Troubleshooting - Quincy lab Analog Series Operating Manual

Chamber Loading
The oven's chamber temperature stability can be affected by changes in ambient (room) temperature and/or equipment
running in close proximity (creating microclimates) or cycling on the same electrical circuit. Take time to see how unit
location or changes in room temperature from seasonal heating or air conditioning may influence the oven's set
temperature. For best chamber temperature stability, keep the ambient temperature stable.
Thermal Safety Reset (Snap Disc)
Oven Safety Reset-
of the user, if the unit exceeds its maximum temperature, an internal safety "snap disc"
will cut power OFF to the unit until it is manually reset (FIG. 7).
To Reset
- disconnect the oven from power. Next, lay the oven on its back and
remove the bottom cover. Locate the round "snap disc" and push on the button to reset.
Maintenance / Cleaning Procedures / Common Replacement Parts
The Lab Series Ovens are designed to be virtually maintenance free. But operational safety requires periodic cleaning
and chamber temperature accuracy verification (see calibration and temp. range adjustment insert for more information).
Cleaning Procedure -
exit ports clear of obstruction and clean of dust and dirt. To reduce the risk of fire, it may be necessary to remove the
bottom plate cover to clean or vacuum any dirt and dust build-up. To clean the exterior and interior surfaces, use a
damp cloth or an all-purpose cleaner. Avoid commercially available oven cleaners.

Troubleshooting

PROBLEM
1. Tripped GFCI power outlet
Unit not turning ON
when power switch
is in the ON position
2. Thermal safety disc tripped.
3. Disconnected / loose wires.
Oven has power but 1. Thermal Fuse (10GC models only)
its not heating
2. Bad / broken / old Thermostat
or is overheating.
Common Replacement Parts
Thermostat
Hydraulic Thermostat
PART # 101-2223
Bimetal Thermostat (Model 10)
PART # 201-2217
Technical Support
If you have any ques�ons or need technical assistance, contact Quincy Lab technical support.
www.quincylab.com
Visit us on the web at
Email: information@quincylab.com
Voice: 800-482-4328 ; Press 2 for tech support.
Fax:
773-622-2282
Limited Warranty
Quincy Lab, Inc. warrants to the original purchaser that this product will be free from defects in material and
workmanship under normal use throughout the warranty period. The standard warranty period for this instru-
ment is twenty four (24) months from date of shipment. The instrument warranty is supplemented with a three
year warranty on the heating element. Please refer to your invoice or shipping documents to determine the active
warranty period. This warranty covers parts & labor (labor at factory only) and shipping cost for replacement parts.
(Continued)
To protect the oven's electrical components and for the safety
Periodically check the rear air intake vents for dirt or dust build-up. Keep the intake &
POSSIBLE CAUSE
Thermometer
Spirit Thermometer
PART # 201-2219
Thermometer grommet
PART # 101-2204
WHAT TO DO BEFORE CALLING TECH. SUPPORT
1. Check if the unit tripped a GFCI outlet or fuse. Try a non GFCI
power outlet connection before moving to number 2 on this list.
2. Reset the oven's "snap disc". Refer to "Thermal Safety
Reset' section above for more information.
3. Check all wire connections in the electrical area (bottom) and
make sure there are no loose or disconnected wires in the unit.
1. Check thermal fuse in the back of the thermostat is not blown
or broken. Repacle if blown/broken.
2. If the oven does not heat, overheats, or does not maitain a
setpoint temperature, it's an indication of a bad/broken/old
thermostat. Replace thermostat on the unit.
Rocker Switch
GC Series
PART # 201-2213
GC Series
parts scan QR code.
PART # 201-2213-1
Quincy Lab, Inc.
109 Shore Dr.,
Burr Ridge, Illinois 60527
Reset button
Thermo Fuse (Snap Disc)
For a full list of
replacement
FIG. 7
PAGE 4
