Black Max BM907022 Quick Reference Manual

WARNING:
This Quick Reference Guide is not a substitute for reading the operator's manual. To reduce the risk of injury or death, user must read and understand operator's manual before using this product. All page references refer to
the operator's manual.
IMPORTANT!
WARNING:
Using a generator indoors CAN KILL YOU IN MINUTES.
Do not connect to a building's electrical
Generator exhaust contains carbon monoxide. This is a
system unless the generator and transfer
poison you cannot see or smell.
switch have been properly installed and
the electrical output has been verified by
a qualified electrician. The connection
must isolate the generator power from
NEVER use inside a home
utility power and must comply with all
or garage, EVEN IF doors
applicable laws and electrical codes. and windows are open.

TOOLS NEEDED

Socket Wrench

FIRST TIME ASSEMBLY

1 4
Install the feet (see page 11).
Raise and secure the handle (see page 13).
2 Install the wheels (see page 11).
Add entire bottle of lubricant provided to the
5
3 Connect and charge the battery (see pages 12 and 18).
generator (see page 13).
Set unit on flat surface so engine is level.
Remove dipstick, wipe clean, put back in hole
(but don't screw in) and check lubricant level.
BM907022 QUICK REFERENCE GUIDE
1
Add fuel (see page 14).
NOTICE:
Do not use E15 or E85 fuel in this prod-
uct. It is a violation of federal law and will
damage the unit and void your warranty.
Only use OUTSIDE and Only use unleaded gasoline containing
far away from windows,
up to 10% ethanol.
doors, and vents.
Combination Wrench
This is a 4-cycle engine. Do not mix fuel and
lubricant together.
Mix fuel stabilizer with gasoline according to
manufacturer's directions prior to filling the
tank.
Turn the fuel valve to ON and put the engine
2
switch in the ON position, wait 30 seconds (see
page 15).
FUEL
VALVE ON
Turn the engine switch to the OFF position
1
(see page 15).
ENGINE SWITCH
(OFF POSITION)

STARTING THE UNIT

Slide the lock button down and push the engine
3
switch to the START position. Engine can also be
started by pulling the recoil starter grip until the
engine runs. (See page 15)
LOCK BUTTON
OR PULL RECOIL STARTER
TO START
30 S
NOTICE:
A connected and
charged battery is
required for the
generator to be
started using
either the engine
switch or the
recoil starter.

STOPPING THE UNIT

2 Turn the fuel valve to the OFF position (see page 15).
FUEL
VALVE OFF

USING THE GENERATOR

1
Connect devices to be powered by generator by following the steps below (see pages 8-9).
• Make sure the generator can supply enough continuous (running) and surge (starting) watts for the items you
will power at the same time. See page 9 for how to calculate total amount of power needed.
• Start the generator with nothing connected.
• Plug in and turn on the first load, preferably the largest load you have.
• Permit the generator output to stabilize (engine runs smoothly and attached device operates properly).
• Plug in and turn on the next load.
• Again, permit the generator to stabilize.
• Repeat previous two steps for each additional load.
IMPORTANT: Never add more loads than the generator capacity. Take special care to consider surge loads in
generator capacity. (See pages 8-9.)

STORING THE UNIT

When preparing to store the generator, allow the unit to cool for 30 minutes, then follow the guidelines listed on
1
page 18.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE
Engine will not start. Battery disconnected or not charged.
Check engine indicator light is on.
Engine switch is OFF.
No fuel.
Stale gasoline or water in gasoline.
Lubricant level is low.
Fuel valve is OFF.
Spark plug faulty, fouled, or improperly gapped.
Engine stored without treating or draining gaso-
line, or refueled with bad gasoline.
Dirty fuel filter.
CO sensor LED is flashing red, indicating a CO
hazard.
CO sensor LED is flashing yellow and/or making
an audible chirp, indicating a sensor fault.
Engine hard to start. Water in gasoline.
Weak spark at spark plug.
Engine lacks power. Dirty air filter.
Engine stored without treating or draining gaso-
line, or refueled with bad gasoline.
Electric start feature not Battery disconnected or not charged.
working.
Engine battery charge circuit fuse is blown.
CO sensor has caused automatic shutoff and CO
levels are not yet at a safe level.
AC receptacle does not work. Circuit breaker is tripped.
GFCI is tripped.
Item plugged in is defective.
Generator makes a "spark An occasional light "knocking" or "pinging" under
knock" or "pinging" noise. heavy load is not a cause for concern. However, if
the knocking or pinging occurs under normal load
at a steady engine speed, the problem may be with
the brand of gasoline being used.
If problem persists after trying the above solutions, contact customer service or a qualified service center
NOTICE:
As the equipment owner, you are responsible for the performance of the required maintenance listed in the Maintenance
section It is recommended that you retain all receipts covering maintenance on your equipment. Neglecting or failing to perform the
required maintenance may increase emissions, decrease fuel efficiency, degrade performance, cause irreversible engine damage and/or
void your warranty.
Make the most of your purchase! Go to www.blackmaxtools.com
and register your new tool online. For questions about operating
or maintaining your product, please call 1-800-726-5760.
SOLUTION
Make sure battery is connected and charged.
Contact a qualified service center.
Turn engine switch to ON.
Fill fuel tank.
Drain entire system and refill with fresh fuel.
Check engine lubrincant level and fill, if
necessary.
Turn fuel valve ON.
Replace spark plug.
Drain fuel and carburetor. Refuel with fresh
gasoline.
Replace fuel filter or contact a qualified service
center.
Leave area immediately and relocate to an open
outdoor area. Ventilate area thoroughly before oc-
cupying again. Ensure the generator is located in
an open outdoor area at least 20 feet away from all
doors, windows, and occupied spaces, and point
exhaust away from occupied structures.
The CO sensor needs to be repaired or replaced.
Contact customer service or a qualified service
center for assistance.
Drain entire system and refill with fresh fuel.
Replace spark plug or contact a qualified service
center.
Check air filter element. Clean or replace as
needed.
Drain fuel and carburetor. Refuel with fresh gaso-
line. If problem continues, contact a qualified
service center.
Make sure battery is connected and charged.
Replace the engine battery charge circuit fuse.
Ensure the generator is located in an open, out-
door area and point exhaust away from occupied
structures before restarting.
Reset the AC circuit breaker.
Reset the GFCI.
Try a different item.
Switch to a different brand of gasoline, making sure
that the octane rating is 86 or higher. If problem
continues, contact a qualified service center.
for assistance.
