriver into the slot on
the bottom left.
4) Wire the thermostat according to the wiring diagram on page 6.
5) Screw the backplate onto a back box or directly to the surface.
6) Close the front housing and tighten the screw on the bottom of
the thermostat.
